How to Connect the 4x4 Matrix for HDMI w/4 ELR-POL Outputs
1. ConnectuptofourHi-Defsourcestothe4x4 Matrix for HDMI w/4 ELR-POL Outputs
usingHDMIcables.
2. ConnectuptofourHDTVdisplaystothesuppliedELR-POLReceiverunitsusing
HDMIcables.
3. ConnecteachELR-POLReceiverunittothe4x4 Matrix for HDMI w/4 ELR-POL
OutputsusingCAT-5e(orbetter)cables.






4. IRControl:FordetailsonusingtheBi-directionalIRfeatureonthematrix,seepage
24.
5. ConnecttheACpowercordtothematrixandconnecttheplugtoanavailable
electricaloutlet.

Wiring Diagram
GEF-HDFST-444-4ELR
HD Displays
HDMI CABLE
4x
Hi-Def Sources
4x
Matrix
RS-232 CABLE
EXT-PACS
CAT-5 CABLE
IP Control
Network
4x
IR Extenders
4x
Receivers
®
IR EMITTER
4x
IR Emitters
IR EXTENDER
4x
IR Emitters
X
close
NOTE:Whenconnectedtothematrix,eachELR-POLReceiver
unitispoweredovertheCAT-5ecable.Noexternalpower
suppliesarerequiredfortheELR-POLReceiverunits.
CONNECTING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
