Training Gym Pro Instruction Manual Version 1.1 The instruction manual uses for Training Gym Pro version 1.2.9 or later.
Software Instruction Manual Table of Content 1. How to Install PC Software Application ...................................................................... 3 1.1 Installing the USB driver ................................................................................................................... 3 1.2 Installing the Training Gym Pro......................................................................................................... 5 2.Running GS-Sport Training Gym Pro Application............
Software Instruction Manual 1. How to Install PC Software Application 1.1 Installing the USB driver You can also download the USB driver from our official website: www.globalsat.com.tw For GH-625: The USB driver is required to recognize your device via USB when it is connected to your PC. 1. Insert the CD into the CD-ROM drive, and the Auto-run will begin. 2. Select the appropriated driver base on your system to install driver to your PC. 3.
Software Instruction Manual Step 3: The USB driver installation has been accomplished.
Software Instruction Manual To check Computer Management＞Device Manager, you may see the STM Virtual COM port has been detected. 1.2 Installing the Training Gym Pro Install Framework v2.0 or above To check the Microsoft Framework version in your system go to: ’’Control Panel > Add/Remove Programs’’ Note: Originally, the Framework version in Windows XP SP2, SP3 and Vista or above should be version 2.0.
Software Instruction Manual Step 2 : Choose language Step 3 : Press ’’OK’’ Step 4 : Press ’’Install’’ Page 6
Software Instruction Manual Step 5: Installation process and press ‘‘close’’ to enter the Training Gym Pro application. Step 6 The software will execute and connect the database automatically.
Software Instruction Manual Step 7: Create a user account and select model. Note: Please base on your device type to select Model before use. Step 8 : The process bar will detect connection via the USB cable.
Software Instruction Manual 2. Running GS-Sport Training Gym Pro Application You can run the GS-Sport Training Gym Pro by double clicking on the " GS-Sport Training Gym Pro " short-cut icon from desktop. Or go to Start > All Programs > GlobalSat GS-Sport > GS-Sport Training Gym Pro. 3. PC Software Application Introduction 3.1 System Requirement For better performance, the following system requirements are recommended for GS-Sport Training Gym Pro: CPU: Pentium III Processor or higher.
Software Instruction Manual At least 512 MB of RAM Windows XP, Vista or higher. Internet Explorer 6.0 or higher Framework 2.0 or higher 3.2 How to Create/Login Software You should have been prompted to create a user name when you installed the software Login GS-Sport Training Gym Pro software Note: 1. You can create other user names to login and import backup database as well. 2.
Software Instruction Manual 3.3 Section Description of Training Gym Pro 3 1 5 4 2 6 No. 1 3.
Software Instruction Manual Attitude graph Speed graph Heart rate graph 4 Statistics Analysis Chart Cadence graph Power graph Smooth curve Time / Distance base 5 Google Maps (satellite, terrain, hybrid) Maps Open Street Map (Cycle, Mapnik, Osmarender) 6 Training Records Information 3.4 Menu Structure of Training Gym Pro item 3.
Software Instruction Manual Download from device Track Points Upload to device Delete all from device Download from device Data Transmission Way Points Upload to device Delete all from device Routes Upload to Device Delete all from Device Com port Setting Device Com port setting Device Configuration Edit or modify your device information.
Software Instruction Manual 4. PC Software Application 4.1 Main Menu 4.1-1 Import Activity In GS-Sport Training Gym Pro, click [Main] > [Import Activity] You can import any serial of GSsport Training Gym to Training Gym Pro software Select the .act file of training data and then click’’ Open’’ Will pop a message when activity information be loaded successfully.
Software Instruction Manual 4.1-2 Export Activity In GS-Sport Training Gym Pro, click [Main] > [Export Activity] Choose a training file you want to save name it on note column. To Save it.
Software Instruction Manual Will pop a message to let you know the file name and file be saved. 4.1-3 Capture Google Map Capture current Google map window and save it as JPG format 4.1-4 Show on Google Map Show the trained information on Google map directly. 4.1-5 Show on Google Earth Show the training data on Google earth directly (please download google earth in advance) 4.1-6 Log Out You can log application out and change other username to login. 4.
Software Instruction Manual 4.2 File Menu 4.2-1 Open Choose the several kind of log file you want to load into Training Gym Pro software besides, it supports KML, GPX, CSV, NMEA, TXT format. 4.2-2 Save Choose the file from data base you want to save it. Right now it supports KML, GPX, CSV, NMEA, TXT format. 4.3 Search Menu 4.3-1 Search by date Check ‘’search by date ‘’ and select the period of date to get completely training information. 4.
Software Instruction Manual 4.4 Planning Menu 4.4-1 Way Points You can plan your waypoints or finding somewhere through Way Points. Please enter an address or a name then press search (optional). Press Add Waypoint and add a waypoint on Google map.
Software Instruction Manual Add the waypoint on Google map then name it (limitation 6 characters) and save it. And the map will show every waypoint you just added. When waypoint saving is finished, you will see all waypoints on top column. Then, you can select waypoints you need and go to [Data Transmission] > [Way Points] > [Upload to Device] to upload waypoints to your device. (Please see 4.5-2 Way Points for details.
Software Instruction Manual 4.4-2 Routes You can plan your routes and upload to your device through Routes. Please enter an address or a name then press search (optional). Press Start Route and add the first waypoint on Google map.
Software Instruction Manual Keep adding waypoints on Google map for the route. When you finish routing, please press End Route. Name the route and save it. And your waypoints information will be shown on top column.
Software Instruction Manual When route saving is finished, you will see the route on left bottom of column. Then, you can go to [Data Transmission] > [Routes] > [Upload to Device] to upload the route to your device. (Please see 4.5-3 Routes for details.
Software Instruction Manual 4.5 Data Transmission Menu 4.5-1 Track Point 4.5-1.1 Download from device When you click [Data Transmission] > [Track Point] > [Download from device], the system will search device and the progress bar shows as below List of training data will show and you can select which training data to download.
Software Instruction Manual Training data and statistics will show on left column after downloaded from device 4.5-1.2 Upload to device You can click [Data Transmission] > [Track Point] > [Upload to device] and select the training data on left bottom of column to transfer to device.
Software Instruction Manual 4.5-1.3 Delete all from device When you click [Data Transmission] > [Track Points] > [Delete all from device] will pop a message to double confirm as are you sure you want to delete all Track Record from device.
Software Instruction Manual Start to delete all training data from device All Track Records deleted successfully from the device. 4.5-2 Way points 4.5-2.1 Download from device You can click [Data Transmission] > [Waypoint] > [Download from device], to download waypoints from device to PC Software. All list of waypoint will transmit directly and show on the top column.
Software Instruction Manual 4.5-2.2 Upload to device You can click [Data Transmission] > [Waypoint] > [Upload to Device] to transfer waypoints from PC Software to device. Select the waypoint you want to transmit to device.
Software Instruction Manual Uploading waypoint completed successfully when finished. 4.5-2.3 Delete all from device You can click [Data Transmission] > [Waypoint] > [Delete all from device] to delete the all waypoints of device. 4.5-3 Routes 4.5-3.1 Upload to device You can click [Data Transmission] > [Routes] > [Upload to device] and select the training data on left bottom of column to transfer to device.
Software Instruction Manual 4.5-3.2 Delete all from device When you click [Data Transmission] > [Routes] > [Delete all from device] will pop a message to double confirm as are you sure you want to delete all Route Records from device.
Software Instruction Manual All Routes deleted successfully from the device. 4.6 Configuration Menu 4.6-1 Com Port Setting You can scan COM port to build synchronization between device and computer. Please scan the comport before your start uploading or download data to device Comport scan finished 4.6-2 Device Configuration The application will retrieve device information and all configurations. And you also can configure them.
Software Instruction Manual Note: There is something difference of configuration items base on different Model. 4.6-3 Firmware Upgrade You can update your firmware of device by using this item. Click ’’Browse’’ to select the latest firmware file (*.ghx) to upgrade.
Software Instruction Manual Press Update to get new firmware Step :2 Are you sure you want to update device, you will lose all device data , Press OK (If you need to save old data in device, please save it before you update new firmware.) 4.6-4 Unit Exchange You can change the expression between Speed(Dist/Hr) and Pace(Min/Dist). There are three measurement units for selection.
Software Instruction Manual 4.6-5 Language There are English, Chinese, Spanish, German, Italian, French, Japanese and Russian languages for selection. Once you chose a language, the Training Gym Pro will change accordingly. 4.7 Overlay To get comparison with multiple records, you can use Overlay to get start. Click Overlay to active the control window and select data folder you interest to make comparison. And you can make a comparison in Time base or Distance base.
Software Instruction Manual 4.8 Help Menu 4.8-1 About GS-Sport You will see the version of Training Gym Pro. 4.8-2 About Us Will connect to GS-Sport website directly: www.gs-sport.com.tw 5. Map types There are two main popular webpage instant Map available in Training Gym Pro software. Google map and Open Street Map which includes Cycle map, Mapnik map, Osmarender Map: 5.
Software Instruction Manual 5.2 Satellite Map (Google Map) 5.3 Terrain Map (Google Map) 5.
Software Instruction Manual 5.5 Cycle Map (Open Street Map) 5.6 Mapnik Map (Open Street Map) 5.
Software Instruction Manual 6. Troubleshooting & FAQ 1. Why does it show “PC com port error” when I download data? Solution: (1). Please check if the USB driver is installed or not. (2). Please check the USB driver supports your system or not. (3). Connect to your PC with the USB cable. (4). Double click the “GS-Sport Training GYM Pro” icon from desktop to start the application. (5). From menu bar click “Configurations”, and click “Scan COM Port” button. COM port will be automatically scanned. 2.
Software Instruction Manual item 3.
Software Instruction Manual FCC RF Exposure requirements: This device and its antenna(s) must not be co-located or operation in conjunction with any other antenna or transmitter. NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
