GEN 一 TECHNOLOGY GS60716 USER GUIDE Please read this instruction throughly before using this product and keep it for future reference. ©2020 Distributed by: Gener8 Technology Indianapolis, IN Have questions or comments? Call 877-220-6508 or email: customerservice@gener8hk.
FUNCTION OVERVIEW ❶ ❷ ❸❹ ❺ 1.Volume+ 2.Volume- 3.Power On/Off 4.Reset 5.Front-facing Camera 6.Earphone 7.MicroSD Card Slot 8.Micro USB 9.Microphone 10.Speaker 11.Back Camera Google, Android, Google Play and other marks are trademarks of Google LLC.
GETTING STARTED Power On/Off * Press and hold the power button for 2~3s to turn on your tablet. Select your language and set up your tablet following the start guide. * Press and hold the power button for 2s, then release it. It will show Power off ,Restart and Screenshot on the screen. Tap Power off to turn off the tablet. * Press and hold the power button for 10s to do a forced reboot when it's frozen. Battery * A rechargeable Li-ion battery is installed in the tablet.
HOME SCREEN Icons on the Bottom Menu 1.Volume2.Back 3.Home Screen 4.Recent Activities 5.Volume+ ❶ ❷ ❸ ❹ ❺ Home Settings,Widgets and Wallpapers * Tap and hold the empty section of a Home screen, Home settings, Widgets and Wallpapers will be displayed. * Tap Home Settings to enable/disable Add icon to Home screen. This is applicable to the new Apps installed from Play Store. It also provides the shortcut to enable/disable the notification dots.
* Tap Widgets, touch and hold any application (e.g. Clock), then slide and add it to a Home screen. Remove it by sliding it to X Remove. * Tap Wallpapers to change the current wallpaper of the tablet from the default wallpapers or your photos. SETTING BASICS Quick Settings Swipe down from the top of the screen to access Quick Settings. :Wifi. Tap to connect/disconnect to a wireless network :Bluetooth. Enable/disable the Bluetooth of the tablet :Do not disturb.
Network & internet * Connect to any working Wifi * Enable/disable the Airplane Mode * Monitor the data usage and more Connected devices * Turn on/off Bluetooth * Pair with Bluetooth devices and check the paired devices * Check the received files from other devices via bluetooth connection.
Apps & notifications * Check the Apps recently opened * Check all the Apps on the tablet * Set the App permissions * Uninstall the third-party Apps * Adjust App notification settings * Clear the cache of the Apps Battery * Display the remaining battery power as a percentage * Enable/disable Battery percentage and Battery Manager * Set Power saving optimization * Manage the battery optimization for apps and more Display * Adjust the screen brightness * Adjust the font size and display size * Set a screen s
Privacy * Set tablet access permissions and privacy management Location * Turn on/off the location services for specific Apps Security * Set screen lock pattern, e g Password, PIN, Swipe etc * Enable disable all the notifications while the screen is locked * Set to show/hide the password when input a password.
System * Set Language Tap Languages & input> Languages +Add a language to add your language. adding, hold and slide the to the top to change the language.
Bluetooth Pairing Please turn on the Bluetooth on your tablet and your bluetooth device. 1. Tap Connected devices. 2. Tap +Pair new device to enter the scanning interface. Devices available will be displayed after a few seconds. 3. Tap the desired device to get a paring code and click PAIR on both devices The automatic connection is applied to some devices. APP MANAGEMENT App Download and Installation 1. Tap and open Play Store on the Home screen. 2.
Uninstall the App Touch and hold the App, then slide to the Uninstall to Uninstall the App. Clear the Cache of the App 1. Go to Settings > Apps & notifications. 2. Select an App > Storage > CLEAR CACHE to clear the cache. INTERNET NAVIGATION Please make sure the tablet is connected to a working Wifi network before navigating the Internet. You may use the pre-installed Chrome browser or use another browser downloaded on the Play Store. MULTIMEDIA Connecting to a Computer 1.
Connecting to an External Device 1. Install a microSD card into the microSD card slot and go to Quick Settings. 2. Tap SET UP. 3. Set the microSD card as a portable storage by selecting Portable storage. Enter microSD Card storage to move files between the card and tablet.
SPECIFICATION Size 7“ Connection WiFi Chipset RK3326 CPU Quad-Core Cortex A35 up to 1.5GHz GPU Mali G31MP2 RAM 2GB Display/ Resolution TN/1024*600 Storage 16GB Front-facing Camera 0.3MP Network 802.11b/g/n,BT4.1 Back Camera 2MP Power Supply USB 5V/1.5A Battery 2500mAh Touch Multi-touch Operating System Android™ 10 Ports Micro USB /microSD Card Slot TROUBL ESHOOTING Q1. The tablet doesn't power on. * Reboot your tablet after charging for more than 30 minutes.
* Instead of Charge only, choose Media device(MTP) or Camera(PTP) when connecting the tablet to the computer. Q5. The tablet cannot connect to the Wifi. * Make sure the Wifi in your tablet is ON. * Make sure you input the correct password when connecting the Wifi. * Restart the route. * Make sure there is no filter setting or device connection limitation in the setting of the router. * Forget the current Wifi, reset the router and connect the Wifi again. Q6. The storage space of the tablet is not enough.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
