GEH-6385 Reference and Troubleshooting, 2300 V Drives Chapter 4 Wizards
•
••
•
4-7
The following are descriptions of error messages.
Error Message Description/Procedure
Cell Test invoked in
simulator mode.
The simulator mode variable Simulate mode act is
TRUE. The Fiber-Optic Test cannot be run in simulator
mode. Change the simulator mode by setting request
parameter Simulate mode to FALSE and run the Fiber-
Optic Test again.
Cell Test did not run to
completion. Cell Test
request was removed.
The Cell Test command was removed during Cell Test.
The user may have aborted the test.
Cell Test did not run to
completion. Internal Cell
Test fault detected.
A drive trip fault occurred during the Fiber-Optic Test.
Correct and clear any existing trip faults and run the
Fiber-Optic Test again.
Fiber-Optic Test
interrupted.
The Fiber-Optic Test could not be run due to one of the
following reasons:
Voltage was detected on the DC bus.
The static charger was not in an idle state.
A drive trip fault was detected.
Correct and clear any existing drive trip faults. Press the
“SWITCHGEAR OPEN” button on the drive cabinet door.
Wait for the dc bus voltage to completely discharge. Run
the Fiber-Optic Test again.
Fiber-Optic Test did not
run. Fiber-Optic Test
cannot be run with
switchgear closed.
Press the “SWITCHGEAR OPEN” button on the drive.
Wait for the DC bus voltage to completely discharge.
Run the Fiber-Optic Test again.
