Use and Care Guide

WHAT’S IN THE CASE

The DPS16 comes in a custom hard plastic protective carrying case. Inside the case are:

• The H16 console. The console integrates an LCD monitor, a connector for a high-

performance camera-tipped probe from General, and front-panel controls for controlling the

camera’s lights, adjusting system parameters, and recording and playing back videos and

photos captured by an attached probe.

• The P16PIP Pipe & Duct Inspection Probe & Reel Set

• One spherical metal ring for centering the probe in 2 in. I.D. pipes

• One brush set for centering the probe in 4 in. I.D. pipes

• One brush set for centering the probe in 6 in. I.D. pipes

• A 5/64-in. Allen wrench for attaching the 2 in. probe centering ring

• A plastic bag containing five spare 5/64-in. Allen screws

• A 2GB SD memory card for the H16

• An AC adapter/battery charger for a 110/220VAC supply. The adapter has a 5.5VDC, center-

positive output plug.

• A video cable for connecting the H16 to a TV monitor. The cable has RCA plugs at one end

and a mini-stereo plug at the other end.

• A USB cable with a mini-USB plug on one end and a full-size USB plug on the other end. It

can be used to display the contents of the SD card on a computer directly, without removing

the card from the console.

• A soft cloth, a bottle of liquid, and cotton swabs for cleaning the console

• A package of desiccant

• This user’s manual
