Determining the Current Routing State
Intheexamplebelow,therstrow(OUT)representseachHDMIoutputonthematrix.
Thebottomrow(IN)representseachHDMIinputonthematrix.Together,thesetworows
displaythecurrentroutingstate.
Startingonthebottomrow,wecanseethatInput3hasbeenroutedtoOutput1,Input2
hasbeenroutedtoOutput2,Input1hasbeenroutedtoOutput3,andInput4hasbeen
routedtoOutput4.








Ifallinputsareroutedtotheirrespectiveoutputs,thefront-paneldisplaywillappearas
follows:












Thisisreferredtoasa“1-to-1”routingstate.Thisisthefactory(default)settingforthe
4x4 Matrix for HDMI w/4 ELR-POL.
OPERATING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
12
OUT:1234
IN:3214
OUT:1234
IN:1234
