PRODUCT OVERVIEW
Feature Highlights
The following table contains the major features of the GSC3610/GSC3615:
Table 1: GSC3610/GSC3615 Features in a Glance
GSC3610/GSC3615 Technical Specifications
The following table resumes all the technical specifications including the protocols / standards supported,
voice codecs, telephony features, languages and upgrade/provisioning settings for GSC3610/GSC3615.
Table 2: GSC3610/GSC3615 Technical Specifications
Network Protocol
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS
(A record, SRV, NAPTR), DHCP, SSH, TFTP, NTP, STUN, SIMPLE,
LLDP-MED, 802.1x, TLS, SRTP
Image Sensor Resolution
1/2.9” CMOS Sensor, 1920(H)*1080(V)
Video Compression
H.264/H.265/JPEG/MJPEG
Supported Maximum Video
Resolution and Frame Rate
Primary Stream:1920*1080
Secondary Stream: 640*480
Video Output
Network
Audio
1 x 3.5mm Line-In Port; 1 x 3.5mm Line-Out Port
GSC3610
GSC3615
• Motion detection
• Smart infrared technology for optimal white balance and exposure
• Built-in PoE to power the device and provide a network connection
• Alert notifications via outbound voice or video call & email screenshot
• IP66-level weatherproof capability
• Primary stream 1920x1080 and Secondary stream 640x480
• SIP/VoIP support for video and audio streaming to endpoints (external
microphone required)
