Routing Sources using the IR Remote Control
TheincludedIRRemoteControlunitprovidesdiscreteswitchingforeachoutput.TheIR
remotecontrolunitconsistsof16buttons.Buttonsarecolor-codedandarrangedingroupsof
four.Thereareatotaloffouroutputsonthematrix.TherstsetofbuttonsontheIRremote
representOutput1.ThesecondsetoffourbuttonsrepresentOutput2,andsoon.Each
individualbuttonwithinagroup,representsaninput.
Example 1: Route Input 4 to Output 1
• TherstgroupofbuttonsrepresentOutput1.Therefore,weneedtoselectInput4by
pressingbutton4intherstgroupofbuttons.Input4isnowroutedtoOutput1.


















Example 2: Route Input 1 to Output 2
• ThesecondgroupofbuttonsrepresentOutput2.Therefore,weneedtoselect
Input1bypressingbutton1inthesecondgroupofbuttons.Input1isnowrouted
toOutput2,asindicatedonthefront-panelLCM:



OPERATING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
23
OUT:1234
IN:4234
LEDindicatesa
buttonwaspressed
Input4selected
OUT:1234
IN:4134
Input1selected
