Specifications

Job Name: Job Type:
Comments: Quantity:
** By typing in the gray boxes above you can populate this form before printing.
** To save this document click on the logo above. A pdf document of this Specification Sheet will be created that can be saved locally.
Dimensions:
Length: 17"
Width: 17''
Height: 22 3/8''
Weight: 8.6 lbs.
Overall Height: 80''
Wire: 180'' (color/Black)
Mounting Proc.: Screw Collar -
Stem
Connection: Mounted To Box
Bulbs:
4 - LED Candelabra Torpedo 3.5w Max. 120v - included
Features:
ENERGY STAR® Qualified
LED Bulbs are an efficient, versatile and durable light source that
deliver exceptional performance.
Meets Title 24 energy efficiency standards
Title 24 compliant when used with included Joint Appendix (JA8)
approved lamp.
Material List:
1 Body - Steel - Iron Oxide
1 6" Stem - Steel - Iron Oxide
4 12" Stem - Steel - Iron Oxide
Safety Listing:
Safety Listed for Damp Locations
Instruction Sheets:
Backplate / Canopy Details:
Type Height / Length Width Depth Diameter Outlet Box Up Outlet Box Down
Canopy 1 1/8 5
Replacement Bulb Data:
Product #
Type Base Watts Watts Consumed Volts Hours Lumens Temp (°K) CRI
LTB10C35027CB Clear
Glass
Lens
Torpedo E12
Candelabra
3.5 3.5 120v 25000 350 2700 90
Shipping Information:
Medium Four Light Hall / Foyer
English
Package Type Quantity Length Width Height Cube Weight Frt. Class UPS Ship
Individual 1 25 19.5 19.5 5.501 17.3 250 Yes
Finish: Iron Oxide (IO)
