Features
• Extends 4K Ultra HD (3840 x 2160 @ 60Hz, 4:2:0 or @ 30Hz, 4:4:4) and
Bi-Directional R over a single CAT-5e cable up to 130 feet/40 meters (8-bit color)
• Extends 4K Cinema (DCI) (4096 x 2160 @ 24 or 30Hz 4:4:4), and
Bi-Directional IR over a single CAT-5e cable up to 130 feet/40 meters (8-bit color)
• Extends HDMI at 1080p Full HD and Bi-Directional IR over a single CAT-5e cable up
to 230 feet/70 meters (up to 12-bit Deep Color)
• HDMI Features Supported:
► HDMI 2.0
► HDCP 2.2 and 1.4
► 12-bit Deep Color
► LPCM 7.1 audio, Dolby® TrueHD, and DTS-HD Master Audio™ pass-through
► 3DTV pass-through
► CEC pass-through
► Lip Sync pass-through
• IR extension from Sender to Receiver and from Receiver to Sender
• Gefen Bi-Directional POL feature provides power to the Sender or the Receiver unit
over the link cable - only one side needs external power
• Uses Gefen’s implementation of HDBaseT™ technology
• Advanced EDID Management
• Locking power connector
• Surface mountable
Features and Packing List
1080P
60Hz, 4:2:0
HDCP
2.2
HDCP
2.2
4K
CINEMA
DCI, 4096 x 2160, 30Hz
4K
CINEMA
DCI, 4096 x 2160, 30Hz
