Specification

For answers to your Monogram
®
or GE appliance
questions, visit our website at geappliances.com
or call GE Answer Center
®
service, 800.626.2000.
Listed by
Underwriters
Laboratories
To insure accuracy, it is best to make a
template when cutting the opening in the counter
Electrical junction box 16" MIN.
below countertop
Cooktop
36"
21-3/8"
18-7/8"
33-3/4"
19-1/8" to
19-1/4"
33-7/8"
to 34"
CP9536SJ, PP9036DJ, PP7036EJ,
PP7036DJ, JP5036DJ
2-1/2" MIN.
Required
1-3/4" MIN.
to rear wall
13" MAX. depth of unprotected
overhead cabinets (when no
hood or microwave is installed)
15" MIN. height from countertop
to nearest cabinet (including
light rails) on both sides of
cooktop
3-1/4" at front of unit and
6" at conduit location
30" MIN. from countertop to
unprotected cabinet (when
no hood or microwave is
installed)
2" MIN. clearance
to side wall from cut-out
on both sides of cooktop
See label next
to nameplate for
MIN. clearance
to wall
Important: Requires a 5" free area between
the bottom of the cooktop to any combustible
material, i.e., shelving. Free area not required
when installing wall oven underneath cooktop.
Refer to installation instructions. Requires a 15"
minimum from cooktop to adjacent overhead
cabinets. Units are furnished with a 48" flexible
armored cable.
Note: 36" Ribbon cooktops are approved for use
over select GE 30" Single Wall Ovens and Warming
Drawers. Refer to cooktop and wall oven/warming
drawer installation instructions packed with
product for current dimensional data. If installed
with a GE Telescopic Downdraft System, consult
both the cooktop and downdraft installation
instructions packed with product before installing.
Cooktop gas/electric supply may need to be
re-routed to install downdraft. The countertop
cutout requires 23-1/2" minimum flat countertop
surface and 25" minimum total countertop depth.
In addition, other clearances to front edge of the
countertop must be considered.
Before installing, consult installation
instructions packed with product for
current dimensional data.
Dimensions and Installation Information (in inches)
PP7036DJ
GE Profile
™
Series 36" Built-In Knob Control Cooktop
KW Rating
240V
9.6
208V
8.3
Amperage
240V
40 Amps
†
208V
40 Amps
†
Specification Created 1/15
†
Note: Check local codes for
required breaker size
Approximate Cooking Dimensions
