Washers www.GEAppliances.com Safety Instructions . . . . . . . . .2, 3 Operating Instructions Control Panels . . . . . . . . . . . .4–6 Control Settings . . . . . . . . . . .7, 8 Features . . . . . . . . . . . . . . . . .9, 10 Loading and Using the Washer . . . . . . . . . . . . . 10, 11 Troubleshooting Tips . . . . .12–14 Consumer Support Consumer Support . . .Back Cover Warranty . . . . . . . . . . . . . . . . . .
Safety Instructions IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury, or loss of life. WATER HEATER SAFETY Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or more. Hydrogen gas can be explosive under these circumstances.
www.GEAppliances.com ■ Never reach into washer while it is moving. Wait until the machine has completely stopped before opening the lid. Use this appliance only for its intended purpose as described in this Owner’s Manual. ■ Do not mix chlorine bleach with ammonia or acids such as vinegar and/or rust remover. Mixing different chemicals can produce a toxic gas which may cause death.
About the washer control panel. • Select load size and other wash options • Add clothes • Select wash cycle • Close lid • Add detergent • Add diluted fabric softener (on models with a fabric softener dispenser) • Push START Quick Start Guide NOTE: When making a selection with any knob, simply point the knob anywhere within the shaded range for that setting.
www.GEAppliances.
About the washer control panel.
About the control settings. www.GEAppliances.com Safety Instructions Color Logic (on some models) Select the correct TEMPERATURE setting. Match the particular color below the words with the same color on the WASH/SPIN SPEED setting. Next, match the color again with the same color on the Cycle Selector knob. Example: Washing a load of medium-soiled cotton towels and sheets. 1 2 3 4 Choose the LOAD SIZE. Choose the TEMPERATURE setting—for this load it would be the HOT COLD (which is a particular color).
Safety Instructions About the control settings. Temperature Select the water temperature for the wash and rinse cycles. Always follow fabric manufacturer’s care label or instructions when laundering. Wash Cycle The wash cycle controls the length of the washing process. The knob can be turned in either direction. Turning the Cycle Selector knob after starting a cycle will stop the washer and reset the cycle to the new selection. Press START to begin the new cycle selection.
About washer features. www.GEAppliances.com Safety Instructions 2nd Rinse Option (on some models) When you use extra detergent or bleach to clean heavily soiled clothes, you may want to use the 2nd Rinse option. It provides a second deep cold rinse. Extended Spin Option (on some models) Use this option to extract more water from your clothes. Clothes will be drier when this option is selected and will dry more quickly in your dryer.
Safety Instructions About washer features. The Agitator Cap or Fabric Softener Dispenser (depending on model) The agitator cap fits into the top of the agitator. If it accidentally comes off, simply put it back on. 3 Add water to dispenser until it reaches the maximum fill line. The fabric softener dispenser automatically releases liquid fabric softener at the proper time during the cycle. Do not stop the washer during the first spin. This will cause the dispenser to empty too soon.
www.GEAppliances.com Wash Basket: Leave the lid open after washing to allow moisture to evaporate. If you want to clean the basket, use a clean soft cloth dampened with liquid detergent, then rinse. (Do not use harsh or gritty cleaners.) Fill Hoses: Hoses connecting washer to faucet should be replaced every 5 years. Lint Filter: The lint filter is located under the agitator. It is self-cleaning and requires no maintenance.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Before you call for service… Troubleshooting Tips Save time and money! Review the charts on the following pages, or visit www.GEAppliances.com. You may not need to call for service. AUTOTEMP Possible Causes What To Do AutoTemp cold wash temperature is incorrect The washer is in a cold rinse cycle • This is normal.
www.GEAppliances.com What To Do Washer pauses in cycle The DELICATES or CASUALS cycle was chosen • This is normal. The washer alternates between agitate and soak during the DELICATES and CASUALS cycles to get your clothes cleaner with less wear. Washer won’t operate Washer is unplugged • Make sure cord is plugged securely into a working outlet. Water supply is turned off • Turn both hot and cold faucets fully on. Controls are not set properly • Check controls.
Consumer Support Troubleshooting Tips Operating Instructions Safety Instructions Before you call for service… PERFORMANCE (cont.) Possible Causes What To Do Pilling Result of normal wear on poly-cotton blends and fuzzy fabrics • While this is not caused by the washer, you can slow the pilling process by washing garments inside out.
GE Washer Warranty. (For customers in the United States) Staple your receipt here. Proof of the original purchase date is needed to obtain service under the warranty. For The Period Of: We Will Replace: Any part of the washer which fails due to a defect in materials or workmanship. During this full one-year warranty, GE will also provide, free of charge, all labor and related service costs to replace the defective part.
Consumer Support. GE Appliances Website GEAppliances.com Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals, order parts, catalogs, or even schedule service on-line. You can also “Ask Our Team of Experts™” your questions, and so much more... Schedule Service GEAppliances.com Expert GE repair service is only one step away from your door.
