3. Refertopage10andmakesureallremainingconnectionsaremadebetweenthematrix
andallsourceanddisplaydevices.
Controlling the Source from the viewing location
Pointthesource’sIRremotecontrolattheIRExtender.Theillustrationbelowshowshow
thesource,connectedtoHDMI In 1,iscontrolledfromtheReceiverunit(viewinglocation).
IRsignalsaretransmittedovertheCAT-5cabletothematrix.
OPERATING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
25
SAT
DVD
TV
?
1
2
3
4
5
6
7
8
9
0
_
IRsignals
SourceIRremote
CAT-5
IRExtender
IREmitter
HDMIcable
up to 330 feet
(100 meters)
ReceiverunitMatrix
Source
