5. ConsecutivelypressingtheInput -buttonwilldecreasetheinputvaluebyafactorof

1(withinarangeof1-4).Forexample,ifInput4wasoriginallyroutedtoOutput4,

pressingtheInput -buttonwillrouteInput3toOutput4.



Tochangetheroutingstatusofanotheroutput,presstheOutput +orOutput -

buttonstoselectthedesiredoutput.UsetheInput +orInput -buttonstochange

thesource.

6. PresstheMenubuttontoreturntotheRoutingScreen.Theupdatedroutingstatus

willbedisplayed.



OPERATING THE

4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS

NOTE:IftheMenubuttonisnotpressedafteraroutingchange

hasbeenmade,thenthe4x4 Matrix for HDMI w/4 ELR-POL

willautomaticallyreturntotheRoutingScreenafterabout20

seconds.

OUT: 4

IN: 3

Sourcechangedfrom

Input4toInput3.

OUT:1234

IN:3223
