METRAHIT⏐ISO
TRMS Multimeter with Insulation Measurement
Technical Data
1
15 ... 45 ... 65 Hz ... 10 (5) kHz sine. See page 6 regarding influence
2
At 0° ... + 40° C
3
Display of up to max. 5.1 V, “OL” in excess of 5.1 V.
4
Applies to measurements at film capacitors
5
Lowest measurable frequency for sinusoidal measuring signals symmetrical to the
zero point
6
Overload capacity of the voltage measurement input:
power limiting: frequency x voltage max. 3 x 10
6
V x Hz at > 100 V
7
Overload capacity of the current measurement input:
See current measuring ranges for maximum current values.
8
Input sensitivity, sinusoidal signal, 10% to 100% of voltage or current measuring
range; limitation: up to 30% of the range at up to 100 kHz in the mV measuring
range., 30% of the range in the 3 A measuring range
The voltage measuring ranges with max. 30 kHz apply in the A measuring range.
9
Plus sensor deviation
10
With ZERO function active
11
With short circuited terminal tips
Exception: residual value of 1 to 10 digits,
in the mV/μA range
1 to 35 d
at zero point due to the TRMS converter
12
10 minute cool-down period
Key: d = digit(s), MR = measuring range, rdg. = reading
Meas.
Func-
tion
(input)
Measuring Range
Resolution at
Upper Range
Limit
Input Impedance
Intrinsic Error
under Reference Conditions
Overload
Capacity
2
±(... % rdg. + ... d) ±(... % rdg. + ... d) ±(... % rdg. + ... d)
~ /
~
1, 11 1, 11
Value Time
V
300.0 mV 100 μV9MΩ 9MΩ // < 50 pF 0.2 + 3
10
1 + 3 (> 100 d) 1.5 + 5 (> 100 d)
1000 V
DC
AC
RMS
Sine
6
Cont.
3.000 V 1 mV 9 MΩ 9MΩ // < 50 pF 0.15 + 2
1 + 3 (> 30 d) 1.5 + 5 (> 100 d)
30.00 V 10 mV 9 MΩ 9MΩ // < 50 pF 0.15 + 2
300.0 V 100 mV 9 MΩ 9MΩ // < 50 pF 0.15 + 2
1000 V 1 V 9 MΩ 9MΩ // < 50 pF 0.2 + 2
Voltage drop at approx. range limit
~
1, 11 1, 11
A
300.0 μA 100 nA 18 mV 18 mV 0.5 + 5 1.5 + 5 (> 100 d) 1.5 + 5 (> 100 d)
0.3 A Cont.
3.000 mA 1 μA 160 mV 160 mV 0.2 + 3
1.5 + 5 (> 30 d) 1.5 + 5 (> 100 d)
30.00 mA 10 μA 32 mV 32 mV 0.5 + 3
300.0 mA 100 μA 200 mV 200 mV 0.2 + 3
3.000 A 1 mA 120 mV 120 mV 1 + 5
10 A 5 min
12
10.00 A 10 mA 400 mV 400 mV 1 + 5
Factor: 1:1/10/100/1000
Input Input impedance
~
1, 11 1, 11
A
@ A
0.03, 0.3, 3, 30 A 30 mA
Current measurement input
(jack A~)
— 1.5 + 5 (> 100 d) — 0.3 A Cont.
0.3, 3, 30, 300 A 300 mA
3, 30, 300, 3 k A 3 A Plus clip-on current transformer error 3 A 5 min.
A
@ V
0.3, 3, 30, 300 A 300 mV
Voltage measurement input approx. 9 MΩ
(V socket)
0.5 + 3
1.5 + 3 (> 300 d) 1.5 + 5 (> 300 d) Meas. input
6
:
3, 30, 300, 3 k A 3 V 1.5 + 3 (> 30 d) 1.5 + 5 (> 100 d)
1000 V
RMS
Max. 10 s
30, 300, 3k, 30k A 30 V Plus clip-on current sensor error
Open-circuit
voltage
Meas. current at
range limit
±(... % rdg. + ... d)
Ω
300.0 Ω 100 mΩ < 1.4 V Approx. 300 μA 0.5 + 3 with ZERO function active
1000 V
DC
AC
RMS
Sine
Max. 10 s
3.000 kΩ 1 Ω < 1.4 V Approx. 200 μA 0.5 + 2
30.00 kΩ 10 Ω < 1.4 V Approx. 30 μA 0.5 + 2
300.0 kΩ 100 Ω < 1.4 V Approx. 3 μA 0.5 + 2
3.000 MΩ 1kΩ < 1.4 V Approx. 3 μA 0.5 + 2
30.00 MΩ 10 kΩ < 1.4 V Approx. 33 nA 2.0 + 5
300.0 Ω 100 mΩ Approx. 10 V
Approx. 1 mA const.
2 + 5
5.1 V
3
1 mV Approx. 10 V 2 + 5
Discharge resist. U
0 max
±(... % rdg. + ... d)
F
30.00 nF 10 pF 10 MΩ 0.7 V 1 + 6
4
with ZERO function active
1000 V
DC
AC
RMS
Sine
Max. 10 s
300.0 nF 100 pF 1 MΩ 0.7 V 1 + 6
4)
3.000 μF 1 nF 100 kΩ 0.7 V 1 + 6
4)
30.00 μF10nF 12kΩ 0.7 V 1 + 6
4)
300.0 μF 100 nF 3 kΩ 0.7 V 5 + 6
4)
f
min
5
±(... % rdg. + ... d)
Hz (V)/
Hz (A)
Hz (A
300.0 Hz 0.1 Hz
1Hz
0.1 + 2
8
Hz (V)
6
:
Hz(A )
6
:
1000 V
Hz (A):
7
Max. 10 s
3.000 kHz 1 Hz
30.00 kHz 10 Hz 10 Hz
Hz (V)
300.0 kHz 100 Hz 100 Hz
±(... % rdg. + ... d)
9
°C
Pt100
– 200.0 ...
+850.0° C
0.1 °C
0.5% + 15
1000 V
DC/AC
RMS
Sine
Max. 10 sPt1000
– 150.0 ...
+850.0° C
0.5% + 15
K
(NiCr-Ni)
– 250.0 ...
+1372.0° C
1% + 5 K
