H-Series Catwalk Installation Supplement for GSI Bins Built with Stiffeners Instruction Manual PNEG-1744 Date: 05-21-10 PNEG-1744
PNEG-1744 H-Series Catwalk Installation
Table of Contents Contents Chapter 1 Introduction ..........................................................................................................................................4 Chapter 2 Dryer Dimensions, Stiffener and Catwalk Locations ........................................................................6 Catwalk Support Assembly at Stiffener ................................................................................................. 6 Dryer Catwalk Layouts ...........................
1. Introduction Please note that the original catwalk installation instructions (included in CATM-01-5 and CATH-01-5) were written for Farm Fans (FFI) dryers supported with buttresses. This supplement contains catwalk installation instructions for dryers built with “stiffeners”. Please follow this supplement when installing a catwalk on a dryer with stiffeners. You will be referred back to the original manual when necessary.
NOTES PNEG-1744 H-Series Catwalk Installation 5
2. Dryer Dimensions, Stiffener and Catwalk Locations Catwalk Support Assembly at Stiffener Hardware to attach to stiffener can be at a different location than shown.
2.
2.
PNEG-1744 H-Series Catwalk Installation Figure 2G on Page 13 Figure 2G on Page 13 Figure 2H on Page 13 Figure 2H on Page 13 Figure 2G on Page 13 Figure 2H on Page 13 Figure 2H on Page 13 Figure 2G on Page 13 Figure 2G on Page 13 Figure 2G on Page 13 2.
Figure 2G on Page 13 Figure 2G on Page 13 Figure 2H on Page 13 Figure 2H on Page 13 Figure 2G on Page 13 Figure 2G on Page 13 Figure 2H on Page 13 Figure 2G on Page 13 Figure 2G on Page 13 Figure 2H on Page 13 2.
PNEG-1744 H-Series Catwalk Installation Figure 2I on Page 14 Figure 2I on Page 14 Figure 2G on Page 13 Figure 2H on Page 13 Figure 2G on Page 13 Figure 2H on Page 13 Figure 2G on Page 13 Figure 2G on Page 13 Figure 2G on Page 13 Figure 2H on Page 13 Figure 2H on Page 13 Figure 2G on Page 13 2.
2.
2.
2.
2.
2. Dryer Dimensions, Stiffener and Catwalk Locations Catwalk Locations Middle Module Location Figure 2J Location of Catwalk for Middle Module Middle Module Location Parts List Ref # 16 Part # Description Qty 1 SS-692308 9-5 Gauge 2 Ring 1 2 SS-7053 N.S.
2. Dryer Dimensions, Stiffener and Catwalk Locations Top Module Location Figure 2K Location of Catwalk for Top Module Top Module Location Parts List Ref # Part # Description Qty 1 SS-692308 9-5 Gauge 2 Ring 1 2 SS-7053 N.S.
3. Installation Instructions For Step 1, please refer to the instructions included in the original manual. Follow Step 2 in this supplement. Then, return to the original manual for Steps 4-8. (Step 3 in the original manual is obsolete for dryers without buttresses.) Step 2: Build catwalk support assemblies (part numbers: D04-0499, D01-2425 and D01-2437).
