RS-232 / IP CONTROL
Conguring the IP Address

The4x4 Crosspoint Matrix for HDMIsupportsIP-basedcontrolusingthebuilt-inWebGUI
andTelnetprotocol.TosetupTelnetcontrol,thenetworksettingsforthematrixmustbe
conguredviaRS-232.Thedefaultnetworksettingsforthematrixareasfollows:
IPAddress: 192.168.1.72
Subnet:  255.255.255.0
Gateway: 192.168.1.254
HTTPPort: 80
TelnetPort: 23
1. ConnectanRS-232cablefromthePCtothematrix.
2. Launchaterminalemulationprogram(e.g.HyperTerminal)andusethefollowing
settings:

BaudRate:  19200
DataBits:  8
Parity:  None
StopBits:  1
FlowControl:  None






3. SettheIPaddressforthematrixusingthe#sipaddcommand(seepage49for
details).
4. Setthesubnetmaskusingthe#snetmaskcommand(seepage50fordetails).
5. Setthegateway(router)IPaddressusingthe#sgatewaycommand(seepage44
fordetails).
6. SettheTelnetlisteningportusingthe#set_telnet_portcommand(seepage41
fordetails).
7. SettheHTTPlisteningportusingthe#set_http_portcommand(seepage39for
details)
8. Power-cyclethematrixtorebootandcompleteallIPsettingchanges.
9. Afterthematrixhasrebooted,usetheIPaddressthatwasspeciedinstep3
toTelnettothematrix.
NOTE:Dependinguponthenetwork,theIPaddress,subnetmask,
gateway(router)IP,Telnetport,andHTTPportwillneedtobeset.
Consultyournetworkadministratortoobtainthepropersettings.
