3-36 •
••
• Chapter 3 Paramters/Functions Innovation Series Medium Voltage GP Type - G Drives GEH-6385
Configuration parameters
The following table specifies the configuration parameters of the LAN Configuration
and Health function.
Parameter Description
Network interface Network interface type. Specifies one of the following
interface types:
No interface
ACL dual port memory
ISBus
DRIVENET - Other optional LAN modules such as
Genius and Profibus
LAN frame time
Expected communication frame period. Allowed frame
periods are 1, 2, 4, and 8 milliseconds.
LAN fbk avg time Period over which feedback signals are sequentially
averaged. The LAN Signal Map help topic describes
which feedback signals are averaged. If LAN fbk avg
time is zero, no averaging occurs.
LAN cmds inhibit
Disables LAN references, forcing the signal interface to
operate in feedback-only mode. Local images of
reference signals are set to zero (0.0) or False.
LAN trips inhibit Disables LAN heartbeat trip fault (LAN heartbeat trip),
and enable the corresponding alarm (LAN heartbeat
alarm).
LAN heartbeat time Period within which transition must be detected in the
LAN heartbeat signal (Heartbeat ref, lan) to satisfy the
local heartbeat timeout check.
Sys ISBus node #
ISBus node for the Innovation Series Drive device. Each
device on the ISBus bus should be assigned a unique
node between 1 and 31.
LAN parameter 1
through LAN
parameter 16
These parameters are used only by optional LAN
modules and are specific to those modules. Such items
as baud rate and device number are configured via these
parameters. Please see the documentation for the
specific LAN module for detailed information.
