User Manual

Dimensions
 Hard‐CeilingMount
 In‐CeilingMount
Specifications
Camera
ImageSensor 1/3”progressivescanCMOS
PictureElements 1280(H)x1024(V)
Color 0.05Lux
B/W 0.03Lux
Minimum
Illumination
IRON 0Lux
ShutterSpeed Automatic,Manual(1/5~1/8000sec.)
WhiteBalance Automatic,Manual(2800K~8500K)
GainControl Automatic
S/NRatio 50dB
BLC Yes
Lens
Megapixel Yes
Day/Night Yes(withremovableIR‐cutfilter)
LensType Varifocal
FocalLength 3~9mm
MaximumAperture F/1.3±5%
Mount Ø14mm
ImageFormat 1/3”
HorizontalFOV 86°~32°
Focus Manual(w/lock)
Zoom Manual(w/lock)
Operation
Iris DCdrive
Max.Torque(Focus/ZoomScrews) 0.049N.m
IRLEDQuantity 10IRLEDs
Max.IRDistance 15m(50ft.)
Operation
VideoCompression H.264,MJPEG
VideoStreaming DualstreamsfromH.264andMJPEG
FrameRate
30fpsat1280x1024
*Theframerateandtheperformancemayvarydependingonthenumberofconnectionsanddata
bitrates(differentscenes).
ImageSetting
Brightness,Contrast,Sharpness,Gamma,WhiteBalance,Flicker‐less,ImageOrientation,ShutterSpeed,
BacklightCompensation,D/NSensitivity,WDR,Defog
GV-FD120D March 6, 2014
- 2 -
