5-6
•
••
•
Chapter 5 Signal Mapping Innovation Series Medium Voltage GP Type - G Drives GEH-6385
Application of Feedback Signals
In most control systems the LAN (Genius, Profibus-DP, and such) operates
asynchronous with the execution of control logic. Two situations can occur:
• Under Sampling - If the control logic sweep rate is slower than the LAN sweep
rate, certain samples of feedback signals from the drive are not seen by the
control logic.
• Over Sampling - If the control logic sweep rate is faster than the LAN sweep
rate, certain feedback signal samples from the drive are seen multiple times by
the control logic.
To address the under sampling problem, signal conditioning is provided for
dedicated analog feedback channels in the form of sequential averaging. Feedback
signals are comprised of a series of short-term averages of the source signal. The
parameter LAN fbk avg time configures the averaging period; updates to the feedback
signal map are performed coherently.
Note that when an integer relationship exists between LAN frame time and LAN fbk
avg time, then the frame and feedback averaging periods are synchronized to the
extent possible. This synchronization is optimal for synchronous LAN interfaces,
such as those provided by the ISBus.
Variable Maps
This section defines the signal maps for the ACMVAC4-G (General Industries)
pattern. The following tables provide:
• Standard 32-bit SPFP maps
• 20-character user names and 12-character symbolic names
• Units or scale groups (as appropriate)
