6 - 36 PANELWARE MMI Application Manual for GE Fanuc Genius Protocol - June 1995 GFK-1115
6
4. Insert the input fields for minutes (MM:), seconds (SS:), month (MM:), Day (DD:), and Year
(YYYY:) into the picture. Use the input field Input Bit/Byte, for all but the Year field, which
must be Input Word Unsigned. Basically these fields are inserted the same as the input field
for hours. The table below shows the field parameters and the scaling parameters for each of
the input fields:
Field No.
(see figure on page 6-37) Field or Scaling parameters
0 HH (Hours)
Field parameters:
Position: 4,1
Number of Digits: 2
Places after dec. point: 0
Character size: 1
Field size: 3
Destination Tagname: TIME_HH_S/DI
Tagname for Completion:
Value for Completion: 0
Up/Down Input? (Y/N): No
Locking Active? (Y/N): No
Scaling? (Y/N): Yes
Scaling parameters:
0% Value in the PLC: 0
100% Value in the PLC: 23
Minimum Value on Panel: 0
Maximum Value on Panel: 23
1 MM (Minutes)
Field parameters:
Position: 12,1
Destination Tagname: TIME_MM_S/DI
Remaining Parameters Identical to field 0
Scaling parameters:
0% Value in the PLC: 0
100% Value in the PLC: 59
Minimum Value on Panel: 0
Maximum Value on Panel: 59
2 SS (Seconds)
Field parameters:
Position: 20,1
Destination Tagname: TIME_SS_S/DI
Remaining Parameters Identical to field 0
Scaling parameters:
0% Value in the PLC: 0
100% Value in the PLC: 59
Minimum Value on Panel: 0
Maximum Value on Panel: 59
3 MM (Month)
Field parameters:
Position: 4,3
Destination Tagname: DATE_MM_S/DI
Remaining Parameters Identical to field 0
Scaling parameters:
0% Value in the PLC: 1
100% Value in the PLC: 12
Minimum Value on Panel: 1
Maximum Value on Panel: 12
4 DD (Day)
Field parameters:
Position: 12,3
Destination Tagname: DATE_DD_S/DI
Remaining Parameters Identical to field 0
Scaling parameters:
0% Value in the PLC: 1
100% Value in the PLC: 31
Minimum Value on Panel: 1
Maximum Value on Panel: 31
