User's Manual

The Security Menu
You can set, chan
g
e or remove
p
asswords in the Securit
y
menu.
IDE Controller
Enabled
Disabled
If enabled, both the PATA and
SATA IDE Controllers are enabled.
If disabled, both the PATA and
SATA IDE controllers are disabled.
HDC Configure as PATA Only
SATA Only
IDE
Combined
IDE Non-
Combined
AHCI
Sets the Harddisk Controller
Configuration Type.
SATA Port 0 Hotplug
Enabled
Disabled
If enabled, the SATA Port 0
Hotplug is enabled.
SATA Port 1 Hotplug
Enabled
Disabled
If enabled, the SATA Port 1
Hotplug is enabled.
SATA Port 1 ILS
Enabled
Disabled
If enabled, the SATA Port 1
InterLock Switch is enabled.
SATA Port 2 Hotplug
Enabled
Disabled
If enabled, the SATA Port 2
Hotplug is enabled.
Primary IDE Cable Type
Auto
40 Pins
80 Pins
Determines the type of IDE Cable
used.
Channel 1 Master
Not
Installed
If a drive is installed, its
manufacturer, drive type, and model
are displayed. Pressing [Enter]
displays additional drive and setting
information:
Type : <Auto/User Defined>
If USER Defined is enabled, the
following settings can be changed:
32Bit I/O
<Enabled/Disabled>
Block Mode:
<Enabled/Disabled>
Transfer Mode:
<Enabled/Disabled>
Security Mode:
Channel 1 Slave
(Drive
Model)
Channel 2 Master
Not
Installed
Channel 2 Slave
Not
Installed
Channel 3 Master
(Drive
Model)
Channel 3 Slave
Not
Installed
Channel 4 Master
Not
Installed
Channel 4 Slave
Not
Installed
Pa
g
e 50 of 70V
R
-2 Hel
p
