User manual

INTRODUCTION
7
Top / Front / Back
1 PowerIndicator
ThisLEDindicatorwillglowbrightbluewhenthematrixispoweredandtheELR-POL
ReceiverunitisconnectedtothematrixusingCAT-5e(orbetter)cable.
2 HDMIOut
ConnectanHDTVdisplaytotheHDMIOutportusinganHDMIcable.
3 HDMILockingConnector
UsedtolocktheHDMIcableinplace.
4 IROut
ConnectanIREmitter(Gefenpartno.EXT-IREMIT)cablefromthisjacktotheHDTV
display.
5 IRExt
ConnectanIRExtender(Gefenpartno.EXT-RMT-EXTIRC)cabletothisjack.





6 ELR-POLIn
ConnectaCAT-5e(orbetter)cablefromthisjacktooneoftheELR-POLjacksonthe4x4
Matrix for HDMI w/4 ELR-POL Outputs.
WARNING:Do notconnecttheGefenPACSorMiniPACStotheIR
ExtjackontheELR-POLReceiverunit.Doingsowillcausefatal
damagetothepowersupplyforthePACS/MiniPACS.
