Supported Formats
Video • 4096 x 2160
• 3840 x 2160
• 1920 x 1200 (WUXGA)
• 1080p Full HD
Audio • Linear PCM (7.1 channels)
• Dolby Atmos® and Dolby® TrueHD
• DTS:X™ and DTS-HD Master Audio™
Connectors & Indicators
HDMI In (Sender) • 1 x HDMI Type A, 19-pin, female
HDMI Out (Receiver) • 1 x HDMI Type A, 19-pin, female
Link (Sender / Receiver) • 1 x RJ-45, shielded, female
IR In/Ext (Sender / Receiver) • 1 x 3.5mm, female
IR Out (Sender / Receiver) • 1 x 3.5mm, female
Power (Sender / Receiver) • 1 x 4-pin, locking, female
Power Link (Sender / Receiver) • 1 x LED, bi-color, blue / green
Operational
Maximum Pixel Clock • 300 MHz
Power Input • 24V DC
Power Consumption • 12 Watts (max.)
Operating Temperature • +32 to +113 °F (0 to +45 °C)
Storage Temperature • -4 to +185 °F (-20 to +85 °C)
Storage Humidity (RH) • 0% to 90%, non-condensing
Operating Humidity (RH) • 5% to 90%, non-condensing
MTBF • 50,000 Hours
Physical
Dimensions (W x H x D)
(Sender / Receiver)
• 4.3” x 1” x 3.2”
(110mm x 26mm x 85mm)
Unit Weight (ea.) • 0.4 lb (0.2 kg)
Specications
