DESCRIPTION The system Gemini 7201 is a compact alarm supplied with sensors and siren, which can be installed on vehicles with 12Volt battery-negative to earth. FUNCTIONS GEMINI 7201. - Compact alarm with dynamic code (Frequency 433.92 MHz ). - Blinker and electronic siren. - Negative control for supplementary siren. - Electrical central door locking control (negative or positive) windows and electric sunroof (for vehicles equipped with Pack-comfort system).
SPECIAL FUNCTIONS Panic Is obtained pressing the transmitter 2 button with the alarm armed or disarmed after the neutral time of 45 seconds. The siren activates for 29 seconds. To de-activate the siren within the 29 seconds, press again on the transmitter 2 button. SIREN EXCLUSION While alarm disarmed, turn the ignition key of the vehicle to ON. Press on the transmitter 2 button for at least 3 seconds, the LED lights fix till the releasing of the transmitter’s button to signal the siren sound exclusion.
ULTRASONIC MODULE DESCRIPTION GEMINI ref. 5123. The ultrasonic module ref. 5123 protects the vehicle, detecting the door opening or the movements inside the passenger’s compartment. DESCRIPTION OF THE MODULE GEMINI 7059. FITTING INSTRUCTIONS. Connect the ultrasonic module to the alarm system wiring harness then put the connectors of the ultrasonic cells in the suitable socket: RED for the TX cell and WHITE for the RX cell.
7059 Alarm Triggering LED AMP Connector Sensitivity Adjustment 7059 Sensor - Fitting Positions NOTE : the sensor module must be fitted on the car in a central position with the TOP side (TRIMMER and LED side) turned on the internal of the passengers compartment. 7059 EM Field Frequency Operating Temperature Alarm Triggering pulse Negative Operating Power Supply Current Consumption TECHNICAL DATA. 2,45GHz ±2,45MHz -40°C ÷ +85°C 4 sec.
FITTING DIAGRAM ref.7201 Push-Button 2 Push-Button 1 ON 1 2 3 4 5 6 2344 2344 CLAMP 7059 +30 CLAMP Ultrasonic module 5123 + - NOTE : The Black wires have the identification mark in the end. PINK White-Red PINK Aerial Antena Antenne White-Brown Pink Brown Green/black CLAMP Connection module 2344 with 7201 alarm system.
Diagram 4 Diagram 2 EARTH YELLOW-RED ON NOTE : Use N°1 module 5056. Yellow YELLOW-GREY White-Red 1 2 3 4 5 6 2 OFF - 3 OFF Red RED-GREY +30 5A +30 5056 RED-GREY Comune, Common, Commun (Positive or Negative) YELLOW-RED YELLOW-GREY ON YELLOW-GREY Apre, Open, Ouvre, Apertura, Abre. RED-BLUE YELLOW-BROWN Chiude, Close, Ferme, Cierra, Fecha. YELLOW-BLUE M EX : ALFA, FIAT, FORD, LANCIA, OPEL, PEUGEOT, RENAULT, SAAB, SEAT,VW POLO(95>).
Diagram 6 EARTH Yellow YELLOW-GREY RED-GREY ON NOTE : Use N°1 module 5056. White-Red PINK Brown Green/black YELLOW-RED Diagram 8 +30 YELLOW-GREY RED-GREY J1-J2-J3 POS.BC 5056 RED-GREY +30 PINK RED-BROWN YELLOW-BROWN 1 2 3 4 5 6 Ref.2306T Original switch Close YELLOW-BLUE Red Yellow Commun BLUE WHITE-BLACK Open RED-GREY YELLOW-GREY RED-BLUE YELLOW-BROWN COMFORT NOTE : Use N°1 module 5056 et N°1 module 2355 EX : DAEWOO NEXIA,OPEL FRONTERA (<99).
Diagram 9P Diagram 22 YELLOW-RED ON 1 2 3 4 5 6 NOTE : Use N°2 Diodes 1N4004. 2 OFF - 3 ON NOTE : Use N°1 module 5056. EARTH Yellow YELLOW-GREY Red RED-GREY White-Red +30 5A 5056 +30 Commun Positive YELLOW-RED RED-GREY IN4004 IN4004 YELLOW-GREY CLOSE (25 sec.) COMFORT (25sec.) YELLOW-GREY RED-GREY YELLOW-BROWN 1 2 3 4 5 6 RED-BROWN 2 OFF - 3 OFF YELLOW-BLUE OPEN (1 sec.) EX : SEAT TOLEDO(<96). Do not connect RED-BLUE ON Central door locking L.H.S.
