User manual

3. ConsecutivelypressingtheOut -buttonwillcyclethrougheachoutput,
fromrighttoleft.


















Changing the Source
4. Oncethedesiredoutputhasbeenselected,presstheInput +orInput -button.
ConsecutivelypressingtheInput +buttonwillincrementtheinputvaluebyafactor
of1(withinarangeof1-4).Forexample,ifInput1wasoriginallyroutedto
Output3,thenpressingtheInput +buttonwillrouteInput2toOutput3.

NotethatifthemaximumInputvalue(4)isreached,thenpressingtheInput +button
willsettheInputto1.Conversely,iftheminimumInputvalue(1)isreached,then
pressingtheInput -buttonwillsettheInputto4.
OPERATING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
14
OUT: 4
IN: 4
OUT: 3
IN: 2
Sourcechangedfrom
Input1toInput2.
