Spec Sheet

Listed by
Underwriters
Laboratories
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
JB645DK
GE
®
Series 30" Free-Standing Electric Range
Specification Created 12/15
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
For answers to your Monogram, GE Café
™
Series,
GE Profile
™
Series or GE
®
Series appliance questions,
visit our website at geappliances.com or call
GE Answer Center
®
service, 800.626.2000.
RECEPTACLE LOCATIONS
Locally approved flexible service cord or conduit must
be used because terminals are not accessible after range
installation. See shaded area in drawing for location of
electrical outlet box. Recommended outlet locations allow
range to be installed directly against wall.
NOTE: This appliance has been approved for 0” spacing
to adjacent surfaces above the cooktop. However, a 6”
minimum spacing to surfaces less than 15” above the
cooktop and adjacent cabinet is recommended to reduce
exposure to steam, grease splatter and heat.
INSTALLATION INFORMATION: Before installing,
consult installation instructions for current dimensional
data and additional requirements.
†NOTE: Check local codes for required breaker size.
KW RATING
240V 12.1
208V 9.1
BREAKER SIZE
240V 40 Amps†
208V 40 Amps†
30"
25"
2-1/2"
2-1/2"
7-1/2"
29-7/8"
47"
11"
35-3/4"
to
36-1/2"
w/o handle
w/handle
47-5/8"
28"
25-3/8"
ACCEPTABLE ELECTRICAL
OUTLET AREA
30
" FREE-STANDING ELECTRIC
SINGLE OVEN
