Installation & Conguration
Setup Guide
5. After the Matrix Controller has completed the initialization process, the following
message will appear in the LCM display on the front panel:
The Matrix Controller will prompt for the passcode. Ignore this for now and continue
to the next step. Most of the system setup will be done through the Web interface.
The front panel is covered in the User Manual.
6. Connect a computer to the same network as the Matrix Controller. Set the computer’s
IP address to 192.168.1.xxx, where xxx is a value between 1 and 254.
7. Set the subnet mask to 255.255.255.0.
8. Open a Web browser and enter the following address: 192.168.1.74.
9. The login page to the Matrix Controller will be displayed.
10. Type admin (case-sensitive) in both the Username and Password elds, then click
the Login button.
ENTER PASSCODE:
_00000
Important
Do not use the IP address 192.168.1.74 because this is the IP address of the
Matrix Controller. If the current network conguration is already within this
range, make sure that the IP address 192.168.1.74 is not assigned to another
device in order to avoid conicts.
