V110 USER MANUAL Rugged Mobile Computing Solution
Oct. 2013 TRADEMARKS All brand and product names are trademarks or registered trademarks of their respective companies. NOTE The information in this manual is subject to change without notice. For the latest version of the manual, please visit the Getac website at www.getac.com.
Table of Contents Chapter 1 Getting Started.............................................................. 1-1 Getting the Computer Running ............................................. 1-2 Unpacking ........................................................................... 1-2 Connecting to AC Power .................................................... 1-3 Opening and Closing the Cover......................................... 1-4 Operating in Tablet Mode .................................................
Using the Touchpad ................................................................ 2-7 Configuring the Touchpad................................................. 2-9 Navigating on the Screen ..................................................... 2-10 Using the Touchscreen ..................................................... 2-10 Using the Dual Mode Display (Optional) ........................ 2-13 Using the Network Features................................................. 2-14 Using the LAN .................
Advanced Menu .................................................................. 5-4 Security Menu ..................................................................... 5-5 Boot Menu .......................................................................... 5-6 Exit Menu ............................................................................ 5-6 Chapter 6 Using Getac Software ................................................... 6-1 OSD Control Panel .....................................................
System Restore, Refresh, or Reset (for Windows 8 Models) .............................................................................. 8-11 System Recovery (a Tool for Windows 7 Models)........... 8-12 Appendix A Specifications ............................................................... A-1 Appendix B Regulatory Information ............................................... B-1 On the Use of the System ....................................................... B-2 Class B Regulations ........................
Chapter 1 Getting Started Congratulations on purchasing this rugged computer. This chapter first tells you step by step how to get the computer up and running. Then, you will find a section briefly introducing the external components of the computer.
Getting the Computer Running Unpacking After unpacking the shipping carton, you should find these standard items: Notebook computer Accessories: − AC adapter − AC power cord − Stylus or digitizer pen (optional) − Tether − Carrying Strap − AG/AR (anti-glare/anti-reflection) film, which is already attached to the screen − Screen cleaning cloth − Driver disc − Document(s) Inspect all the items. If any item is damaged or missing, notify your dealer immediately.
Connecting to AC Power It is suggested that you use AC power when you start up the computer for the very first time. 1. Plug the DC cord of the AC adapter to the power connector of the computer (). 2. Plug the female end of the AC power cord to the AC adapter and the male end to an electrical outlet (). 3. Power is being supplied from the electrical outlet to the AC adapter and onto your computer. Now, you are ready to turn on the computer. CAUTION: Use only the AC adapter included with your computer.
Opening and Closing the Cover To open the top cover: 1. Pull loose the cover latch () and release the clamp (). 2. Lift up the cover (). You can tilt the cover forward or backward for optimal viewing clarity. To close the top cover: 1. Close the display. 2. Lift the cover latch and engage the clamp on the display. Then, push in the cover latch to click it into place.
Operating in Tablet Mode In addition to being used as a regular notebook computer (Laptop mode), your computer can also be operated in Tablet mode. In Tablet mode, you operate the computer with a stylus or digitizer pen, or a fingertip, instead of a keyboard or mouse. 1. Open the top cover so that it is almost perpendicular with the keyboard of the computer. 2. Turn the display counter-clockwise by 180o. CAUTION: The allowed rotation range is between counter-clockwise by 180o and clockwise by 45 o.
4. Lift the cover latch and engage the clamp on the display. Then, push in the cover latch to click it into place.
Turning On and Off the Computer Turning On Press the power button ( ). The Windows operating system should start. Turning Off When you finish a working session, you can stop the system by turning off the power or leaving it in Sleep or Hibernation mode: To... Do this... Windows 8 Windows 7 Power off (Shutdown) 1. Open the Charms Bar of Windows 8 by swiping in from the right side of the screen. 2. Tap Settings and then tap (Power). 3. Tap Shut down in the Power menu that pops up.
Taking a Look at the Computer NOTE: Depending on the model you purchased, the appearance of your computer may not be exactly the same as those shown in this manual. CAUTION: You need to open the protective covers to access the connectors. When not using a connector, make sure to close the cover completely for water- and dust-proof integrity. (Engage the locking mechanism if existing.) Front Components Ref Component Description Strap Holder Two buckles hold the carrying strap.
Ref Component Description See Also Down Button Decreases the sound volume. Top Cover Latch Locks the top cover. P. 1-4 P2 Button Starts the Getac Camera program and serves as the shutter release button. P. 6-6 When Function Lock is on: Decreases the LCD brightness. When Function Lock is on: Enables or disables the touchscreen feature. P1 Button Switches on or off Function Lock (FL), which changes the P2, Up, and Down buttons to an alternative function.
Rear Components To access a connector, open its protective cover by lifting up the tab of the cover. When closing the cover, push the tab downward until the cover clicks into place. Ref Component Description See Also Power Connector HDMI Connector Connects a HDMI monitor or TV set. P. 4-2 USB 3.0 Port P. 4-3 RJ-45 Connector Connects the LAN cable. 1-10 Serial Port Connects the AC adapter. Connects a USB device, such as a flash disk, printer, digital camera, joystick, and more.
Right-Side Components To access a connector, open its protective cover by lifting up the tab of the cover. When closing the cover, push the tab downward until the cover clicks into place. To access a device bay, slide the cover latch toward the unlocked position ( ) and then lift up the tab to release the cover. When closing the cover, push the tab downward until the cover clicks into place and then slide the latch toward the locked position ( ).
Ref Component ExpressCard Slot Description Accepts an ExpressCard for additional functions. See Also P. 4-7 Left-Side Components To access a device bay, slide the cover latch toward the unlocked position ( ) and then lift up the tab to release the cover. When closing the cover, push the tab downward until the cover clicks into place and then slide the latch toward the locked position ( ). Ref Component Description See Also Hard Disk Drive Inside is the hard disk drive. P.
Top-open Components Ref Component Description See Also RFID Antenna (optional) Scans and reads RFID (Radio-frequency identification) tags. Touchscreen Displays and receives information for the computer. Camera Lens (optional) Allows you to use your computer’s camera function. When the camera lens is in use, the LED beside it lights up. Microphone Receives sound and voice to record voice. P. 6-6 P. 2-10 P.
Ref Component Description Light Sensor Detects the surrounding lighting condition for automatic adjustment of the LCD brightness and optional keyboard backlight. Windows Logo Button For Windows 8: Goes to the Start screen. Or if you're already on Start, pressing this button brings you to the last application you were in. See Also For Windows 8 (when pressed longer): Opens or closes the OSD Control Panel. P. 6-2 For Windows 7: Opens or closes the OSD Control Panel. P.
Ref Component Description See Also RF (Radio Frequency) Lights green when the RF radio of any RF feature (WLAN/BT/WWAN) is on. Keyboard Serves as the data input device. P. 2-2 Touchpad Serves as the pointing device. P. 2-7 Bottom Components Ref Component Description Camera Indicator (optional) Lights up when the camera lens beside it is in use. Flash (optional) Provides extra light when taking pictures. Camera Lens (optional) Allows you to use the camera function.
Ref Component Description Memory Slots Inside are the memory slots for expanding the memory size of your computer. SIM Card Slot (optional) Inside is the SIM card slot. Antenna Passthrough (optional) Connects to the docking station for using external WWAN/GPS/WLAN antenna. Can be tri type or dual type (WWAN+GPS or WLAN+GPS) depending on your model. Docking Connector Inside is the docking connector for connecting an office dock or vehicle dock (purchased separately).
Installing the Accessories Attaching the Carrying Strap Insert one end of the strap into one strap holder () on your computer and feed it through the slider buckle (). Use the fastener () to fix the strap end in place. Secure the other end of the strap to the computer in the same way. The strap provides a slot for storing the stylus or digitizer pen ().
Using the Tether A tether is provided for attaching the stylus to your computer. 1. Insert one of the tether’s loop ends through the hole of the stylus (as indicated by below). Then, insert the other end through the first loop (as indicated by below) and pull it tight. 2. Insert the other loop end to the strap holder on computer (as indicated by below). Then, insert the stylus end through the loop (as indicated by below) and pull it tight.
Attaching the Handgrip Strap (Optional) To use the handgrip strap, attach its four loops to the four bottom hooks on your computer. Make sure the loops are securely hooked. When you need to operate and hold your computer at the same time, insert your hand through the strap for a firm grip.
Chapter 2 Operating Your Computer This chapter provides information about the use of the computer. If you are new to computers, reading this chapter will help you learn the operating basics. If you are already a computer user, you may choose to read only the parts containing information unique to your computer. CAUTION: Do not expose your skin to the computer when operating it in a very hot or cold environment. The computer can get uncomfortably warm when you use it in high temperatures.
Using the Internal Keyboard Your keyboard has all the standard functions of a full-sized computer keyboard plus an Fn key added for specific functions. The standard functions of the keyboard can be further divided into four major categories: Typewriter keys Cursor-control keys Numeric keys Function keys Typewriter Keys Typewriter keys are similar to the keys on a typewriter. Several keys are added such as the Ctrl, Alt, Esc, and lock keys for special purposes.
Numeric Keypad A 15-key numeric keypad is embedded in the typewriter keys as shown next: Numeric keys facilitate entering of numbers and calculations. When Num Lock is on, the numeric keys are activated; meaning you can use these keys to enter numerals. NOTE: When the numeric keypad is activated and you need to type the English letter in the keypad area, you can turn Num Lock off or you can press Fn and then the letter without turning Num Lock off.
Function Keys On the top row of the keys are the function keys: F1 to F12. Function keys are multi-purpose keys that perform functions defined by individual programs. Fn Key The Fn key, at the lower left corner of the keyboard, is used with another key to perform the alternative function of a key. The letter “Fn” and the alternative functions are identified by the color of blue on the keytop. To perform a desired function, first press and hold Fn, then press the other key.
Key Description Switches the display output to the next choice if an external display is connected. Choices are: LCD only LCD + External display (Duplicate) LCD + External display (Extend) External display only The hot keys are equivalent to Windows logo key + P. Decreases the LCD brightness. Increases the LCD brightness. Switches the touchscreen on or off (option). Switches the touchpad off or on. Switches the system sound output off (mute) or on. Switches the display on or off.
Windows Keys The keyboard has two keys that perform Windows-specific functions: Windows Logo key and Application key. The Windows Logo key opens the Start menu and performs softwarespecific functions when used in combination with other keys. The Application key usually has the same effect as a right mouse click.
Using the Touchpad CAUTION: Do not use a sharp object such as a pen on the touchpad. Doing so may damage the touchpad surface. NOTE: Press Fn+F9 to toggle the touchpad on or off. For optimal performance of the touchpad, keep your fingers and the pads clean and dry. When tapping on the pad, tap lightly. Do not use excessive force.
Here are some common terms that you should know when using the touchpad: Term Action Point Move your finger on the pad until the cursor points to the selection on the screen. Click Press and release the left button. –or– Tap gently anywhere on the pad. Double-click Press and release the left button twice in quick succession. –or– Tap twice on the pad rapidly. Drag and drop Press and hold the left button, then move your finger until you reach your destination (drag).
Gestures Actions Descriptions Two-finger pinch Zoom Swipe in from the right edge Open the Charms bar. Swipe down from the top edge Perform the same function as a right-click. Swipe in from the left edge Switch to the previous application. Configuring the Touchpad You may want to configure the touchpad to suit your needs. For example, if you are a left-handed user, you can swap the two buttons so that you can use the right button as the left button and vice versa.
Navigating on the Screen The screen of your computer is touch-sensitive. You can control the location of the cursor/pointer on the screen using the included stylus/digitizer pen or your finger to communicate with the computer. CAUTION: Do not use a sharp object such as a ballpoint pen or pencil on the touchscreen. Doing so may damage the touchscreen surface. Use the included stylus/digitizer pen or your finger. NOTE: An AG/AR film has been attached to the screen before shipment.
Equivalent Mouse Function Term/Action Tap: Touch the screen once. Click/Point Double-tap: Touch the screen twice rapidly. Double-click Tap and hold: Tap and hold until a popup menu appears. Right-click Drag: Hold the stylus (or finger) on the screen and drag across the screen until reaching your destination. Drag Using Multi-touch Gestures You can interact with your computer by placing two fingers on the screen.
Gestures ( Actions = finger down; = finger up) Rotate or Move two fingers in opposing directions. -orUse one finger to pivot around another. Press and Tap Descriptions Use rotating to move a picture or other item on the screen in a circular direction (clockwise or counterclockwise). The gesture works in applications that support the specific gesture. Use press and tap to access the shortcut menu. Press on target and tap using a second finger.
Gestures ( Actions = finger down; = finger up) Flicks Make quick drag gestures in the desired direction. Descriptions Flick left or right to navigate back and forward in a browser and other applications. The gesture works in most applications that support back and forward. Using the Dual Mode Display (Optional) Dual mode display (if your model has the feature) incorporates both touchscreen and digitizer functions. The display is set to Touchscreen mode by default.
Using the Network Features Using the LAN To connect the network cable to the LAN module, connect one end of the LAN cable to the RJ-45 connector on the computer and the other end to the network hub. Using the Wireless LAN The WLAN module of your computer supports IEEE 802.11a/b/g/n/ac. Turning On/Off the WLAN Radio To turn on the WLAN radio: 1. Make sure that the Airplane mode is switched off. You can control the Airplane mode using one of the below methods. • Press Fn+F1.
• For Windows 7: Use either Windows Mobility Center or Getac Quick Bar. To open Getac Quick Bar, tap and hold the Getac Utility icon on Windows taskbar and select Quick Bar. Tap the WLAN button in the Quick Bar (an X over the button means the radio is currently off). To turn off the WLAN radio: You can turn off the WLAN radio the same way you turn it on. If you want to quickly turn off all wireless radio, simply switch on Airplane mode. Connecting to a WLAN Network 1.
Using the BT Feature The BT 4.0 technology allows short-range (about 50 meters) wireless communications between devices without requiring a cable connection. Data can be transmitted through walls, pockets and briefcases as long as two devices are within range. Turning On/Off the BT Radio To turn on the BT radio: 1. Make sure that the Airplane mode is switched off. You can control the Airplane mode using one of the below methods. • Press Fn+F1. • Use the Airplane Mode button in the OSD Control Panel.
To turn off the BT radio: You can turn off the BT radio the same way you turn it on. If you want to quickly turn off all wireless radio, simply switch on Airplane mode. Connecting to another BT Device 1. Make sure that the BT function is enabled (as described above). 2. Make sure that the target BT device is turned on, discoverable and within close range. (See the documentation that came with the BT device.) 3. For Windows 8: Open the Charms Bar of Windows. Tap Settings Change PC Settings Devices.
Using the WWAN Feature (Optional) A WWAN (Wireless Wide Area Network) uses mobile telecommunication cellular network technologies to transfer data. The WWAN module of your computer supports 3G and 4G LTE. NOTE: Your model only supports data transmission. Voice transmission is not supported. Installing a SIM Card 1. Turn off the computer and disconnect the AC adapter. 2. Carefully place the computer upside down. 3. Remove the 8 screws to open the compartment cover. 4. Locate the SIM card slot.
Locking tab 5. Close the compartment cover and secure with 8 screws. Turning On/Off the WWAN Radio To turn on the WWAN radio: 1. Make sure that the Airplane mode is switched off. You can control the Airplane mode using one of the below methods. • Press Fn+F1. • Use the Airplane Mode button in the OSD Control Panel. • For Windows 8: Open the Charms Bar, tap Settings Change PC Settings Wireless. Slide the Airplane mode switch to the Off position. 2.
To turn off the WWAN radio: You can turn off the WWAN radio the same way you turn it on. If you want to quickly turn off all wireless radio, simply switch on Airplane mode. Setting up a WWAN Connection 1. Make sure that the SIM card is inserted and the WWAN function is enabled (as described above). 2. Start the WWAN utility software (AirCard Watcher). The screen as below appears. 3. You can use the WWAN utility software to configure and use WWAN connections. See the online help for information.
Chapter 3 Managing Power Your computer operates either on external AC power or on internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way.
AC Adapter CAUTION: The AC adapter is designed for use with your computer only. Connecting the AC adapter to another device can damage the adapter. The AC power cord supplied with your computer is for use in the country where you purchased your computer. If you plan to go overseas with the computer, consult your dealer for the appropriate power cord. When you disconnect the AC adapter, disconnect from the electrical outlet first and then from the computer.
Battery Pack Your computer has two battery packs. The battery pack is the internal power source for the computer. It is rechargeable using the AC adapter. NOTE: Care and maintenance information for the battery is provided in the “Battery Pack Guidelines” section in Chapter 7. Charging the Battery Pack NOTE: Charging will not start if the battery’s temperature is outside the allowed range, which is between 0 °C (32 °F) and 50 °C (122 °F).
Initializing the Battery Pack You need to initialize a new battery pack before using it for the first time or when the actual operating time of a battery pack is much less than expected. Initializing is the process of fully charging, discharging, and then charging. It can take several hours. A software tool called “Gauge Reset” is provided for the purpose. Use the G-Manager program and select the Battery tab to find the tool.
Switch The value of the corresponding green segment indicates the relative percentage of the battery charge. The battery pack is fully discharged when you see no segment glowing green. Battery Low Signals and Actions The battery icon battery. changes appearance to display the current state of the Battery Battery Level Icon Description Discharging The icon shows the charge remaining in 10-percent increments until the charge reaches the low-battery level.
Replacing the Battery Pack CAUTION: There is danger of explosion if the battery is incorrectly replaced. Replace the battery only with the computer manufacturer’s battery packs. Discard used batteries according to the dealer’s instructions. Do not attempt to disassemble the battery pack. NOTE: You can hot swap one battery pack while the other one is supplying the power. To replace the battery pack, follow these steps: 1.
4. Noting the orientation, insert the new battery pack all the way into the slot. 5. Slide the battery latch toward the left to the locked position. (Battery 1 as the example) 6. When closing the cover, push the tab downward until the cover clicks into place and then slide the latch toward the locked position ( ).
Power-Saving Tips Aside from enabling your computer’s power saving mode, you can do your part to maximize the battery’s operating time by following these suggestions. Do not disable Power Management. Decrease the LCD brightness to the lowest comfortable level. Shorten the length of time before Windows turn off the display. When not using a connected device, disconnect it. Turn off the wireless radio if you are not using the wireless module (such as WLAN, BT, or WWAN).
Chapter 4 Expanding Your Computer You can expand the capabilities of your computer by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter.
Connecting an HDMI Display Monitor If you want the benefits of a larger display screen with higher resolution, you can connect an external display monitor to your computer. Your computer supports an HDMI connector. HDMI (High-Definition Multimedia Interface) is an audio/video interface that transmits uncompressed digital data and therefore delivers true HD quality. You can switch the display output by using Fn+F5, Windows Control Panel, or OSD Control Panel.
Connecting a USB Device Your computer has three USB ports (two USB 3.0 ports at the rear and one USB 2.0 port at the right side) for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. USB 3.0 supports a transfer rate up to 5 Gbit/s and USB 2.0 a transfer rate up to 480 MB/s. USB 3.0 USB 2.
Connecting a Serial Device Your computer has a serial port for connecting a serial device such as a serial mouse or serial communication device.
Connecting an Audio Device For higher audio quality, you can send sound through an external audio device. The combo connector is the “4-pole TRRS 3.5mm” type (Apple iPhone Recessed) so you can connect a compatible headset microphone. SAFETY WARNING: To prevent possible hearing damage, do not listen at high volume levels for long periods.
Using Smart Cards Your computer has a smart card slot. With an embedded microcontroller, smart cards have the unique ability to store large amounts of data, carry out their own on-card functions (e.g., encryption and mutual authentication), and interact intelligently with a smart card reader. To insert a smart card: 1. Locate the smart card reader. Open its protective cover by lifting up the tab of the cover. 2.
Using ExpressCards Your computer has an ExpressCard slot. The ExpressCard slot can accommodate a 54 mm (ExpressCard/54) or 34 mm (ExpressCard/34) wide ExpressCard. Typical ExpressCards support a very extensive range of applications including memory, wired and wireless communication cards, and security devices. To insert an ExpressCard: 1. Locate the ExpressCard slot. Open its protective cover by lifting up the tab of the cover. 2.
3. Open the cover. 4. Pull the card out of the slot. 5. Close the cover.
Replacing the Hard Disk Drive 1. Turn off the computer and disconnect the AC adapter. 2. Slide the cover latch toward the unlocked position ( up the tab () to release the cover. ) () and then lift 3. Using the ribbon strip, first pull the small latch toward the right to unlock () and then pull the hard disk drive out of the computer (). 4. Noting the orientation, insert the new hard disk drive all the way into the slot until the small latch clicks into place. 5.
System Memory Upgrade You can upgrade your computer by expanding system memory. CAUTION: It is not recommended that you buy and install RAM modules by yourself. If you want to expand system memory, please ask Getac service center to install DRAM modules for you so that full compatibility can be guaranteed. RAM modules are extremely sensitive to static electricity. There are cases where static electricity generated by the human body has adversely affected such modules.
4. Remove the plastic bar by unfastening two screws. 5. To install the RAM module, match the module's notched part with the socket's projected part and firmly insert the module into the socket at a 20-degree angle (). Then push down until the retaining clips lock the module into position (). CAUTION: If the RAM module is difficult to insert or difficult to push down, do not force it. Check once more to ensure that the module is positioned correctly. 6. Replace the plastic bar and secure with two screws.
Chapter 5 Using BIOS Setup BIOS Setup Utility is a program for configuring the BIOS (Basic Input/ Output System) settings of the computer. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the computer hardware can understand. The BIOS settings are needed by your computer to identify the types of installed devices and establish special features. This chapter tells you how to use the BIOS Setup Utility.
When and How to Use You need to run BIOS Setup Utility when: You see an error message on the screen requesting you to run BIOS Setup Utility. You want to restore the factory default BIOS settings. You want to modify some specific settings according to the hardware. You want to modify some specific settings to optimize the system performance. To run BIOS Setup Utility: Method 1 for Windows 8 models: Open the Charms Bar of Windows. Click Settings Change PC Settings General.
Menu Descriptions Information Menu The Information menu contains the basic configuration information of the system. There are no user-definable items in this menu. NOTE: The “Asset Tag” information appears when you have entered the asset number for this computer using the asset management program. The program is provided in the Asset tag folder of the Driver disc. Main Menu The Main menu contains the various system settings. System Date sets the system date. System Time sets the system time.
Advanced Menu The Advanced menu contains the advanced settings. Wake Up Capability Any-key Wake Up From S3 allows any key to wake up the system from S3 (Sleep) state. USB Wake-Up From S3 allow a USB device activity to wake up the system from S3 (Sleep) state. (This feature works for Windows 7 only.) AC Initiation sets if connecting AC power will automatically start or resume the system. SATA Mode set to AHCI if your hard disk supports AHCI.
DVMT Total Gfx Mem sets the amount of total graphics memory (pre-allocated + fixed + DVMT) for use by the internal graphics device. Device Configuration enables or disables several hardware components. The items available for setting depend on your model. Security Menu The Security menu contains the security settings, which safeguard your system against unauthorized use. NOTE: You can set the user password only when the supervisor password has been set.
HDD Security Status HDD 0 Password State shows whether you have set the hard disk password or not. Set HDD 0 Password sets the password for locking the Primary Master hard disk drive. After setting a password, the hard disk drive can only be unlocked by the password no matter where it is installed. TPM Setup Menu TPM Support enables or disables TPM (Trusted Platform Module) support.
Load Setup Defaults loads the factory default values for all the items. Discard Changes restores the previous values for all the items. Saves Changes saves the changes you have made.
Chapter 6 Using Getac Software Getac software includes application programs for specific computer components and utility programs for overall management. This chapter briefly describes the programs.
OSD Control Panel The OSD (On Screen Display) Control Panel provides a user-friendly interface for you to quickly activate or operate certain functions on your computer with a simple tap of the screen. To open the OSD Control Panel, start the program named OSDC. You can also press the Windows Logo button (long press if you have a Windows 8 model) on your computer to open it. The following screen appears. Help For detailed information on the program, see the program’s online help.
G-Manager G-Manager is a unified user interface utility that allows you to view, manage, or configure your computer features. With G-Manager, you can perform all or some of the tasks listed below. View system information. Check the battery status and configure the battery. Configure ECO modes (or called power profiles). View light sensor information (select models only). Set if your system will switch to the external antenna when connected to the docking station (select models only).
Help For detailed information on the program, see the program’s online help.
Getac Camera (Optional) Getac Camera is a geo-tagging camera program, which allows you to stamp geographical information on photos as watermarks and embed such information into JPEG files as EXIF 2.2 metadata. NOTE: Getac Camera works with Virtual-GPS (a separate application program). Before starting Getac Camera, close any other program that uses the camera; otherwise, Getac Camera can only provide limited functions. Start Getac Camera. The Getac Camera window appears as shown below.
Getac Smart Tag (Optional) If your model has the RFID reader/writer module, you can use Getac Smart Tag to read UID numbers from RFID tags (14443-A, 14443-B, and 15693 types). Start Getac Smart Tag. The Getac Smart Tag floating button appears and is always on top of the screen. Tap the floating button to start scanning. While scanning is in progress, the button’s color is orange. Idle Scanning To configure the program, open the options menu by tapping and holding the floating button.
Chapter 7 Caring for the Computer Taking good care of your computer will ensure a trouble-free operation and reduce the risk of damage to your computer. This chapter gives you guidelines covering areas such as protecting, storing, cleaning, and traveling.
Protecting the Computer To safeguard the integrity of your computer data as well as the computer itself, you can protect the computer in several ways as described in this section. Using an Anti-Virus Strategy You can install a virus-detecting program to monitor potential viruses that could damage your files. Using the Cable Lock You can use a Kensington-type cable lock to protect your computer against theft. The cable lock is available in computer stores.
Taking Care of the Computer Location Guidelines For optimal performance, use the computer where the recommended temperature is between 0 °C (32 °F) and 55 °C (131 °F). Actual operating temperature depends on product specifications. Avoid placing the computer in a location subject to high humidity, extreme temperatures, mechanical vibration, direct sunlight, or heavy dust. Using in extreme environments for long periods can result in product deterioration and a shortened product life.
General Guidelines Do not expose your skin to the computer when operating it in a very hot or cold environment. Do not place heavy objects on top of the computer as this may damage the display. The screen surface is easily scratched. Avoid touching it with a sharp object such as a pen or pencil. LCD image sticking occurs when a fixed pattern is displayed on the screen for a prolonged period of time. You can avoid the problem by limiting the amount of static content on the display.
Battery Pack Guidelines Recharge the battery pack when it is nearly discharged. When recharging, make sure that the battery pack is fully charged. Doing so may avoid harm to the battery pack.
– charging time will be prolonged when the computer is turned on. To shorten the charging time, it is recommended that you place the computer in Sleep or hibernation mode. – a low temperature will prolong the charging time as well as hasten the discharge time. When using battery power in an extremely low temperature environment, you may experience shortened operating time and incorrect battery level reading. This phenomenon comes from the chemical characteristics of batteries.
When Traveling Before traveling with your computer, make a backup of your hard disk data into flash disks or other storage devices. As an added precaution, bring along an extra copy of your important data. Make sure that the battery pack is fully charged. Make sure that the computer is turned off. Disconnect the AC adapter from the computer and take it with you. Use the AC adapter as the power source and as a battery-charger. Hand-carry the computer. Do not check it in as luggage.
Chapter 8 Troubleshooting computer problems can be caused by hardware, software, or both. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common computer problems.
Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: Try to isolate which part of the computer is causing the problem. Make sure that you turn on all peripheral devices before turning on the computer. If an external device has a problem, make sure that the cable connections are correct and secure. Make sure that the configuration information is properly set in the BIOS Setup program.
Solving Common Problems Battery Problems The battery does not charge (Battery Charge indicator does not light amber). Make sure that the AC adapter is properly connected. Make sure that the battery is not too hot or cold. Allow time for the battery pack to return to room temperature. If the battery doesn't charge after it has been stored in very low temperatures, try disconnecting and reconnecting the AC adapter to solve the problem. Make sure that the battery pack is installed correctly.
Make sure that the other device is not in “Hidden” mode. Make sure that both devices are compatible. Display Problems Nothing appears on the screen. During operation, the screen may automatically turn off as a result of power management. Press any key to see if the screen comes back. The brightness level might be too low. Increase the brightness. The display output might be set to an external device.
Hardware Device Problems The computer does not recognize a newly installed device. The device may not be correctly configured in the BIOS Setup program. Run the BIOS Setup program to identify the new type. Make sure if any device driver needs to be installed. (Refer to the documentation that came with the device.) Make sure if the device needs any jumper or switch settings. (Refer to the documentation that came with the device.) Check the cables or power cords for correct connections.
keyboard of your computer is spill-proof, liquid will remain in the keyboard enclosure if you don’t remove it. The touchpad does not work, or the pointer is difficult to control with the touchpad. Make sure that the touchpad is clean. LAN Problems I cannot access the network. Make sure that the LAN cable is properly connected to the RJ-45 connector and the network hub. Make sure that the network configuration is appropriate. Make sure that the user name or password is correct.
Software Problems An application program does not work correctly. Make sure that the software is correctly installed. If an error message appears on the screen, consult the software program’s documentation for further information. If you are sure the operation has stop, reset the computer. (See “Resetting the Computer” later in this chapter.) Sound Problems No sound is produced. Make sure that the volume control is not set too low. Increase the volume.
When you turn on the computer, it stops after POST. Reset your computer. (See “Resetting the computer” later in this chapter.) Wireless LAN Problems I cannot use the wireless LAN feature. Make sure that the wireless LAN feature is turned on. Transmission quality is poor. Your computer may be in an out-of-range situation. Move your computer closer to the Access Point or another wireless LAN device it is associated with.
I cannot communicate with the computer in the network when Infrastructure mode is configured. Make sure that the Access Point your computer is associated with is powered on and all the LEDs are working properly. If the operating radio channel is in poor quality, change the Access Point and all the wireless station(s) within the BSSID to another radio channel. Your computer may be in an out-of-range situation. Move your computer closer to the Access Point it is associated with.
Resetting the Computer You may have to reset (reboot) your computer on some occasions when an error occurs and the program you are using hangs up. If you are sure the operation has stopped and you cannot use the “restart” function of the operating system, reset the computer. Reset the computer by any one of these methods: Press Ctrl+Alt+Del on the keyboard. Or press and hold the P1 button for more than 2 seconds. This opens the Ctrl-Alt-Del screen where you can select actions including Restart.
System Recovery System Restore, Refresh, or Reset (for Windows 8 Models) If you're having problems with your Windows 8 computer, you can try to restore, refresh, or reset it. To restore your computer to an earlier point in time: 1. Enter Recovery in the search box. 2. Tap Settings, and then tap Recovery. 3. Tap Open System Restore. To refresh your computer without affecting your files: 1. Open the Charms Bar of Windows. 2. Tap Settings Change PC Settings General. 3.
System Recovery (a Tool for Windows 7 Models) Use System Recovery when: The Windows 7 operating system does not start at all. You want to restore the system to the factory state. WARNING: Using this feature will reinstall Windows to your system and configure it to the system’s factory default settings. All data on the hard disk drive will be lost. Make sure that power is not interrupted during the recovery process. An unsuccessful recovery may result in Windows startup problems.
5. The progress bar shows the percentage completed. When it reaches 100%, the system turns off. 6. Turn on the computer. The Windows setup wizard starts. Follow the onscreen prompts to continue. 7. When the system restarts, the installer screen appears. The installer will perform system hardware detection and driver installation. 8. When completed, the system restarts and displays Windows desktop.
Appendix A Specifications NOTE: Specifications are subject to change without any prior notice. Parts Specifications CPU Haswell Intel® Core™ i3/i5/i7 processor BIOS Phoenix, Flash EEPROM, supporting UEFI, NIST, ACPI, and TPM RAM 4GB/8GB DDR3L 1600MHz SO-DIMM Video Controller UMA - Intel® GT2 Display Panel 11.6-inch (16:9) TFT LCD, HD 1366x768 or FHD 1920x1080, sunlight readable, 800 Nits maximum brightness Audio Features Azalia, High Definition audio Speaker 1.
Parts Specifications LAN 10/100/1000 Mbps Ethernet Wireless LAN + BT IEEE 802.11ac, compatible with 802.11a/b/g/n, BT 4.0 + EDR GPS (option) NMEA0183 WWAN (option) 3G/4G LTE Camera (option) Front: HD Rear: 5M pixel, autofocus, LED, video capture RFID Reader (option) Contactless, UART, supporting ISO14443A/B and 15693 Security Kensington lock TPM 1.
Appendix B Regulatory Information This appendix provides regulatory statements and safety notices on your computer. NOTE: Marking labels located on the exterior of your computer indicate the regulations that your model complies with. Please check the marking labels and refer to the corresponding statements in this appendix. Some notices apply to specific models only.
On the Use of the System Class B Regulations USA Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur.
Safety Notices About the Battery Caution Texts Concerning Lithium Batteries DANISH ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. NORWEGIAN ADVARSEL: Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten. Brukte batterier kasseres i henhold til fabrikantens instruksjoner.
type équivalent recommandé par le constructeur. Mettre au rebut les batteries usagées conformément aux instructions du fabricant. Attention (for USA Users) The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under various state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local solid waste officials for details in your area for recycling options or proper disposal.
On the Use of the RF Device USA and Canada Safety Requirements and Notices IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Radio Frequency Interference Requirements and SAR This device meets the government’s requirements for exposure to radio waves.
environment. However, there is no guarantee that interference will not occur in a particular commercial installation, or if operated in a residential area. If harmful interference with radio or television reception occurs when the device is turned on, the user must correct the situation at the user’s own expense. The user is encouraged to try one or more of the following corrective measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.
European Union CE Marking and Compliance Notices Statements of Compliance English This product follows the provisions of the European Directive 1999/5/EC. Danish Dette produkt er i overensstemmelse med det europæiske direktiv 1999/5/EC. Dutch Dit product is in navolging van de bepalingen van Europees Directief 1999/5/EC. Finnish Tämä tuote noudattaa EU-direktiivin 1999/5/EC määräyksiä. French Ce produit est conforme aux exigences de la Directive Européenne 1999/5/EC.
Portuguese Este produto cumpre com as normas da Diretiva Européia 1999/5/EC. Spanish Este producto cumple con las normas del Directivo Europeo 1999/5/EC. Swedish Denna produkt har tillverkats i enlighet med EG-direktiv 1999/5/EC. Restrictions This device is restricted to indoor use when operating in the 5150 to 5350 MHz frequency range.
