Changing the Switching Mode

5. Oncethedesiredinputhasbeenselected,presstheInput +orInput -buttonto

togglebetweenFastorSlowswitchingmode.



Tochangetheswitchingmodeofanotherinput,presstheOutput +orOutput -

buttontonavigatetothedesiredinput.PresstheInput +orInput -button

totoggletheswitchingmodebetweenFast(F)orSlow(S).

6. PresstheMenubuttontoreturntotheSwitchingmodeScreen.



PresstheMenubuttonasecondtimetoreturntotheRoutingscreen.

OPERATING THE

4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS

IN: 2

MODE: F

Switchingmode

changedfromSlowto

FastonInput2.

IN:1234

MODE:FFFF
