3-40
•
••
•
Chapter 3 Paramters/Functions Innovation Series Medium Voltage GP Type - G Drives GEH-6385
The following table specifies the LAN Signal Map request bits that appear in Page 1,
Element 1 of the reference signal map.
Bit Signal Description
0 Heartbeat ref,
lan
Heartbeat signal to validate LAN health.
1 Fault reset req,
lan
Request to reset drive faults. Functionality is always
enabled.
2 Trip request,
lan
Request to trip the drive. Functionality is always
enabled.
3 Alarm request,
lan
Request to declare an alarm in the drive. Functionality
is always enabled.
4-7 Unused
8
Run request,
lan
Request to run the drive. Functionality is always
enabled.
9 Jog request,
lan
Request to jog the drive. Functionality is always
enabled.
10 X stop request,
lan
Request to perform an X stop in the drive.
Functionality is always enabled.
11 Full flux req, lan Request to flux the drive. Functionality is always
enabled.
12 Rev mode req,
lan
Request to reverse the direction of rotation that can be
used in the Speed Reference Generation function.
13 Torque mode
req, lan
Request to enable torque mode that can be used in the
Speed/Torque Regulator function.
14 Droop disab
req, lan
Request to inhibit droop functionality that can be used
in the Droop function.
15 Trq lim 2 sel,
lan
Request to choose between torque limits that can be
used in the Motor Control Interface function.
16 Ramp rate 2
sel, lan
Request to choose between ramp rates that can be
used in the Speed Reference Ramp function.
17 Unused
18
Auto mode req,
lan
Request to enable auto reference mode that can be
used in the Speed Reference Generation function.
19-23 Unused
24 GP lan req bit 1 General purpose request that can be used by a number
of functions.
25 GP lan req bit 2 General purpose request that can be used by a number
of functions.
26 GP lan req bit 3 General purpose request that can be used by a number
of functions.
27 GP lan req bit 4 General purpose request that can be used by a number
of functions.
28 GP lan req bit 5 General purpose request that can be used by a number
of functions.
29 GP lan req bit 6
General purpose request that can be used by a number
of functions.
30 GP lan req bit 7
General purpose request that can be used by a number
of functions.
31 GP lan req bit 8
General purpose request that can be used by a number
of functions.
