Installation Manual

- 2 -
Chip  Intel
®
DSL7540 Thunderbolt
™
3 Controller
Back Panel
Connectors
 1 x DisplayPort, supporting a maximum resolution of 8K
(7680x3840)@60 Hz
(Note 1) (Note 2)
* Support for DisplayPort 1.4 version, HDCP 2.2, and HDR.
 2 x Thunderbolt
™
3 out ports (Thunderbolt
™
3 Port 1/Thunderbolt
™
3 Port 2), supporting up to 40 Gbps bandwidth and a maximum
display resolution of 8K (7680x3840)@60 Hz
(Note 1) (Note 2)
 2 x Mini-DisplayPort In ports (DP_IN1/DP_IN2)
Internal
Connectors
 2 x 6-pin PCIe power connectors
 1 x USB 2.0/1.1 header
 1 x 5-pin Thunderbolt
™
header
 1 x 3-pin Thunderbolt
™
header
Interface  PCIe 3.0 interface (PCIe x4)
Data Transfer
Rate
 40 Gbps Bi-directional per port
Supported
Operating Systems
 Support for Windows 10 (64-bit) with RS3 or later
Compatible
Motherboards
 Go to GIGABYTE’s website for the latest motherboard support list.
Product Specication
(Note 1) Actual resolutions supported are dependent on the graphics card being used.
(Note 2) Due to hardware limitations, the DisplayPort connector, Thunderbolt
™
3 connector 1, and
Thunderbolt
™
3 connector 2 require signal input from external devices and support up to
two display outputs at a time.
