CHAPTER 8: Upgrading Your Notebook
88
7 Loosen the seven memory bay cover screws (these
screws cannot be removed).
8 Use the thumb notch to lift the memory bay cover, then
remove it. Be careful not to break off the tabs located
on the end of the cover opposite of the thumb notch.
9 If you are removing a module, gently press outward on
the clip at each end of the memory module until the
module tilts upward.
Screws
Screws
Screws
Thumb notch
Clip
Clip
