OPERATING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
3. PresstheOutput -orOutput +buttonagaintocyclethroughtheroutingstatefor
eachoutput.ConsecutivelypressingtheOutput +buttonwillcyclethrougheach
input,fromlefttoright,startingwithInput1:
























4. ConsecutivelypressingtheOutput -buttonwillcyclethrougheachoutput,fromright
toleft:
NOTE:InRoutingmode,theOutput +andOutput -buttonscycle
througheachoutput.InSwitchingmode,thesesamebuttonsare
usedtocyclethrougheachinput.
19
IN: 3
MODE: F
IN: 2
MODE: S
