60Hz, 4:2:0 HDBaseT™ Extender w/ 2-way IR and POH GTB-UHD-HBTL User Manual Release A1
Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this product near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install or place this product near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9.
Warranty Information Gefen/Core Brands, LLC warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen LLC is notified within the specified warranty period* from the documented** date of purchase, Gefen will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications.
Contacting Gefen Technical Support Technical Support (707) 283-5900 (800) 472-5555 8:00 AM to 5:00 PM Monday - Friday, Pacific Time Email support@gefen.com Web http://www.gefen.com Mailing Address Gefen Core Brands, LLC c/o Customer Service 1800 S McDowell Blvd Petaluma, CA 94954 USA Product Registration Register your product here: http://www.gefen.com/kvm/Registry/Registration.
Operating Notes • Gefen recommends using CAT-5e (or better) cables. • Resolution will affect extension distance. 1080p Full HD can be extended up to 230 feet (70 meters). 4K resolutions can be extended up to 130 feet (40 meters). See HDBT (HDBaseT™) Mode (page v) for details. • Power Over Line (POL) is a Gefen proprietary technology that provides power to the Receiver unit over a single CAT-5e (or better) cable. A power supply (1 pc included) can be connected to either the Sender or Receiver unit.
Features and Packing List Features • Extends 4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0 or @ 30Hz, 4:4:4) and Bi-Directional R over a single CAT-5e cable up to 130 feet/40 meters (8-bit color) • Extends 4K Cinema (DCI) (4096 x 2160 @ 24 or 30Hz 4:4:4), and Bi-Directional IR over a single CAT-5e cable up to 130 feet/40 meters (8-bit color) • Extends HDMI at 1080p Full HD and Bi-Directional IR over a single CAT-5e cable up to 230 feet/70 meters (up to 12-bit Deep Color) • HDMI Features Supported: ►► HDMI 2
Features and Packing List Packing List The following items are shipped with the 4K Ultra HD HDBaseT Extender w/ 2-way IR and POL. If any of these items are not present in the box when you first open it, immediately contact your dealer or Gefen. • • • • • • • 1 x 4K Ultra HD HDBaseT™ Extender w/ 2-way IR and POL - Sender unit (GTB-UHDHBTL-S) 1 x 4K Ultra HD HDBaseT™ Extender w/ 2-way IR and POL - Receiver unit (GTBUHD-HBTL-R) 1 x 6 ft.
Table of Contents 1 Getting Started Introduction............................................................................................................ 2 Sender Unit.................................................................................................... 2 Receiver Unit.................................................................................................. 4 Installation..............................................................................................................
This page left intentionally blank.
This page left intentionally blank.
60Hz, 4:2:0 HDBaseT™ Extender w/ 2-way IR and POH 1 Getting Started
Introduction Getting Started Sender Unit 1 2 3 GTB-UHD-HBTL-S GTB-UHD-HBTL-S GTB-UHD-HBTL-S Link IR In/Ext IR Out Link IR In/Ext IR Out Link IR In/Ext IR Out ® ® ® 4K Ultra HD 4K Ultra HD HDBaseT™ Extender S HDBaseT™ 4K Extender Ultra HDS w/ 2-way IR and POL w/ 2-way IR and POLS ™ Extender HDBaseT w/ 2-way IR and POL 4 5 6 24V DC Power Link Power HDMI In 24V DC 24V DC Link HDMI In Power Link HDMI In page | 2
Getting Started Introduction ID Name Description 1 Link Connect a CAT-5e cable (or better), up to 230 feet (70 meters), from this port to the Link port on the Receiver unit. 2 IR In/Ext 3.5mm mini-stereo jack. Connect an IR Extender (Gefen part no. EXT-RMT-EXTIRN) to this port. Alternatively, connect a 3.5mm mini-stereo connector from this port to the output of an automation system with an electrical IR output. See Bidirectional IR Control (page 11) for more information on using IR.
Introduction Getting Started Receiver Unit 1 2 3 GTB-UHD-HBTL-R GTB-UHD-HBTL-R GTB-UHD-HBTL-R Link IR In/Ext IR Out Link IR In/Ext IR Out Link IR In/Ext IR Out ® ® ® 4K Ultra HD 4K Ultra HD HDBaseT™ Extender R HDBaseT™ 4K Extender Ultra HDR w/ 2-way IR and POL w/ 2-way IR and POL ™ Extender HDBaseT R w/ 2-way IR and POL 4 5 6 24V DC Power Link Power HDMI Out 24V DC 24V DC Link HDMI Out Power Link HDMI Out page | 4
Getting Started Introduction ID Name Description 1 Link Connect a CAT-5e cable (or better), up to 230 feet (70 meters), from this port to the Link port on the Sender unit. 2 IR In/Ext 3.5mm mini-stereo jack. Connect an EXTRMT-EXTIRN IR Extender (1 pc included) to this port. Alternatively, connect a 3.5mm mini-stereo connector from this port to the output of an automation system with an electrical IR output. See Bidirectional IR Control (page 11) for more information on using IR.
Getting Started Installation Connection Instructions ►► Video 1. Connect the included HDMI cable between the Ultra Hi-Def source and the HDMI In port on the Sender unit. 2. Connect an Ultra HD display to the HDMI Out port on the Receiver unit using another HDMI cable. ►► CAT-5 3. Connect a CAT-5e (or better) cable, up to 230 feet (70 meters) from the Link port on the Sender unit and the Link port on the Receiver unit. Information Resolution will affect extension distance.
Installation Getting Started Sample Wiring Diagram CAT-5 CABLE HDMI CABLE IR IN IR Extender (EXT-RMT-EXTIRN) OR Ultra HD Source IR OUT Automation Control Device Receiver Unit IR Emitter OR IR Extender (EXT-RMT-EXTIRN) Automation Control Device Sender Unit IR Emitter Ultra HD Display GTB-UHD-HBTL Information The wiring diagram, shown above, requires an additional IR emitter (Gefen part no. EXT-IREMIT) and IR extender (Gefen part no. EXT-RMT-EXTIRN).
This page left intentionally blank.
60Hz, 4:2:0 HDBaseT™ Extender w/ 2-way IR and POH 2 Basic Operation page | 9
Basic Operation LED Status The Power Link LED indicator on the Sender and Receiver unit provides basic information on the current status of the 4K Ultra HD HDBaseT Extender w/ 2-way IR and POL. The information, in the table below, applies to both the Sender and Receiver unit. Status Description Solid blue • The Sender / Receiver unit is powered. • Link integrity between Sender and Receiver unit is good. • Link integrity is compromised.
Basic Operation Bidirectional IR Control Controlling the Source from the Viewing Location 1. Connect an EXT-RMT-EXTIRN IR Extender (1 pc included) to the IR In/Ext port on the Receiver unit. If using an automation system, connect the 3.5mm mini-stereo connector from the IR In/Ext port on the Receiver unit to the automation system. IR signals are transmited over the Link cable. 2.
Basic Operation Bidirectional IR Control Controlling the Display from the Source Location 1. Connect an EXT-RMT-EXTIRN IR Extender (1 pc included) to the IR In/Ext port on the Sender unit. If using an automation system, connect the 3.5mm mini-stereo connector from the IR In/Ext port on the Receiver unit to the automation system. IR signals are transmited over the Link cable. 2. Connect an EXT-IREMIT IR Emitter (1 pc included) from the IR Out port on the Receiver unit to the IR sensor on the display.
Basic Operation Bidirectional IR Control Controlling the Source / Display from Different Locations Information Additional IR extenders (Gefen part no. EXT-RMT-EXTIRN) and IR emitters (Gefen part no. EXT-IREMIT) will be required for this configuration. Using bidirectional IR, the 4K Ultra HD HDBaseT Extender w/ 2-way IR and POL allows the source and/or display to be controlled from the Sender or Receiver unit. Refer to the diagram, below, for connection details.
GTB-UHD-HBTL-S DIP Switch Configuration IR Out IR In/Ext Sender unit ON RSN 1234 GTB-UHD-HBTL-R ON RSN 1234 Link IR In/Ext Power ON Link 24V DC Receiver unit Basic Operation Link On the bottom of both the Sender and Receiver unit are a set of DIP switches. The Sender unit has a bank of four DIP switches. The Receiver unit has a bank of two DIP switches. See the following pages for DIP switch settings.
Basic Operation DIP Switch Configuration Each of the following sections describe the DIP switch settings that control each feature. DIP switches that are not related to a specific feature have been grayed-out. Note that DIP switch settings can be used independently or in conjunction with other features, as desired. Information DIP switch 2, on the Receiver unit, is not used and is reserved for optional future expansion.
Basic Operation DIP Switch Configuration HPD Mode HPD (Hot-Plug Detect) is an HDMI feature that senses if the HDMI cable is disconnected from the source or sink device. Once this occurs, the HDMI link is re-initialized if necessary. The 4K Ultra HD HDBaseT Extender w/ 2-way IR and POL allows you to control the way HPD is handled. Description Sender unit HPD High • Both DIP switch 1 and 2 must be in the down (OFF) position when setting HPD high.
This page left intentionally blank.
This page left intentionally blank.
60Hz, 4:2:0 HDBaseT™ Extender w/ 2-way IR and POH 3 Appendix
Appendix Surface Mounting Instructions The Sender and Receiver units can be mounted on any flat surface, as shown below (screws not included). There should be an inch or two of clearance between the edges of the unit and any walls or vertical surfaces to allow for enough clearance for connection and disconnection of the HDMI cables. For installation on a drywall surface, use a #6 drywall screw. When installing, it is recommended to use the center hole on a stud.
Appendix Network Cable Diagram Front of RJ-45 Connector 1 2 3 4 5 6 7 8 Gefen recommends the TIA/EIA-568-B wiring option. Use the following table when terminating cables in the field.
Appendix Specifications Supported Formats Video • • • • 4096 x 2160 3840 x 2160 1920 x 1200 (WUXGA) 1080p Full HD Audio • • • Linear PCM (7.1 channels) Dolby Atmos® and Dolby® TrueHD DTS:X™ and DTS-HD Master Audio™ HDMI In (Sender) • 1 x HDMI Type A, 19-pin, female HDMI Out (Receiver) • 1 x HDMI Type A, 19-pin, female Link (Sender / Receiver) • 1 x RJ-45, shielded, female IR In/Ext (Sender / Receiver) • 1 x 3.5mm, female IR Out (Sender / Receiver) • 1 x 3.
Appendix Index B T Bidirectional IR Control 11 C Connection Instructions 6 Table of Contents viii Technical Support iv W Warranty Information iii Wiring Diagram 7 D DIP Switch Configuration 14 E EDID Management 15 F Features vi H HPD Mode 16 I Installation 6 L LED Status 10 M Mounting Instructions 20 N Network Cable Diagram 21 O Operating Notes v P Packing List vii R Receiver Unit 4 S Safety Instructions ii Sender Unit 2 Specifications 22 page | 23
