User's Manual

page | 5
Introduction
ID Name Description
1 Link Connect a CAT-5e cable (or better), up to
230 feet (70 meters), from this port to the
Link port on the Sender unit.
2 IR In/Ext 3.5mm mini-stereo jack. Connect an EXT-
RMT-EXTIRN IR Extender (1 pc included)
to this port. Alternatively, connect a 3.5mm
mini-stereo connector from this port to the
output of an automation system with an
electrical IR output.
See Bidirectional IR Control (page 11)
for more information on using IR.
3 IR Out Connect an IR emitter (Gefen part no. EXT-
IREMIT) from this port to the IR sensor of the
device to be controlled.
See Bidirectional IR Control (page 11)
for more information on using IR.
4 24V DC This power receptacle can be used to
connect the included 24V DC power supply.
Only one power supply is required for the
extender system to operate. The power
supply can be connected to either the
Sender or Receiver unit.
5 Power Link This LED indicator displays the current
state of the Receiver unit. See LED Status
(page 10) for more information.
6 HDMI Out Connect an HDMI cable from this port to an
Ultra-HD display.
Getting Started
