Use and Care Manual

13
Audio/Video Input
Requires a 3.5mm to 3 x RCA audio/video adapter (included) and a RCA audio/video cable (not included).
1. Connect the 3.5mm to 3 x RCA audio/video adapter to the AV input on the unit.
2. Connect the 3.5mm to 3 x RCA audio/video adapter to an RCA audio/video cable (not included), then connect
that RCA audio/video cable to the RCA stereo audio outputs and composite video output on the media player.
3. Set the projector's Source to AV IN and use the controls on the connected player to select and play media.
USB
HDMI IN
AV IN
VGA IN
AUDIO
OUT
Connect AV cable (not included)
to source's AV outputs
Video - Yellow
Audio Left Channel - White
Audio Right Channel - Red
Connect included adapter
to source's AV cable
AV IN
Connecting to Other Devices
