NOTEBOOK REFERENCEGUIDE ®
Contents Chapter 1: About This Reference. . . . . . . . . . . . 1 About this guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Accessing your online User Guide . . . . . . . . . . . . . . . . . . . . . 2 Gateway contact information . . . . . . . . . . . . . . . . . . . . . . . . . 3 Gateway model and serial number . . . . . . . . . . . . . . . . . 3 Microsoft Certificate of Authenticity . . . . . . . . . . . . . . . . . . . 3 For more information . . . . . . . . . . . . . . . . .
Contents Adjusting brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Turning your wireless radio on or off . . . . . . . . . . . . . . . . . 32 IEEE 802.11 wireless network radio . . . . . . . . . . . . . . . . 33 Bluetooth radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Chapter 4: Using Drives and Accessories . . . . . 35 Using the memory card reader . . . . . . . . . . .
www.gateway.com Chapter 6: Traveling with Your Notebook . . . 57 Packing your notebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Traveling by air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Dial-up modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Radio frequency wireless connections . . . . . . . . . . . . . . . . . 59 Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Security . . .
Contents Diskette drive (external) . . . . . . . . . . . . . . . . . . . . . . . . . 91 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92 DVD drives (external) . . . . . . . . . . . . . . . . . . . . . . . . . . . 93 Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 File management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95 Hard drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CHAPTER1 About This Reference • • • • • About this guide Accessing your online User Guide Gateway contact information Microsoft Certificate of Authenticity For more information 1
CHAPTER 1: About This Reference About this guide This guide includes information and maintenance instructions that are specific to your model of Gateway notebook. For all other notebook information, see your online User Guide. Accessing your online User Guide In addition to this guide, your online User Guide has been included on your hard drive.
www.gateway.com Gateway contact information Important The labels shown in this section are for informational purposes only. Label information varies by model, features ordered, and location. Gateway model and serial number The label on the bottom of your notebook contains information that identifies your notebook model and its features. Gateway Customer Care will need this information if you call for assistance.
CHAPTER 1: About This Reference 4
CHAPTER2 Checking Out Your Notebook • • • • • Front Left Right Bottom Keyboard area 5
CHAPTER 2: Checking Out Your Notebook Front Power indicator Battery charge indicator Component Power indicator Icon Description ■ ■ ■ Battery charge indicator 6 LED on - Notebook is on. LED blinking - Notebook is in Sleep or Hybrid Sleep mode. LED off - Notebook is off. LED blue - Battery is fully charged. LED purple - Battery is charging. ■ LED blinking red - Battery charge is very low. ■ LED solid red - Battery is malfunctioning.
www.gateway.com Left Power connector Monitor port Component Docking port Icon Ventilation fan Memory card reader PC Card slot Description Power connector Plug the AC adapter cable into this connector. Monitor port Plug an analog VGA monitor or projector into this port. For more information, see “Viewing the display on a projector or monitor” on page 41. Docking port Connect the optional port replicator to this port. Warning: Power is passed through this port.
CHAPTER 2: Checking Out Your Notebook Component Icon Description PC Card slot Insert one Type II PC Card into this slot. For more information, see “Adding and removing a PC Card” on page 37. Memory card reader Insert a memory card from a digital camera, MP3 player, PDA, or cellular telephone into the memory card reader. For more information, see “Using the memory card reader” on page 36.
www.gateway.com Right USB ports Component Icon Ethernet Modem jack jack IEEE 1394 port Kensington lock slot Microphone jack Headphone jack Description USB ports Plug USB devices (such as a CD or DVD drive, diskette drive, flash drive, printer, scanner, camera, keyboard, or mouse) into these ports. Ethernet jack Plug an Ethernet network cable into this jack. The other end of the cable can be plugged into a cable modem, DSL modem, or an Ethernet network jack.
CHAPTER 2: Checking Out Your Notebook Bottom Memory bay Battery latch Speaker Battery Speaker Ventilation fan Hard drive bay Component Customer care label Icon Description Hard drive bay The hard drive is located in this bay. For more information, see “Replacing the hard drive kit” on page 86. Speakers Provide audio output when headphones or amplified speakers are not plugged in. Memory bay Install a memory module into this bay.
www.gateway.com Component Icon Description Ventilation fan Helps cool internal components. Warning: Do not work with the notebook resting on your lap. If the air vents are blocked, the notebook may become hot enough to harm your skin. Caution: Do not block or insert objects into these slots. If these slots are blocked, your notebook may overheat resulting in unexpected shutdown or permanent damage to the notebook. Caution: Provide adequate space around your notebook so air vents are not obstructed.
CHAPTER 2: Checking Out Your Notebook Keyboard area Power button Keyboard Status indicators Component Icon Touchpad Description Power button Press to turn the power on or off. You can also configure the power button for Sleep/Resume mode. For more information on configuring the power button mode, see “Changing advanced settings” on page 55. Keyboard Provides all the features of a full-sized, computer keyboard. For more information, see “Using the keyboard” on page 24.
CHAPTER3 Setting Up and Getting Started • • • • • • • • • • • • Working safely and comfortably Connecting the AC adapter Connecting the dial-up modem Connecting to a broadband modem or network Starting your notebook Turning off your notebook Restarting (rebooting) your notebook Using the status indicators Using the keyboard Using the EZ Pad touchpad Adjusting the volume Turning your wireless radio on or off 13
CHAPTER 3: Setting Up and Getting Started Working safely and comfortably Before using your notebook, follow these general guidelines for setting up a safe and comfortable work area and avoiding discomfort and strain: • Keep hands and arms parallel to the floor. • Adjust the screen so it is perpendicular to your line of sight. • Place your feet flat on the floor or on a footrest. • Although notebooks are sometimes called “laptops,” do not use your notebook while it rests on your unprotected lap.
www.gateway.com Setting up your computer desk and chair When you are setting up your computer desk and chair, make sure that the desk is the appropriate height and the chair helps you maintain good posture. • Select a flat surface for your computer desk. • Adjust the height of the computer desk so your hands and arms are positioned parallel to the floor when you use the keyboard and touchpad.
CHAPTER 3: Setting Up and Getting Started Connecting the AC adapter You can run your notebook using an AC adapter or your notebook’s battery. The battery was shipped to you partially charged. You should use the AC adapter right away to fully charge the battery. Allow three hours for the battery to fully charge. Warning Do not attempt to disassemble the AC adapter. The AC adapter has no user-replaceable or user-serviceable parts inside.
www.gateway.com 2 Connect the AC adapter to your notebook’s power connector. 3 Plug the power cord into a wall outlet. The battery charge indicator turns on (see “Front” on page 6 for the location of the battery charge indicator). If the battery charge indicator does not turn on, complete the following steps until it turns on: a Unplug the adapter from your notebook, then plug it back in. b Press FN+F1 to toggle the status lights on and off.
CHAPTER 3: Setting Up and Getting Started Connecting the dial-up modem Your notebook has a built-in 56K modem that you can use to connect to a standard telephone line. Warning To reduce the risk of fire, use only No. 26 AWG or larger (for example, No. 24 AWG) UL-listed or CSA-certified telecommunication line cord for your dialup modem connection. To connect the modem: 1 Insert one end of the modem cable into the modem jack on your notebook.
www.gateway.com Connecting to a broadband modem or network Your notebook has a network jack that you can use to connect to a cable or DSL modem or to a wired Ethernet network. To connect to a cable or DSL modem or to a wired Ethernet network: 1 Insert one end of the network cable into the network jack on your notebook. 2 Insert the other end of the network cable into a cable modem, DSL modem, or Ethernet network jack.
CHAPTER 3: Setting Up and Getting Started Starting your notebook Warning Do not work with the notebook resting on your lap. If the air vents are blocked, the notebook may become hot enough to harm your skin. Caution Provide adequate space around your notebook so air vents are not obstructed. Do not use the notebook on a bed, sofa, rug, or other similar surface. To start your notebook: 1 Lift the LCD panel. 2 Press the power button located above the keyboard.
www.gateway.com Waking up your notebook When you have not used your notebook for several minutes or if you close the LCD panel without turning off your notebook, it may enter a power-saving mode called Sleep. While in Sleep mode, the power indicator flashes. If your notebook is in Sleep mode, press the power button to “wake” it up. Tip For more information about Sleep mode, see “Changing power modes” on page 52.
CHAPTER 3: Setting Up and Getting Started To turn off your notebook: (Start), click the arrow next to the lock icon, then click Shut Down. The notebook turns off. • Click Important If for some reason you cannot use the Shut Down option in Windows to turn off your notebook, press and hold the power button for about five seconds, then release it.
www.gateway.com Using the status indicators Important If none of the indicators are on, you may need to press FN+F1 to toggle the status indicators on. Status indicators inform you when a drive is being used or when a button has been pressed that affects how the keyboard is used. The status indicators are located below the touchpad.
CHAPTER 3: Setting Up and Getting Started Indicator Icon Battery charge Description ■ ■ ■ ■ Num lock ■ 1 Caps lock ■ ■ A ■ LED blue - Battery is fully charged. LED purple - Battery is charging. LED blinking red - Battery charge is very low. LED solid red - Battery is malfunctioning. LED on - Numeric keypad is turned on. LED off - Numeric keypad is turned off. LED on - Caps lock is turned on. LED off - Caps lock is turned off.
www.gateway.com Key types The keyboard has several different types of keys. Some keys perform specific actions when pressed alone and other actions when pressed in combination with another key. Key type Icon Description Function keys Press these keys labeled F1 to F11 to perform actions in programs. For example, pressing F1 may open help. Each program uses different function keys for different purposes. See the program documentation to find out more about the function key actions.
CHAPTER 3: Setting Up and Getting Started System key combinations When you press the FN key and a system key at the same time, your notebook performs the action identified by the text or icon on the key. Press and hold FN, then press this system key... To... Toggle the status indicators on or off. For more information, see “Using the status indicators” on page 23. Turn the optional IEEE 802.11 wireless network radio on or off.
www.gateway.com Press and hold FN, then press this system key... To... Turn the optional Bluetooth radio on or off. Warning: Radio frequency wireless communication can interfere with equipment on commercial aircraft. Current aviation regulations require wireless devices to be turned off while traveling in an airplane. Bluetooth communication devices are examples of devices that provide wireless communication. -+ Increase the LCD panel brightness above the normal brightest setting.
CHAPTER 3: Setting Up and Getting Started Using the EZ Pad touchpad The EZ Pad™ consists of a touchpad and two buttons. Touchpad Left button Right button When you move your finger on the touchpad, the pointer (arrow) on the screen moves in the same direction. You can use the EZ-Pad left and right buttons below the touchpad to select objects. Tip You can attach a mouse to the notebook or optional port replicator using a USB port. You do not need to shut down the notebook to connect a USB mouse.
www.gateway.com Tip You may have received your notebook with the EZ Pad touchpad set to only accept clicking by using the touchpad buttons. You can change this feature to allow tapping on the touchpad to simulate clicking the left button. For more information, see “Changing the mouse, touchpad, or pointing device settings” in your online User Guide. To... Do this... Move the pointer on the screen. Move your finger around on the touchpad.
CHAPTER 3: Setting Up and Getting Started To... Do this... Move an object on the screen. Position the pointer over the object. Press the left button and hold it down, then use the touchpad to move (drag) the object to the appropriate part of the screen. Release the button to drop the object where you want it. Adjusting brightness To adjust screen brightness: • Use the increase brightness and decrease brightness keys on the keyboard. For more information, see “System key combinations” on page 26.
www.gateway.com Adjusting the volume You can use the volume control to adjust the overall volume of your notebook. To adjust the overall volume level using hardware controls: • If you are using external speakers, turn the knob on the front of the speakers. -ORUse the mute and volume control buttons on the keyboard. For more information, see “System key combinations” on page 26. -ORClick (Start), All Programs, Accessories, then click Windows Mobility Center. The Windows Mobility Center window opens.
CHAPTER 3: Setting Up and Getting Started 4 To adjust device volume levels, click Mixer. The Volume Mixer dialog box opens, where you can click and drag sliders for individual devices. Tip Adjust the Windows Sounds slider to change system sounds volume independently of general volume (such as the volume used for music and game sounds). 5 Click X in the top-right corner of the window to close it. Turning your wireless radio on or off Your Gateway notebook may have a factory-installed wireless radio.
www.gateway.com IEEE 802.11 wireless network radio Your notebook may have an IEEE 802.11 radio for communicating with other computers on a wireless Ethernet network. To turn the wireless IEEE 802.11 radio on or off: • Press FN + F2. The wireless status indicator turns on or off. For the location of the wireless status indicator, see “Using the status indicators” on page 23. -ORClick (Start), All Programs, Accessories, then click Windows Mobility Center. The Windows Mobility Center window opens.
CHAPTER 3: Setting Up and Getting Started 34
CHAPTER4 Using Drives and Accessories • • • • • Using the memory card reader Adding and removing a PC Card Using an optional port replicator Installing a printer or other peripheral device Viewing the display on a projector or monitor • Ordering accessories 35
CHAPTER 4: Using Drives and Accessories Using the memory card reader You can use memory cards to transfer pictures from a digital camera to your notebook. You can also use the memory card reader to transfer data between your notebook and a device that uses memory cards, such as a PDA, MP3 player, or cellular telephone. Memory card types The memory card reader supports Memory Stick®, Memory Stick Pro®, MultiMediaCard™, Secure Digital™, Mini Secure Digital™, and RS-MultiMediaCard™.
www.gateway.com Adding and removing a PC Card Your notebook has a PC Card slot (also known as a PCMCIA card slot). This slot accepts one Type II card. You do not need to restart your notebook when changing most cards because your notebook supports hot-swapping. Hot-swapping means that you can insert a PC Card while your notebook is running. If your PC Card does not work after hot-swapping, see the PC Card manufacturer’s documentation for further information.
CHAPTER 4: Using Drives and Accessories 5 Release the eject button by pressing the PC Card eject button once. 6 Eject the PC Card by pressing the eject button again. Using an optional port replicator Although you can attach devices directly to your notebook, a port replicator lets you make all of those connections at one time. When you travel with your notebook, you merely disconnect from the port replicator instead of unplugging all the devices.
www.gateway.com Installing a printer or other peripheral device Your notebook or optional port replicator has one or more of the following ports: IEEE 1394 (also known as Firewire® or i.Link®) and Universal Serial Bus (USB). You use these ports to connect peripheral devices such as printers, scanners, and digital cameras to your notebook. Important Before you install a printer, scanner, or other peripheral device, see the device documentation and installation instructions.
CHAPTER 4: Using Drives and Accessories To connect your USB device to your notebook: 1 Connect one end of the USB cable to your device. 2 Connect the other end of the cable to a USB port on your notebook. Tip For the location of the USB ports on your notebook, see “Right” on page 9. For the location of the USB ports on an optional port replicator, see the port replicator user guide. Connecting an IEEE 1394 device Your notebook has a 4-pin IEEE 1394 port (also known as a Firewire® or i.
www.gateway.com Viewing the display on a projector or monitor You can use your notebook for giving presentations by connecting an external monitor or projector to your monitor (VGA) port. Your notebook supports simultaneous LCD and external display. Simultaneous display lets you control the presentation from your notebook at the same time as you face your audience. To use a projector or external monitor: 1 Turn off your notebook.
CHAPTER 4: Using Drives and Accessories Adjusting the display properties If the image on the projector or monitor does not appear correctly, or if you want to use the display as an extension of your notebook desktop, you should adjust the display properties on the projector or external monitor. To adjust the display properties on a projector or external monitor: 1 Click (Start), All Programs, Accessories, then click Windows Mobility Center. The Windows Mobility Center window opens.
www.gateway.com 6 To use the external monitor or projector as an extension of your desktop (increasing the size of your Windows desktop), click to select the check box for Extend my Windows desktop onto this monitor. You can click and drag the “2” monitor icon to position it the same way the physical monitor is arranged on your desk. 7 Click OK. Using the projector or monitor for a presentation You can configure your notebook so the settings are correct each time you give a presentation.
CHAPTER 4: Using Drives and Accessories 3 Adjust properties such as Turn off screen saver and Set the volume to if necessary. 4 Click OK. 5 Click Turn on to turn on the presentation settings. When you are finished giving the presentation, click Turn off to return to your standard notebook settings. Ordering accessories To order accessories, visit the Accessory Store at www.gateway.com. Accessories may not be available in all localities.
www.gateway.com Port replicators Although you can attach devices directly to your notebook, a port replicator lets you make all of those connections at one time. When you travel with your notebook, you merely disconnect from the port replicator instead of unplugging all the devices. A port replicator also provides additional ports and other expansion features not included with your notebook. See the user guide for the port replicator for more information about using a port replicator with your notebook.
CHAPTER 4: Using Drives and Accessories 46
CHAPTER5 Managing Power • • • • • • Monitoring the battery charge Recharging the battery Changing the battery Recalibrating the battery Getting the most from your battery Changing notebook power settings 47
CHAPTER 5: Managing Power Monitoring the battery charge Your new Gateway notebook is designed to provide an exceptional balance of performance and portability. Your notebook uses the latest chipset and mobile processor technologies to manage the processor speed and power consumption for a greater battery life experience. This design provides you with maximum performance when plugged into AC power balanced with optimized battery life when on battery power. Closely monitor the battery charge.
www.gateway.com Changing the battery Replacing the battery Warning Danger of explosion if battery is incorrectly replaced. Replace only with a battery specifically manufactured for your Gateway notebook. Discard used batteries according to local hazardous material regulations. The battery used in this device may present a fire or chemical burn hazard if mishandled. Do not disassemble, heat above 212°F (100°C), or incinerate. Dispose of used batteries promptly. Keep away from children.
CHAPTER 5: Managing Power 6 Slide the battery latch to the locked position. 7 Turn your notebook over. 8 Open the LCD panel. Recalibrating the battery Important Do not interrupt the battery recalibration process. If recalibration is interrupted, you must start the process over again. If your notebook unexpectedly goes into Sleep mode while you are using it but the battery charge is not low, you may need to recalibrate your battery.
www.gateway.com Getting the most from your battery Maximizing battery performance To get maximum performance from your notebook battery, we recommend that you initially condition (fully charge and discharge) your new battery a few times during the first several weeks of use, to let it reach its maximum rated capacity.
CHAPTER 5: Managing Power • Use the notebook touchpad instead of an external mouse. • Decrease or mute speaker volume. • Turn off all scheduled tasks. • Turn off auto-save features in Microsoft Office and other applications. • Copy programs from CDs or DVDs to the hard drive so you do not use battery power by running external optical drives. • Use the external CD or DVD drive only when necessary. This drive uses a large amount of power.
www.gateway.com • Hibernate - (also called save to disk) writes all current • memory (RAM) information to the hard drive, then turns your notebook completely off. The next time you turn on your notebook, it reads the memory information from the hard drive and opens the programs and documents that were open when you activated Hibernate mode.
CHAPTER 5: Managing Power Changing notebook power settings You can change the function of your notebook’s power button, Sleep system key, and power-saving timers by changing power settings on your notebook. You can customize power settings from the Windows Mobility Center by selecting power plans and adjusting advanced power settings. Changing the power plan Power plans (groups of power settings) let you change power saving options such as when the display or hard drive is automatically turned off.
www.gateway.com To change the power plan: 1 Click (Start), All Programs, Accessories, then click Windows Mobility Center. The Windows Mobility Center window opens. 2 Click (Change power settings). The Select a power plan window opens. 3 Select the power plan you want to use. - OR Click Change plan settings, modify the power plan you selected, then click Save changes. Help For more information about changing the power plan, click Start, then click Help and Support.
CHAPTER 5: Managing Power 2 Click (Change power settings). The Select a power plan window opens. 3 Click a setting on the left side of the screen that you want to change. The top three settings are not tied to a power plan. The bottom three settings modify the currently selected power plan. Help For more information about changing the power management settings, click Start, then click Help and Support. Type the keyword power management in the Search Help box, then press ENTER.
CHAPTER6 Traveling with Your Notebook • • • • • • • • Packing your notebook Traveling by air Dial-up modem Radio frequency wireless connections Files Security Power Additional tips 57
CHAPTER 6: Traveling with Your Notebook Packing your notebook • Remove all peripheral devices and cables. Remember to • • pack those you will need while traveling (including your external CD or DVD drive). Pack your notebook securely into a briefcase or hand-carried luggage, and keep it separate from toiletries, liquids, and food. Do not pack it in checked luggage. Keep your notebook stable during travel. Secure it to prevent it from sliding around in overhead bins and car trunks.
www.gateway.com Radio frequency wireless connections Important If your notebook came equipped with an internal embedded wireless device, see “Legal Information” on page 117 for general wireless regulatory guidelines. • Every country has different restrictions on the use of • wireless devices. If your notebook is equipped with a wireless device, check with the local radio approval authorities prior to your trip for any restrictions on the use of a wireless device in the destination country.
CHAPTER 6: Traveling with Your Notebook Security • Get a locking cable for your notebook so you can attach • • • a cable lock and leave your notebook in your hotel room while you are away. Always keep your notebook with you while waiting in airports, train stations, or bus terminals. Be ready to claim your notebook as soon as it passes through the X-ray machine in security checkpoints.
www.gateway.com 4 Highlight Password on boot, then press ENTER. 5 Highlight Enabled, then press ENTER. 6 Open the Exit menu, highlight Exit Saving Changes, then press ENTER. 7 When you start your computer, you are prompted to enter the user password you set in Step 3. • Review the information in “Protecting your notebook” in your online User Guide. Power • Take your AC power adapter to recharge the battery. If • • you are traveling internationally, take power plug adapters.
CHAPTER 6: Traveling with Your Notebook • Consult your insurance company and credit card • company to learn about emergency travel assistance if your notebook is lost or damaged. Take your recovery discs in case you need to install an additional driver or software. Tip You can create a Drivers and Applications Recovery disc using the Gateway Recovery Center.
CHAPTER7 Maintaining Your Notebook • • • • • Caring for your notebook Cleaning your notebook Maintaining the battery Cleaning CDs or DVDs Recovering your system 63
CHAPTER 7: Maintaining Your Notebook Caring for your notebook To extend the life of your notebook: • Be careful not to bump or drop your notebook, and do not put any objects on top of it. The case, although strong, is not made to support extra weight. • When transporting your notebook, we recommend that you put it in a carrying case. • Keep your notebook away from magnetic fields. Magnetic fields can erase data on hard drives.
www.gateway.com Cleaning your notebook Keeping your notebook clean and the vents free from dust helps keep your notebook performing at its best. You may want to gather these items and put together a notebook cleaning kit: • A soft, lint-free cloth • An aerosol can of air that has a narrow, straw-like extension • Cotton swabs • A DVD drive cleaning kit Cleaning the exterior Warning When you shut down your notebook, the power turns off, but some electrical current still flows through your notebook.
CHAPTER 7: Maintaining Your Notebook Cleaning the keyboard You should clean the keyboard occasionally by using an aerosol can of air with a narrow, straw-like extension to remove dust and lint trapped under the keys. If you spill liquid on the keyboard, turn off your notebook and turn the notebook upside down. Let the liquid drain, then let the keyboard dry before trying to use it again. If the keyboard does not work after it dries, you may need to replace it.
www.gateway.com Using the right charger is important. By now you probably know that each kind of battery has its own technology, its own rate of charge, and so on. Charging lithium batteries correctly is one way to extend their life and to avoid damage. Clean the gold or silver connector on the battery (the part of the battery that makes contact with the notebook) with alcohol or electronic contact cleaner.
CHAPTER 7: Maintaining Your Notebook Cleaning CDs or DVDs Wipe from the center to the edge, not around in a circle, using a product made especially for the purpose. Recovering your system You can solve most computer problems by following the information in “Troubleshooting” on page 89 or in the technical support pages at www.gateway.com. Problem solving may also involve re-installing some or all of the notebook’s software (also called recovering or restoring your system).
www.gateway.com If you upgrade or exchange your hard drive or if your hard drive is completely erased or corrupted, your only option for system recovery may be to reinstall Windows from the Windows DVD, then recover your pre-installed software and device drivers using recovery discs that you created. (Your notebook must have an external DVD-compatible drive to use these options.) • To re-install Windows using the Windows DVD, see “Recovering your system using the Windows DVD” on page 79.
CHAPTER 7: Maintaining Your Notebook You should create a set of discs for recovering your pre-installed software and device drivers, in case you need to use them later for a complete system recovery. (Your notebook must have an external recordable disc drive to perform this procedure.) To create discs for recovering pre-installed software and drivers: 1 Click (Start), All Programs, Gateway Recovery Center, then click Gateway Recovery Center. The Gateway Recovery Center opens.
www.gateway.com 4 Insert a blank, recordable disc into an external recordable disc drive, then click Next. If an AutoPlay dialog box opens, click the x in the upper-right corner to close it. A dialog box opens that tells you the number of blank discs you need to create a full set of recovery discs. 5 If you have enough blank discs of the specified type, click I have enough discs, then click Next. If you do not have enough discs, choose a different disc type, or click Cancel. The disc recording begins.
CHAPTER 7: Maintaining Your Notebook Recovering pre-installed software and drivers using Gateway Recovery Center To recover specific drivers and software: 1 Click (Start), All Programs, Gateway Recovery Center, then click Gateway Recovery Center. The Gateway Recovery Center opens.
www.gateway.com 3 Click the software or driver you want to recover, then click Next. Recovering pre-installed software and drivers using recovery discs If you created a multiple-disc set of recovery discs, each disc contains a unique set of software and drivers. If a recovery disc does not offer the software or driver you need to recover, try another disc. To recover software and drivers using recovery discs: 1 Insert a software and driver recovery disc into an external CD or DVD drive.
CHAPTER 7: Maintaining Your Notebook 2 To recover pre-installed software, click Application recovery, then click the software you want to recover. - OR To recover pre-installed device drivers, click Device driver recovery, then click the type of driver you want to recover. 3 Click Next. 4 If the software or driver is not shown on the list, and you have a multiple-disc set of recovery discs, close Gateway Recovery Center and try another disc.
www.gateway.com Using Microsoft System Restore Microsoft System Restore periodically takes “snapshots” of your system settings and saves them as restore points. In most cases of hard-to-resolve software problems, you can return to one of these restore points to get your system running again. Windows automatically creates an additional restore point each day, and also each time you install software or device drivers. You can also create a restore point manually.
CHAPTER 7: Maintaining Your Notebook 2 On the left side of the window, click Repair Windows using System Restore, then click Next. The Choose a restore point dialog box opens. 3 Click the restore point you want, click Next, then click Finish. A confirmation message box appears. 4 Click Yes. Your system is restored using the restore point you specified. This process may take several minutes, and may restart your notebook.
www.gateway.com Manually creating a restore point To manually create a restore point: (Start), Control Panel, System and Maintenance, then click Backup and Restore Center. The Backup and Restore Center opens. 1 Click 2 On the left side of the window, click Create a restore point or change settings, then click Next. The System Properties dialog box opens to the System Protection tab. 3 Click Create. The Create a restore point dialog box opens.
CHAPTER 7: Maintaining Your Notebook Recovering your system to its factory condition If your notebook’s problems are not solved by any of the other recovery options, you may need to recover its hard drive to its factory condition. This process is called a factory recovery. Caution A complete factory recovery deletes everything on your hard drive, then reinstalls Windows and any pre-installed software and device drivers. If you can access important files on your hard drive, back them up now.
www.gateway.com 8 To perform a recovery with data backup (recommended), click Recovery with automatic data backup, then click Next. Important Before your hard drive is recovered, your personal files will be automatically backed up to c:\backup. - OR To perform a full factory recovery without data backup, click Full factory recovery, then click Next. Caution Continuing with the full factory recovery will delete everything on your hard drive.
CHAPTER 7: Maintaining Your Notebook 3 When the prompt “Press any key to boot from CD or DVD” appears, press any key on your keyboard. A list of valid boot devices appears. 4 Press the arrow keys to select the drive containing the Windows DVD, then press ENTER and follow the on-screen instructions. 5 After Windows is completely re-installed, use the software and driver recovery discs you created to recover your notebook’s pre-installed software and device drivers.
CHAPTER8 Upgrading Your Notebook • Preventing static electricity discharge • Adding or replacing memory modules • Replacing the hard drive kit 81
CHAPTER 8: Upgrading Your Notebook Preventing static electricity discharge Warning To avoid exposure to dangerous electrical voltages and moving parts, turn off your notebook, unplug the power cord, modem cable, and network cable, and remove the battery before opening the case. Warning To prevent risk of electric shock, do not insert any object into the vent holes of the notebook. Important Before installing or replacing components, you should read and understand the information in this section.
www.gateway.com Adding or replacing memory modules Important Use only memory modules designed for your Gateway notebook. Tools You need a small Phillips screwdriver to replace memory modules. Your notebook uses memory modules called SO-DIMMs (Small Outline Dual Inline Memory Modules). The modules are available in various capacities and any module can be placed in any slot. Memory bay To add or replace memory modules: 1 Follow the guidelines under “Preventing static electricity discharge” on page 82.
CHAPTER 8: Upgrading Your Notebook 7 Loosen the captive memory bay cover screw (this screw cannot be removed), then remove the cover. Screw 8 Gently press outward on the clip at each end of the memory module until the module tilts upward. Clip Clip 9 Pull the memory module out of the slot.
www.gateway.com 10 Hold the replacement module at a 30-degree angle and slide it into the empty memory slot. This module is keyed so it can only be inserted in one direction. If the module does not fit, make sure that the notch in the module lines up with the tab in the memory bay. Important Use only memory modules designed for your Gateway notebook. 11 Gently push the module down until it clicks in place. 12 Replace the memory bay cover, then tighten the captive screw.
CHAPTER 8: Upgrading Your Notebook Replacing the hard drive kit Tools You need a small Phillips screwdriver to replace the hard drive kit. If you would like more hard drive capacity, you can replace your original drive with a higher-capacity drive. Hard drive To replace the hard drive kit: 1 Create a Drivers and Applications Recovery disc using the Gateway Recovery Center. For more information, see “Recovering pre-installed software and drivers” on page 69.
www.gateway.com 9 Remove the two hard drive bay cover screws. Screw Screw 10 Slide the hard drive bay cover, then remove it. The hard drive is attached to the back of the cover. 11 Remove the screws on the side of the hard drive that secure the hard drive to the hard drive cover. Screw Screw Screw Screw 12 Remove the metal shield covering the old drive. 13 Insert the new drive label side up onto the cover so the screw holes line up.
CHAPTER 8: Upgrading Your Notebook 14 Replace the metal shield. 15 Replace the screws that secure the cover to the drive. 16 Slide the new hard drive into your notebook, then replace the cover screws. 17 Insert the battery then turn your notebook over. 18 Connect to the optional port replicator. -ORConnect the power adapter, modem cable, network cable, and external DVD drive. 19 Turn on your notebook, open the external DVD drive, insert the Windows DVD, close the DVD drive, then restart your notebook.
CHAPTER9 Troubleshooting • • • • Safety guidelines First steps Troubleshooting Telephone support 89
CHAPTER 9: Troubleshooting Safety guidelines Warning Do not try to troubleshoot your problem if power cords or plugs are damaged, if your notebook was dropped, or if the case was damaged. Instead, unplug your notebook and contact a qualified computer technician. Tip For more information about preventing damage from static electricity, see “Preventing static electricity discharge” on page 82.
www.gateway.com • If a peripheral device (such as a keyboard or mouse) does not work, make sure that all connections are secure. Make sure that your hard drive is not full. • • If an error message appears on the screen, write down • • the exact message. The message may help Gateway Customer Care in diagnosing and fixing the problem. If you added or removed peripheral devices, review the installation procedures you performed and make sure that you followed each instruction.
CHAPTER 9: Troubleshooting You see an “Access Denied” or “Write protect” error message • Move the write-protection tab in the upper-right corner of the diskette down (unprotected). • The diskette may be full. Delete unnecessary files on the diskette and try again. • Not all diskettes are IBM-compatible. Make sure that the diskette you are using is IBM-compatible. • Try a different diskette. Occasionally diskettes are flawed and cannot be read by the diskette drive.
www.gateway.com The text on the display is dim or difficult to read • Adjust the brightness using the system keys or Windows Mobility Center. For more information about adjusting the brightness, see “Adjusting brightness” on page 30. • Change the display settings. For instructions on changing the display settings, see “Changing screen settings” in your online User Guide.
CHAPTER 9: Troubleshooting • Try a different disc. Occasionally discs are flawed and cannot be read by the drive. • Some music CDs have copy protection software. You may not be able to play these CDs on your notebook. • Your notebook may be experiencing some temporary • memory problems. Shut down and restart your notebook. Clean the disc. For more information, see “Cleaning CDs or DVDs” on page 68. An audio CD does not produce sound • Make sure that the CD label is facing up, then try again.
www.gateway.com • Make sure that the disc’s regional code and your DVD drive’s regional code match. • Make sure that a DVD player program has been installed on your notebook. For instructions on playing a DVD, see “Playing music and movies” in your online User Guide. You cannot eject a CD or DVD Your notebook must be turned on to remove CDs and DVDs. If you do not want to turn on your notebook, manually eject the disc by inserting an opened paper clip into the manual eject hole.
CHAPTER 9: Troubleshooting Hard drive You see an “Insufficient disk space” error message • Delete unnecessary files from the hard drive using Disk Cleanup. For instructions on deleting unnecessary files, see “Deleting unnecessary files” in your online User Guide. • Empty the Recycle Bin by right-clicking the Recycle Bin icon, then clicking Empty Recycle Bin. Caution All deleted files will be lost when you empty the Recycle Bin. • Save your files to another drive.
www.gateway.com Internet You cannot connect to the Internet • If you are using a dial-up modem, make sure that the modem cable is plugged into the modem jack and not the Ethernet network jack. For the location of your modem jack, see “Right” on page 9. -OR- • • If you are using a cable or DSL modem, make sure that the modem cable is plugged into the Ethernet network jack and not the modem jack. For the location of your network jack, see “Right” on page 9.
CHAPTER 9: Troubleshooting • The complexity of graphics and multimedia on Web pages • Having multiple Web browsers open, performing multiple downloads, and having multiple programs open on your notebook People are sending you e-mail messages, but you have not received any mail • Click the receive button in your e-mail program. • Make sure that your account with your Internet service provider (ISP) is set up correctly. Contact your ISP for technical support.
www.gateway.com Media Center This section only covers problems relating to Media Center mode. Media Center mode is available only on Windows Vista Home Premium and Ultimate versions. To view Media Center troubleshooting information that is not covered in this section, go to the Gateway support Web Site at www.gateway.com.
CHAPTER 9: Troubleshooting Help For more information about adjusting display settings, click Start, then click Help and Support. Type the keyword changing display settings in the Search Help box, then click the arrow. • Size of display device—Small computer monitors for • standard computer applications are generally not optimized for motion video playback. Although they offer excellent resolutions and refresh rates, they are designed to make static white backgrounds with black text look readable.
www.gateway.com You want to change display settings to get better TV or DVD image quality • Adjust the display device brightness, contrast, hue, and saturation. For more information review the FAQ topic at www.gateway.com. You want to know whether you can burn videos that were recorded with your Media Center computer to a DVD • Yes, you can. The Media Center saves recorded videos in the DVR-MS format.
CHAPTER 9: Troubleshooting 4 Double-click Memory Diagnostics Tool, then follow the on-screen instructions. Help For more information about troubleshooting memory errors, click Start, then click Help and Support. Type the keyword memory error in the Search Help box, then press ENTER. You see a “Not enough memory” error message • Close all programs, then restart your notebook. Memory card reader Drive letter for the memory card slot does not appear in the My Computer window • Reboot your notebook.
www.gateway.com • Make sure that the modem cable is less than 6 feet (1.8 meters) long. • Remove any line splitters or surge protectors from your • telephone line, then check for a dial tone by plugging a working telephone into the telephone wall jack. If you have additional telephone services such as call waiting, call messaging, or voice mail, make sure that all messages are cleared and call waiting is disabled before using the modem.
CHAPTER 9: Troubleshooting • Check for line noise (scratchy, crackling, or popping sounds). Line noise is a common problem that can cause the modem to connect at a slower rate, abort downloads, or even disconnect. The faster the modem, the less line noise it can tolerate and still work correctly. Listen to the line using your telephone. Dial a single number (such as 1). When the dial tone stops, listen for line noise. Wiggle the modem cable to see if that makes a difference.
www.gateway.com The modem is not recognized by your notebook • Make sure that the line connected to the modem is working and plugged into the appropriate port on your notebook. For the location of your modem jack, see “Right” on page 9. • If the modem shares the telephone line with another device, make sure that the telephone line is not in use (for example, someone is on the telephone, or another modem is in use). • Use a different modem cable.
CHAPTER 9: Troubleshooting The modem is noisy when it dials and connects When your modem tries to connect to another modem, it begins handshaking. Handshaking is a digital “getting acquainted” conversation between the two modems that establishes connection speeds and communication protocols. You may hear unusual handshaking sounds when the modems first connect. If the handshaking sounds are too loud, you can turn down the modem volume.
www.gateway.com Networks (wired) Help For more information about network troubleshooting, click Start, then click Help and Support. Type the keyword network troubleshooting in the Search Help box, then press ENTER. You cannot see the other computers on your wired Ethernet network • Make sure that your Ethernet cable is plugged into the Ethernet jack on your notebook. Make sure that the other end is plugged into a router or cable or DSL modem. For the location of your network jack, see “Right” on page 9.
CHAPTER 9: Troubleshooting Internet Explorer is unable to access the Internet • Reset the power on your cable or DSL modem and your access point. This reestablishes communication between your Internet Service Provider and your modem and between your modem and your access point. • If you previously accessed the Internet through a dial-up modem, Internet Explorer may not be set up to access the Internet through a network.
www.gateway.com Your connection on the network seems intermittent or your wireless network is running slower than you expect • The speed of a wireless network is related to signal strength. Signal strength is affected by the distance between your wireless network devices, by radio interference, and by interference from natural obstructions such as walls, ceilings, floors, and doors. If your wireless network is running slower than you expect, you should check your network signal strength.
CHAPTER 9: Troubleshooting Your wireless network is listed as a preferred network, but it has an “x” on it • An x means your preferred network is not currently available or you are not currently in range to connect. Internet Explorer is unable to access the Internet • Reset the power on your cable or DSL modem and your access point. This reestablishes communication between your Internet Service Provider and your modem and between your modem and your access point.
www.gateway.com You forgot your startup password The password feature (which is set in the BIOS Setup utility) is very secure, with no easy way to recover a forgotten password. You must return your notebook for repair. Call Gateway Customer Care for instructions. PC Cards You installed an PC Card and now your notebook is having problems • Make sure that you have correctly installed required software for the PC Card. For more information, see your PC Card’s documentation.
CHAPTER 9: Troubleshooting • Make sure that the battery is calibrated correctly. For • instructions on recalibrating your battery, see “Recalibrating the battery” on page 50. Let the battery return to room temperature. Printer Help For more information about printer troubleshooting, click Start, then click Help and Support. Type the keyword printer troubleshooting in the Search Help box, then press ENTER. The printer will not turn on • Make sure that the printer is online.
www.gateway.com You see a “Printer queue is full” error message • Make sure that the printer is not set to work offline. To make sure that the printer is not set to work offline: 1 Click (Start), then click Control Panel. The Control Panel window opens. 2 Click Hardware and Sound. 3 Click Printers. 4 If the printer status is Offline, right-click the name of the printer you want to use, then click Use Printer Online to set the printer to work online.
CHAPTER 9: Troubleshooting Status indicators The status indicators are not functioning • Make sure the status indicators are turned on. Press FN+F1 to toggle the indicators. Touchpad or pointing device Touchpad or pointing device is not working • Make sure the touchpad or pointing device is turned on. For more information, see “Changing mouse, touchpad, or pointing device settings” in your online User Guide.
www.gateway.com Telephone support Before calling Gateway Customer Care If you have a technical problem with your notebook, follow these recommendations before contacting Gateway Customer Care: • Make sure that your notebook is connected correctly to a grounded AC outlet that is supplying power. If you use a surge protector, make sure that it is turned on. • If a peripheral device, such as a keyboard or mouse, does not appear to work, make sure that all cables are plugged in securely.
CHAPTER 9: Troubleshooting 116
APPENDIX A Legal Information • • • • Important safety information Regulatory compliance statements Environmental information Notices 117
APPENDIX A: Legal Information Important safety information Warning Always follow these instructions to help guard against personal injury and damage to your Gateway system. Warning Do not use Gateway products in areas classified as hazardous locations. Such areas include patient care areas of medical and dental facilities, oxygen-laden environments, or industrial facilities. Warning To reduce the risk of fire, use only No. 26 AWG or larger (for example, No.
www.gateway.com • • When the notebook is turned off, a small amount of electrical current still flows through the notebook. To avoid electrical shock, always unplug all power cables and modem cables from the wall outlets before cleaning the notebook. Unplug the notebook from the wall outlet and refer servicing to qualified personnel if: • The power cord or plug is damaged. • Liquid has been spilled into the notebook. • The notebook does not operate properly when the operating instructions are followed.
APPENDIX A: Legal Information Additional limitations, cautions, and concerns for specific countries are listed in the specific country sections (or country group sections). The wireless devices in your system are only qualified for use in the countries identified by the Radio Approval Marks on the system rating label. If the country you will be using the wireless device in, is not listed, please contact your local Radio Approval agency for requirements.
www.gateway.com The FCC has set a general guideline of 8 inches (20 cm) separation between the device and the body, for use of a wireless device near the body (this does not include extremities). This device should be used more than 8 inches (20 cm) from the body when wireless devices are on. The power output of the wireless device (or devices), which may be embedded in your notebook, is well below the RF exposure limits as set by the FCC.
APPENDIX A: Legal Information California Proposition 65 Warning Warning This product contains chemicals, including lead, known to the State of California to cause cancer, birth defects or reproductive harm. Mercury Warning Hg Warning The lamp in this display contains mercury. Do not put in trash.
www.gateway.com Canada Industry Canada (IC) Intentional emitter per RSS 210 Caution To prevent radio interference to licensed service or co-channel Mobile Satellite systems, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Low power, Radio transmitter type devices (radio frequency (RF) wireless communication devices), operating in the 2.4 GHz band and/or 5.15 – 5.
APPENDIX A: Legal Information Telecommunications per Industry Canada CS-03 (for products fitted with an IC-compliant modem) The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operation, and safety requirements. The Department does not guarantee the equipment will operate to the users’ satisfaction.
www.gateway.com Laser safety statement Warning Use of controls or adjustments or performance of procedures other than those specified in this manual may result in hazardous radiation exposure. To prevent exposure to laser beams, do not try to open the enclosure of a CD or DVD drive. All Gateway systems equipped with CD and DVD drives comply with the appropriate safety standards, including IEC 825.
APPENDIX A: Legal Information Notices Copyright © 2007 Gateway, Inc. All Rights Reserved 7565 Irvine Center Drive Irvine, CA 92618 USA All Rights Reserved This publication is protected by copyright and all rights are reserved. No part of it may be reproduced or transmitted by any means or in any form, without prior consent in writing from Gateway. The information in this manual has been carefully checked and is believed to be accurate. However, changes are made periodically.
Index A AC adapter connecting 16 connector 7 international adapters 52 accessories purchasing 44 safety precautions 119 acoustic handset coupler 58 airplane power adapters 44 application key 25 arrow keys 25 audio adjusting volume 27, 31 headphone jack 9 microphone jack 9 muting 27, 31 troubleshooting 113 volume down button 27 volume up button 27 audio CD cleaning 68 automobile power adapter 52 automobile power adapters 44 B battery alternate power sources 52 bay 49 changing 49 charge indicator 6, 24, 48 c
Index Authenticity 3 cleaning audio CD 68 case 65 CD 68 DVD 68 keyboard 66 LCD panel 66 notebook exterior 65 screen 66 clicking 29 closing unresponsive program 22 connecting AC adapter 16 dial-up modem 18 external keyboard 24 external monitor 41 keyboard 24 mouse 28 printer 39 projector 41 scanner 39 to cable modem 19 to DSL modem 19 to Ethernet 19 to network 19 video camera 40 connections audio 9 broadband Internet 9, 19 cable modem 9, 19 dial-up modem 9, 18 digital camera 9 digital video camera 9, 39 do
www.gateway.com troubleshooting 102 DVD cleaning 68 troubleshooting 93 DVD drive 9, 39 troubleshooting 93 purchasing 44 replacing 86 troubleshooting 96 headphone jack 9 Hibernate mode 52 hot-swapping 37, 39 Hybrid Sleep E mode 26, 53 system key 26 electrostatic discharge (ESD) 82 turning on 56 EmPower power adapter 52 ergonomics 14 I Ethernet i.Link port 9, 39 connecting 19 jack 9, 19 IEEE 1394 port 9, 39 external monitor 7, 26 IEEE 802.
Index connecting 24 features 24 locating 12 troubleshooting 98 USB port 9 keys application 25 arrow 25 battery status 26 brightness 27 directional 25 Fn 25, 26 function 25 Hybrid Sleep 26 LCD brightness 27 LCD/CRT 26 navigation 25 numeric keypad 25 power status 26 Sleep 26 Status 26 system 25 system key combinations 26 toggle display 26 Windows 25 L labels Microsoft Certificate of Authenticity 3 model number 3 serial number 3 laser printer 45 latch battery 10 LCD panel cleaning 66 switching display 26 tr
www.gateway.
Index installing 39 laser 45 troubleshooting 112 USB port 9 programs closing unresponsive 22 opening 29 projector adding 41 color quality 42 port 7 screen resolution 42 using 26 R radio approval authorities 59 radio frequency wireless connections 59 RAM See memory rebooting notebook 22 recalibrating battery 50 recharging battery 48 recovering drivers 69 software 69 system 68, 79 replacing See installing resetting notebook 22 restarting notebook 22 right-clicking 29 S safety avoiding repetitive strain 15
www.gateway.
Index V VGA port 7, 41 video monitor port 7 projector port 7 troubleshooting 114 VGA port 7 video camera connecting 40 volume adjusting 27, 31 adjusting modem 106 controls 31 muting 27, 31 system keys 27 troubleshooting 113 W waking up notebook 21 Windows key 25 Product Key Code 3 wired Ethernet troubleshooting 107 wireless Ethernet using while traveling 59 wireless network button 26 turning off 32 turning on 32 working safely 14 134
