User Manual

Parameter Default value Range Description
ip_address_1x {dotted-quad} none IP address IP address of the AP to be used
in DHCP relay when forwarding
requests for 802.1x users.
subnet_mask {dotted-quad} 255.255.0.0 Any valid mask. Subnet mask for network (used
to determine broadcast ad-
dresses).
gateway {dotted-quad} none IP address Default gateway for packets not
on the local subnet, or the
address of the zone controller if
zone privacy is set.
telnet_port {port} 23 0-65535 Telnet server port number (0
disables access).
http_port {port} 80 0-65535 Web server port number (0
disables access).
manager {[any | specific]} any any, specific Limits management access to
specific IPs, or disables it
altogether.
password {password} private up to 16 charac-
ters in sets of a - z,
A - Z and 0 - 9
Password for management ac-
cess to Access Point (case
sensitive).
ap_name {name} LocalAP Up to 15 charac-
ters
Access Point name (equivalent
to hostname).
protocol_filter {[tcpip | all]} all all, tcp/ip Enables packet filtering, dis-
carding all non-TCP/IP traffic.
zone_privacy {[on | off]} off on or off Enables the zone privacy fea-
ture.
community_get {string} public up to 16 charac-
ters
Community name for SNMP
get operations (case sensitive).
community_set {string} private up to 16 charac-
ters
Community name for SNMP
set operations (case sensitive).
snmp_contact {string} Contact up to 32 charac-
ters
SNMP contact name, from the
RFC1213 MIB (case sensitive).
snmp_sys_name {string} Sys Name up to 32 charac-
ters
SNMP system name, from the
RFC1213 MIB (case sensitive).
snmp_location {string} Location up to 64 charac-
ters
SNMP location data, from the
RFC1213 MIB (case sensitive).
snmp_secret {secret} default up to 16 charac- An ASCII string giving the
52 (60) # Nokia Corporation
Nokia Proprietary and Confidential
dn02119532
Issue 1-0 en
Nokia A036 Wireless LAN Access Point User Manual
