Instructions / Assembly

6” Spike Nail
Notch
INSTALLATION INSTRUCTIONS
FOR MODEL CC-5R
COMPONENTS:
1 - 6ʼ 4” Upright
1 - 20” Crosspiece
1 - 12” Angle Brace
1 - 6” Spike Nail
4 - 3” Galvanized Finish Nails
1 - Red Aromatic Cedar 4ʼ x 4ʼ post,
cut and notched for easy assembly
1. SEPARATE COMPONENTS AND ATTACH CROSSPIECE TO UPRIGHT
-Fit into notch already cut in upright.
-Prop bottom end of upright on an object 8” to 30” high or have someone hold it up.
-Place upright notch face down on square end of crosspiece and drive nail through backside of
upright into crosspiece.
2. ATTACH ANGLE BRACE TO UPRIGHT AND CROSSPIECE
3” Galv. Finish Nails
- Rest post on flat surface with crosspiece pointing upward.
3. SET POST IN GROUND AND ATTACH MAILBOX
(MOUNTING BOARD OR SOUTHERN GEMINI MOUNTING BRACKETS SHOULD BE USED)
-Bury post in ground so that top of crosspiece (bottom of mailbox)
complies to the height above ground specified by your carrier.
(Suggested height 38” - 40”).
- Screw or nail mounting board or mounting brackets to top of
crosspiece.
-Screw or nail mailbox to mounting board or mounting brackets.
