Instruction Manual

monogram.com
35
Professional gas rangetops
Induction cooktopsElectric cooktops Gas cooktops
36" stainless steel
gas cooktop
ZGU385NSMSS (natural gas)
ZGU385LSMSS (liquid propane)
Overall dimensions
(WxHxD in inches):
36-3/4 x 3-3/4 x 21-3/16
Amps @120VAC 5.0
Approx. shipping wt. (lbs.) 68
• Approved installation over
any Monogram single wall
oven or warming drawer
• Natural or LP gas must be
specified by model number
ZGU385NSMSS
ZGU385LSMSS
HI
LO
LITE
OFF
SIM
HI
LO
LITE
OFF
SIM
HI
LO
LITE
OFF
SIM
HI
LO
LITE
OFF
SIM
X-HI
LO
LITE
OFF
SIM
USE WITH
LARGER
POTS
36" gas-on-glass
cooktop
ZGU36KSKSS
Overall dimensions
(WxHxD in inches):
36 x 3-1/16 x 21-7/16—SS
36 x 3-1/16 x 21-1/4—BB
Amps @120VAC 5.0
Approx. shipping wt. (lbs.) 59
• Approved installation over wall
oven or warming drawer
• LP gas conversion kit included
HILO
OFF
LITE
HILO
OFF
LITE
HILO
OFF
LITE
HILO
OFF
LITE
HILO
OFF
LITE
ZGU36KWKWW
Stainless steel gas cooktop
general features
Sophisticated design. Angled and hand-finished to perfection, a
Monogram
®
stainless steel gas cooktop brings an incomparable
mix of edge and elegance to the kitchen.
Dual-flame, stacked burners. Simmer-to-boil flexibility on all
burners delivers exceptional performance and convenience. The
burners are sealed to the cooktop for easy cleaning.
High-output cooking power. Intense heat ideal for searing and
boiling is delivered by an 18,000-BTU* burner, featured on both
36" and 30" cooktops. The 36" model provides a total of 62,000
BTUs,* and the 30" model offers 50,000 BTUs.*
Silent, precise simmering. The simmer flame delivers
a consistent 140°F temperature, without cycling on and off.
No simmer plate required.
Electronic ignition with auto reignition. Instant ignition system
ensures a continuous flame and reignites automatically if
accidentally extinguished.
Hand-machined, stainless steel knob controls. A red indicator
light embedded in each knob makes it easy to view and select
heat settings. Knob controls rotate with smooth precision.
Interlocking, continuous grates. The continuous-grate design
creates a steady surface for cookware, and grates are integrated
into the cooktop for a clean, finished appearance.
Gas-on-glass cooktop general features
Sophisticated styling.
The front edge is slightly curved to
form an attractive, soft arc that complements other Monogram
appliances.
Precise, versatile temperature control. Five burners provide
a range of heat intensities: one 15,000-BTU* burner, one 11,000-
BTU* burner, one 9100-BTU* burner and two 6000-BTU* burners.
Continuous grate design. Heavy pots are easy to slide from
burner to burner.
Soft-touch control knobs. Tactile knobs are pleasing to
the touch and are dishwasher safe.
For additional details on product installation, warranty coverage,
care and maintenance, visit monogram.com.
Gas cooktops
30" stainless steel
gas cooktop
ZGU384NSMSS (natural gas)
ZGU384LSMSS (liquid propane)
Overall dimensions
(WxHxD in inches):
30-3/4 x 3-3/4 x 21-5/8
Amps @120VAC 5.0
Approx. shipping wt. (lbs.) 55
• Approved installation over
any Monogram single wall
oven or warming drawer
• Natural or LP gas must be
specified by model number
HI
LO
LITE
OFF
SIM
ZGU384LSMSS
ZGU384NSMSS
X-HI
LO
LITE
OFF
SIM
HI
LO
LITE
OFF
SIM
HI
LO
LITE
OFF
SIM
USE WITH
LARGER
POTS
*Natural gas
