User manual

34
RS-232 / IP CONTROL
RS-232 Interface
OnlyTXD,RXD,andGNDareused.
RS232 Settings
Baudrate.......................................................................................................................19200
Databits...............................................................................................................................8
Paritybits.......................................................................................................................None
Stopbits................................................................................................................................1
FlowControl...................................................................................................................None
IMPORTANT: WhensendingRS-232commands,acarriagereturn
mustbeincludedattheendofthecommand.Aspacemustbe
includedbetweenthecommandandtheparameter.
DA-15
DE-9
DB-25
DC-37
DD-50
5
6
4
7
3
8
2
9
1
DCD
RXD
TXD
DTR
GND
DSR
RTS
CTS
R1
DCD
RXD
TXD
DTR
GND
DSR
RTS
CTS
R1
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
RS-232Controller Matrix
