DX-WGNBC_WGDTC.
DX-WGNBC_WGDTC.fm Page 2 Monday, June 12, 2006 10:34 PM 2 Contents Dynex DX-WGNBC or DX-WGDTC Wireless LAN Card 6 If you are installing a desktop card, turn off your computer, install the card, then turn on your computer again. The Found New Hardware Wizard opens. -ORInsert your notebook card into the appropriate slot in your notebook. The Found New Hardware Wizard opens. Contents Introduction .....................................................................................
DX-WGNBC_WGDTC.fm Page 3 Monday, June 12, 2006 10:34 PM 3 Installing the software and hardware 7 Right-click on the My Computer desktop icon, click Properties, then click Hardware Device Manager. Make sure that the card is listed as one of the devices in your computer. 10 Click Protocol, then click Add. The Select Network Protocols dialog box opens. 8 If you are using Windows 98, right-click on the Network Neighborhood desktop icon, then click Properties.
DX-WGNBC_WGDTC.fm Page 4 Monday, June 12, 2006 10:34 PM 4 Configuring the wireless network Configuring the wireless network Your Wireless LAN 802.11g card uses its own management software. All functions are controlled by this utility. To make it easier to move from one network environment to another, the utility uses profiles that you create. To use the wireless utility: 1 Click Start, All Programs or Programs, Dynex Wireless LAN Card Utility, then Dynex Wireless LAN Card Utility.
DX-WGNBC_WGDTC.fm Page 5 Monday, June 12, 2006 10:34 PM 5 Configuring the wireless network Connecting to a network 5 Click Next. The following screen opens. To connect to a network: 1 Click Connect on the Available Networks tab. The following screen opens. 2 Set the values of the following fields: • Network Name—Type a name for the new profile. • Network Type —Select from the list of supported network types. Supported types include: • Peer to Peer—This is the 802.
DX-WGNBC_WGDTC.fm Page 6 Monday, June 12, 2006 10:34 PM 6 Troubleshooting 9 Click Next. The following screen opens. About tab The About tab shows the product version including details of the driver, application, and firmware versions. You must use this version number when reporting problems to Dynex. 10 • • • • • 11 The purpose of this screen is to configure the TCP/IP setting of each wireless connection.
Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
IC statement IC statement Operation is subject to the following two conditions: 1) This device may not cause interference and 2) This device must accept any interference, including interference that may cause undesired operation of the device. This device has been designed to operate with an antenna having a maximum gain of 4.57 dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms.
DX-WGNBC_WGDTC.fm Page 12 Monday, June 12, 2006 10:34 PM www.dynexproducts.com (800) 305-2204 Distributed by Best Buy Purchasing, LLC 7601 Penn Ave. South, Richfield, MN 55423 U.S.A. Distribué par Best Buy Purchasing, LLC 7601 Penn Ave. South, Richfield, MN 55423 É.-U. Distribuido por Best Buy Purchasing, LLC 7601 Penn Ave. South, Richfield, MN 55423 U.S.A.
