IR Broadcasting to Displays
InadditiontosendingIRcommandstoasingledisplay,the4x4 Matrix for HDMI w/ 4 ELR-
POL OutputsalsoallowsIRcommandstobebroadcasttoalldisplaysdevices.
1. Connecta3.5mm-to-3.5mmmini-monocablefromoneoftheIREmitteroutputsonthe
GefenPACStotheIRInAllportonthematrix.

IREmitter
Source
HDMIcable
ToReceiverunit
Tolocalnetwork
GefenPACSMatrix
x4
CAT-5
31
OPERATING THE
4X4 MATRIX FOR HDMI W/ 4 ELR-POL OUTPUTS
