Specification

LCD is backlit for easy reading
in dark places
The CA10 comes with a durable, soft canvas carrying case
Parameter
Line Voltage
Peak Voltage
Line Frequency
Voltage Drop
Load Voltage
Neutral-to-Earth Voltage
Hot, Neutral and Ground Line
Impedance
GFCI Triggering Time
RCD Triggering Time
RCD Triggering Current
Operating/Storage Temperature
Dimensions
Weight (without Batteries)
Measurement Range Measurement Accuracy Display Resolution
85 to 265VAC ± 1.0% ± 0.2V 0.1V
121 to 374VAC ± 1.0% ± 0.2V 0.1V
45 to 65 Hz ± 1.0% ± 0.2Hz 0.1Hz
0.1 to 99.9% ± 2.5% ± 0.2% 0.1%
10 to 265V ± 2.5% ± 0.2V 0.1V
0 to 10VAC ± 2.5% ± 0.2V 0.1V
0 to 3Ω ± 2.5% ± 0.02Ω 0.01Ω
>3Ω NA
1ms to 6.5 sec. ± 1.0% ± 2ms 1ms
1ms to 6.5 sec. ± 1.0% ± 2ms 1ms
30 to 37mA ± 1.0% ± 0.2mA 0.1mA
32° to 122°F (0° to 50°C) @ <80% RH
7.6 x 3.1 x 1.5 in. (193 x 78 x 39mm)
10.4 oz. (295g)
Specifications:
12 AWG, 20 in. (0.5m) Long Test Cable, Six “AAA” Batteries,
Soft Carrying Case, User’s Manual, 1 Year Limited Warranty
Includes:
Ideal for identifying 110/220VAC power circuit and wiring problems that can cause
shocks, sparks, fires, equipment failures and poor equipment performance
AC Circuit Analyzer
General Tools & Instruments
80 White Street, New York, NY 10013-3567
TEL: [phone] TOLL FREE: 800. 697. 8665
[e-mail] www.generaltools.com
CA10-SS
