Grandstream Networks, Inc.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 Administration Guide
GXP2130/GXP2140/GXP2160/GXP2170 Administration Guide Table of Content DOCUMENT PURPOSE............................................................................. 4 GUI INTERFACE EXAMPLES .................................................................... 5 GNU GPL INFORMATION .......................................................................... 6 CHANGE LOG ........................................................................................... 7 FIRMWARE VERSION 1.0.5.23 ........................
ACCOUNTS PAGE DEFINITIONS ............................................................................................... 32 SETTINGS PAGE DEFINITIONS ................................................................................................. 43 NETWORK PAGE DEFINITIONS ................................................................................................. 59 MAINTENANCE PAGE DEFINITIONS .........................................................................................
Table of Tables GXP2130/GXP2140/GXP2160/GXP2170 User Manual Table 1: GXP2130/GXP2140/GXP2160/GXP2170 FEATURES IN A GLANCE ......................................... 13 Table 2: GXP2130/GXP2140/GXP2160/GXP2170 COMPARISON GUIDE ............................................... 14 Table 3: GXP2130 TECHNICAL SPECIFICATIONS ................................................................................... 15 Table 4: GXP2140 TECHNICAL SPECIFICATIONS .................................................................
DOCUMENT PURPOSE This document describes how to configure GXP2130/GXP2140/GXP2160/GXP2170 features via phone’s LCD menu and Web GUI menu. The intended audiences of this document are phone administrators. To learn the basic functions http://www.grandstream.com/support of GXP2130/GXP2140/GXP2160, please visit to download the latest “GXP2130/GXP2140/GXP2160/GXP2170 End User Guide”.
GUI INTERFACE EXAMPLES http://www.grandstream.com/sites/default/files/Resources/gxp2130_2140_2160_web_gui.zip 1. Screenshot of Login Page 2. Screenshots of Status Pages 3. Screenshots of Accounts Pages 4. Screenshots of Settings Pages 5. Screenshots of Network Pages 6. Screenshots of Maintenance Pages 7.
GNU GPL INFORMATION GXP2130/GXP2140/GXP2160/GXP2170 firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license. Grandstream GNU GPL related source code can be downloaded from Grandstream web site from: http://www.grandstream.com/sites/default/files/Resources/gxp_gpl_color.tar.
CHANGE LOG This section documents significant changes from previous versions of user manuals for GXP2130/GXP2140/GXP2160/GXP2170. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. FIRMWARE VERSION 1.0.5.23 Updated logo for web UI FIRMWARE VERSION 1.0.5.18 Added more features descriptions for the MPKs mode – Monitored Call Park and Call Park sections.
Added option to download local call recordings. [SETTINGS PAGE DEFINITIONS] Added option to configure the color and pattern of the LED based on status updates. [SETTINGS PAGE DEFINITIONS] Added function to allow configuration of MPK or Line key to provide MWI for other extension. [SETTINGS PAGE DEFINITIONS] Added function to allow configuration of Call Log for other extension. [SETTINGS PAGE DEFINITIONS] Added MPK mode Monitored Call Park for other extension.
downloading. [PHONEBOOK PAGE DEFINITIONS] Added option to enable/disable the dial plan check while dialing through the call history and any phonebook directories. [SETTINGS PAGE DEFINITIONS] Added option to enable/disable the busy tone heard in the handset when call is disconnected remotely. [SETTINGS PAGE DEFINITIONS] Added XML Application support. [SETTINGS PAGE DEFINITIONS] Added Direct IP Call support on MPK and Phonebook.
Added Configuration file upload support via Web UI. [MAINTENANCE PAGE DEFINITIONS] Add Screen saver support. [SETTINGS PAGE DEFINITIONS] Add Wallpaper support. [WALLPAPER] Add the support of STAR key keypad lock feature. [MAINTENANCE PAGE DEFINITIONS] Add the support of Configuration via Keypad Menu. [MAINTENANCE PAGE DEFINITIONS] Add Keypad shortcut to reboot and provisioning. [SHORTCUT OF UPGRADE AND PROVISION VIA KEYPAD MENU] GXP2130 FIRMWARE VERSION 1.0.1.
WELCOME Thank you for purchasing Grandstream GXP2130/GXP2140/GXP2160/GXP2170 Enterprise IP Phone. GXP2130/GXP2140/GXP2160/GXP2170 is a state-of-the-art enterprise grade IP phone. GXP2170 features 12 dual-color line keys(can be digitally programmed as up to 48 provisionable BLF/fast-dial keys). GXP2140/GXP2160/GXP2170 features 4.3 inch TFT Color LCD, 5 programmable context-sensitive soft keys, dual Gigabit network ports, integrated PoE and Bluetooth, 5-way conference, and Electronic Hook Switch (EHS).
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 12 of 87
PRODUCT OVERVIEW FEATURE HIGHLIGHTS Table 1: GXP2130/GXP2140/GXP2160/GXP2170 FEATURES IN A GLANCE GXP2130 GXP2140 GXP2160 GXP2170 3 lines 2.8 inch (320x240) TFT color LCD 4 programmable soft keys Bluetooth V2.1 (GXP2130v2 only) 8 programmable Multi-Purpose Keys 4-way conference 4 lines 4.3 inch (480x272) TFT color LCD 5 programmable soft keys Bluetooth V2.1 5-way conference Expansion board 6 lines 4.
Table 2: GXP2130/GXP2140/GXP2160/GXP2170 COMPARISON GUIDE Features LCD Display LCD Backlight Number of Lines Programmable Hard Keys Programmable Soft Keys Extension Module GXP2130 GXP2140 GXP2160 GXP2170 320x240 480 x 272 480 x 272 480 x 272 Yes Yes Yes Yes 3 4 6 6 8 N/A 24 12 4 5 5 5 N/A Yes, up to 4 EXT Boards GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE N/A Yes, up to 4 EXT Boards Page 14 of 87
GXP2130/GXP2140/GXP2160/GXP2170 TECHNICAL SPECIFICATIONS Table 3: GXP2130 TECHNICAL SPECIFICATIONS Protocols/Standards SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR-069, 802.1x, TLS, SRTP, IPv6 Network Interfaces Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with integrated PoE Graphic Display 2.8 inch (320x240) TFT color LCD Bluetooth Yes, Bluetooth V2.
Energy Efficiency Input: 100-240VAC; Output: +12VDC, 0.5A (6W) Integrated PoE (Power-over-Ethernet) 802.3af, Class 2 Physical Dimension: 193mm (W) x 211mm (L) x 85 mm (H); Unit weight: 0.81kg ; Temperature and Package weight: 1.
Mountable QoS Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS Security User and administrator level passwords, MD5 and MD5-sess based authentication, AES based secure configuration file, SRTP, TLS, 802.
Auxiliary Ports RJ9 headset jack (allowing EHS with Plantronics headsets), USB Telephony Features Hold, transfer, forward, 5-way conference, call park, call pickup, shared-call-appearance (SCA)/bridged-line-appearance (BLA), downloadable phonebook (XML, LDAP, up to 2000 items), call waiting, call log (up to 500 records), customization of screen, off-hook auto dial, auto answer, click-to-dial, flexible dial plan, hot desking, personalized music ringtones and music on hold, server redundancy and f
Network Interfaces Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with integrated PoE Graphic Display 4.3 inch (480x272) TFT color LCD Bluetooth Yes, Bluetooth V2.
GXP2200EXTs ) Physical Dimention: 228mm (W) x 206mm (L) x 46.5mm (H); Unit weight: 0.98kg; Package weight: 1.
CONFIGURATION GUIDE The GXP2130/GXP2140/GXP2160/GXP2170 can be configured via two ways: LCD Configuration Menu using the phone's keypad; Web GUI embedded on the phone using PC's web browser. CONFIGURATION VIA KEYPAD To configure the LCD menu using phone's keypad, follow the instructions below: Enter MENU options. When the phone is in idle, press the round MENU button to enter the configuration menu; Navigate in the menu options.
Press to enter the sub menu for MAC address, IP setting information (DHCP/Static IP/PPPoE), IPv4 address, IPv6 address, Subnet Mask, Gateway and DNS server. System Information Press to enter the sub menu for Hardware version, P/N number. Boot, Core, Base, Prog version and IP Geographic Information.
o Active LCD Brightness Adjusts active LCD brightness by pressing left/right arrow key o Idle LCD Brightness Adjusts idle LCD brightness by pressing left/right arrow key o Screensaver Enable/Disable Screensaver o Screensaver Timeout Configures the minutes of idle before the screensaver activates. Valid range is 3 to 6. Language and Input o Display Language Selects the language to be displayed on the phone's LCD. Users could select Automatic for local language based on IP location if available.
Call Features Configures call forward features for Forward All, Forward Busy, Forward No Answer and No Answer Timeout. System System sub menu includes the following options: Network o IP Setting Selects IP mode (DHCP/Static IP/PPPoE); Configures PPPoE account ID and password; Configures static IP address, Netmask, Gateway, DNS Server 1 and DNS Server 2. o 802.1X Enables/Disables 802.1X mode; Configures 802.1x identity and MD5 password. o Layer 2 QoS Configures 802.
o Config Server Configures config server for provisioning the phone. o Upgrade Via Specifies upgrade/provisioning via TFTP/HTTP/HTTPS. o Start Provison Starts Provision immediately. Language Download o Auto Language Download o Language Download Factory Functions o Diagnostic Mode All LEDs will light up. All keys’ name will display in red on LCD screen before diagnosing. Press any key on the keypad to diagnose the key’s function. When done, the key’s name will display in blue on LCD.
Reboot Reboots the phone.
MENU Call History Local CallLog Status Account Status Network Status System information Contacts Messages Preference Phone System Local Phonebook Local Group LDAP Directory Instant Messages Voice Mails Do Not Disturb Star Key Lock Sounds Appearance Language and Input Date Time Search Mode SIP Call Features Network Bluetooth(GXP2140/60 only) Upgrade Language Download Factory Functions UCM Detect Factory Reset Reboot Enable/Disable Password Ring Tone Ring Volume Active LCD Brightness Idle LCD
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 28 of 87
CONFIGURATION VIA WEB BROWSER The GXP2130/GXP2140/GXP2160/GXP2170 embedded Web server responds to HTTP/HTTPS GET/POST requests. Embedded HTML pages allow a user to configure the IP phone through a Web browser such as Google Chrome, Mozilla Firefox and Microsoft’s IE. To access the Web GUI: 1. Connect the computer to the same network as the phone; 2. Make sure the phone is turned on and shows its IP address. You may check the IP address by pressing Up arrow button when phone is at idle state; 3.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 30 of 87
DEFINITIONS This section describes the options in the phone's Web GUI. As mentioned, you can log in as an administrator or an end user. Status: Displays the Account status, Network status, and System Info of the phone; Account: To configure the SIP account; Settings: To configure call features, ring tone, audio control, LCD display, date and time, Web services, XML applications, programmable keys and etc.
PPPoE Link Up PPPoE connection status. NAT Type The type of NAT connection used by the phone. NAT Traversal Display the status of NAT connection for each account on the phone. Status System Info Product Model Product model of the phone. Part Number Product part number. Software Version Boot: boot version number; Core: core version number; Base: base version number; Prog: program version number.
status on the SIP server. User account information, provided by your VoIP service provider (ITSP). It's SIP User ID usually in the form of digits similar to phone number or actually a phone number. Authenticate ID SIP service subscriber's Authenticate ID used for authentication. It can be identical to or different from the SIP User ID. The account password required for the phone to authenticate with the ITSP Authenticate Password (SIP) server before the account can be registered.
to the STUN server. If NAT type is Full Cone, Restricted Cone or Port-Restricted Cone, the phone will try to use public IP addresses and port number in all the SIP&SDP messages. The phone will send empty SDP packet to the SIP server periodically to keep the NAT port open if it is configured to be "Keep-alive". Configure this to be "No" if an outbound proxy is used. "STUN" cannot be used if the detected NAT is symmetric NAT. Set this to "VPN" if OpenVPN is used.
SIP Transport Determines the network protocol used for the SIP transport. Users can choose from TCP, UDP and TLS. The default setting is “UDP”. SIP URI Scheme when Specifies if "sip" or "sips" will be used when TLS/TCP is selected for SIP using TLS Transport. The default setting is "sips". Use Actual Ephemeral Port in Contact with TCP/TLS This option is used to control the port information in the Via header and Contact header.
"Yes", the P-Preferred-Identity Header will always show in INVITE. If set to "No", the P-Preferred-Identity Header will not show in INVITE. Add Auth Header on To define whether authorization Header will be added on initial REGISTER Initial REGISTER from the first REGISTER. The default setting is “No”. This is used to perform a factory reset through SIP NOTIFY. When the phone Allow SIP Reset receive the NOTIFY with event: RESET, the phone should perform a factory reset after the authentication.
"Standard". Default setting is "No". When set to "Yes", a soft key “BSCCenter” is displayed Broadsoft Call Center on LCD. User can access different Broadsoft Call Center agent features via this softkey. Please note that “Feature Key Synchronization” will be enabled regardless of this setting. Broadsoft Hoteling event feature. Default setting is "No". With “Hoteling Event” Hoteling Event enabled, user can access the Hoteling feature option by pressing the “BSCCenter” sof tkey.
use the Callee or proxy server as the refresher. The default setting is "Omit". UAS Specify Refresher As a Callee, select UAC to use caller or proxy server as the refresher; or select UAS to use the phone as the refresher. The default setting is "UAC". The Session Timer can be refreshed using the INVITE method or the UPDATE Force INVITE method. Select "Yes" to use the INVITE method to refresh the session timer. The default setting is "No".
Multiple vocoder types are supported on the phone, the vocoders in the list is a Preferred Vocoder higher preference. Users can configure vocoders in a preference list that is included with the same preference order in SDP message. Use First Matching When it is set to "Yes", the device will use the first matching vocoder in the Vocoder in 200OK SDP received 200OK SDP as the codec. The default setting is "No".
Dial Plan Prefix Configures the prefix to be added to each dialed number. A dial plan establishes the expected number and pattern of digits for a telephone number. This parameter configures the allowed dial plan for the phone. Dial Plan Rules: 1. Accepted Digits: 1,2,3,4,5,6,7,8,9,0 , *, #, A,a,B,b,C,c,D,d; 2.
Note: In some cases where the user wishes to dial strings such as *123 to activate voice mail or other applications provided by their service provider, the * should be predefined inside the dial plan feature. An example dial plan will be: { *x+ } which allows the user to dial * followed by any length of numbers. Configures Call Log setting on the phone. You can log all calls, only log Call Log incoming/outgoing calls (missed calls will not be logged), or disable call log.
answer incoming calls after a short reminding beep. The default setting is “No”. Allow Auto Answer by Call-Info If set to "Yes", the phone will automatically turn on the speaker phone to answer incoming calls, based on the SIP info header sent from the server/proxy. The default setting is "No". When it is enabled, the phone will put the current call on hold automatically Allow Barging by Call-Info and answer the incoming calls based on the SIP Call-Info header sent from the server/proxy.
Do Not Disturb Configures DND feature code to turn off DND. (DND)--Off Call Forward Configures Call Forward All feature code to activate unconditional call Unconditionally (All)--On forwarding. Call Forward Configures Call Forward All feature code to deactivate unconditional call Unconditionally (All)--Off forwarding Call Forward Busy--On Configures Call Forward Busy feature code to activate busy call forwarding.
non-symmetric NAT routers work with STUN. Configures to turn on/off the public mode for hot desking feature. The Public Mode default setting is “No”. Settings Call Features Configures a User ID/extension to dial automatically when the phone is Off-hook Auto Dial off hook. The phone will use the first account to dial out. The default setting is "No". If configured, when the phone is on hook, it will go off hook after the Off-hook Timeout timeout (in seconds). The default value is 30 seconds.
In-call dial number on pressing Configures the number for the phone to dial as DTMF during the call transfer key using TRAN button. If set to "Yes", the phone will use attended transfer by default. The default Auto-Attended Transfer setting is "No". Do Not Escape # as %23 in Specifies whether to replace # by %23 or not for some special situations. SIP URI The default setting is "No". Enables Click-To-Dial feature.
For details, please check the “Multicast Paging User Guide” on our Website. Settings Ring Tone Configures ring or tone frequencies based on parameters from local Call Progresses Tones: telecom. The default value is North American standard. Frequencies System Ring Tone should be configured with known values to avoid uncomfortable high Dial Tone pitch sounds.
Selects whether the connected headset is normal RJ11 headset, Headset Type Plantronics EHS headset. Configures to enable or disable the speaker to ring when headset is used on "Toggle Headset/Speaker" mode. If set to "Yes", when the phone is in Always Ring Speaker Headset "Toggle Headset/Speaker" mode, both headset and speaker will ring on incoming call. The default setting is "No". Configures the transmission gain of the headset. The default value is Headset TX gain 0dB.
Settings Date and Time NTP Server NTP Update Interval Allow DHCP Option 42 Override NTP Server Time Zone Defines the URL or IP address of the NTP server. The phone may obtain the date and time from the server. The default setting is us.pool.ntp.org. Time interval for updating time from the NTP server. Valid time value is in between 5 to 1440 minutes. The default setting is “1440” minutes. Defines whether DHCP Option 42 should override NTP server or not.
default setting is "Yes". If set to "No", the weather information screen will not show. Configures weather city code for the phone to look up the weather information. The default setting is "Automatic" and the weather City Code information will be obtained based on the IP location of the phone if available. Otherwise, specify the self-defined city code. For example, USCA0638 is the city code for Los Angeles, CA, United States. Specifies the weather update interval (in minutes).
Select the Account to monitor the BLF status. Enter the extension number in the Value field to be monitored. Presence Watcher This option has to be supported by a presence server and it is tied to the "Do Not Disturb" status of the phone's extension. Eventlist BLF This option is similar to the BLF option but in this case the PBX collects the information from the phones and sends it out in one single notify message. PBX server has to support this feature.
from the Base in LDAP configuration under Advanced Settings. The Base in LDAP configuration will be used if the Description field is left blank. Enter the LDAP Name/Number filter in the Value field. For example: If users set MPK 1 as “LDAP Search” for “Account 1”, and set filters: Description -> ou=video,ou=SZ,dc=grandstream,dc=com Value -> sn=Li Since the Base for LDAP server configuration is “dc=grandstream,dc=com”, “ou=video,ou=SZ” is added to narrow the LDAP search scope.
account and the call will be returned based on the account with the last answered call. Intercom Select Account, and enter the extension number in the Value field to do the intercom. LDAP Search This option is to narrow the LDAP search scope. Enter the LDAP search base in the Description field. It could be the same or different from the Base in LDAP configuration under Advanced Settings. The Base in LDAP configuration will be used if the Description field is left blank.
Similar to Speed Dial but it will dial based on the current active account. For example, if the phone is offhook and account 2 is active, it will call the configured Speed Dial number using account 2. Dial DTMF Enter a series of DTMF digits in the Value field to be dialed during the call. "Enable MPK Sending DTMF" has to be set to "Yes" first. Voice Mail Select Account and enter the Voice Mail access number in the Value field.
Multicast Paging This option is for multicast sending. Enter Line key description in Description filed and multicast sending address in Value field. Record This option is for Recording calls. Enter Line key description in Description filed and the recorded extension number in Value field. Please make sure whether your VOIP provider supports this feature before using it. Call Log Select Account and enter account number in the Value field to access to the Call Log of that selected account.
Base in LDAP configuration will be used if the Description field is left blank. Enter the LDAP Name/Number filter in the Value field. For example: If users set MPK 1 as “LDAP Search” for “Account 1”, and set filters: Description -> ou=video,ou=SZ,dc=grandstream,dc=com Value -> sn=Li Since the Base for LDAP server configuration is “dc=grandstream,dc=com”, “ou=video,ou=SZ” is added to narrow the LDAP search scope. “sn=Li” is the example to filter the last name.
Similar to Speed Dial but it will dial based on the current active account. For example, if the phone is offhook and account 2 is active, it will call the configured Speed Dial number using account 2. Dial DTMF Enter a series of DTMF digits in the Value field to be dialed during the call. "Enable MPK Sending DTMF" has to be set to "Yes" first. Voice Mail Select Account and enter the Voice Mail access number in the Value field.
Multicast Paging This option is for multicast sending. Enter Line key description in Description field and multicast sending address in Value field. Record This option is for Recording calls. Enter Line key description in Description filed and the recorded extension number in Value field. Please make sure whether your VOIP provider supports this feature before using it. Call Log Select Account and enter account number in the Value field to allow configuration of call log for other extension.
it. Enterprise Common Enable/Disable and rename the BroadWorks Xsi Enterprise Common Directory features on the phone. If keep the Name box blank, the phone will use the default name “Enterprise Common” for it. Personal Directory Enable/Disable and rename the BroadWorks Xsi Personal Directory features on the phone. If keep the Name box blank, the phone will use the default name “Personal” for it. Missed Call Log Enable/Disable and rename the BroadWorks Xsi Missed Call Log features on the phone.
Choose whether or not to display non-xmpp contacts associated with the Display Non XMPP Contacts Broadsoft IM&P user. Non-xmpp contacts will not display a presence or status message. The default setting is “No”. NETWORK PAGE DEFINITIONS Table 11: Network Page Definitions Network Basic Settings Internet Protocol Selects Prefer IPv4 or Prefer IPv6. The default setting is “Prefer IPv4”. Allows users to configure the appropriate network settings on the phone to IPv4 Address Type obtain IPv4 address.
DNS Server 2 Enter the DNS Server 2 for IPv6. Preferred DNS server Enter the Preferred DNS Server for IPv6. Network Advanced Settings Allows the user to enable/disable 802.1X mode on the phone. The default 802.1X mode value is disabled. To enable 802.1X mode, this field should be set to EAP-MD5, users may also choose EAP-TLS, or EAP-PEAP. 802.1X Identity Enter the Identity information for the 802.1x mode. MD5 Password Enter the MD5 Password for the 802.1X mode. 802.1X CA Certificate 802.
MAINTENANCE PAGE DEFINITIONS Table 12: Maintenance Page Definitions Maintenance Web Access User Password Set new password for web GUI access as User. This field is case sensitive. Confirm Password Enter the new User password again to confirm. Current Admin Password The current admin password is required for setting a new admin password. New Password Confirm Password Set new password for web GUI access as Admin. This field is case sensitive. Enter the new Admin password again to confirm.
configuration file with the matching encrypted prefix will be downloaded and flashed into the phone. Enables your ITSP to lock configuration updates. If configured, only the Config File Postfix configuration file with the matching encrypted postfix will be downloaded and flashed into the phone. Default setting is “Yes”. DHCP option 66 originally was only designed for Allow DHCP Option 43 TFTP server. Later on it was extended to support an HTTP URL.
Send SIP Log registration status change (INFO level); negotiated codec (INFO level); Ethernet link up (INFO level); SLIC chip exception (WARNING and ERROR levels); Memory exception (ERROR level). Configures whether the SIP log will be included in the syslog messages. The default setting is "No". Auto Recover From If set to “Yes”, the phone will automatically recover when running abnormal. Abnormal The default setting is “Yes”.
Keypad Menu There are three different options: Unrestricted. All the options can be accessed in keypad Menu. Basic settings only. The SIP option under Phone submenu, and Network, Upgrade, UCM Detect and Factory Reset options under System submenu will not be available in LCD Menu. Constraint Mode. The phone will require administration password to change the Network, Upgrade and Factory Reset options under System submenu, and SIP option under Phone submenu as well.
USB Filename Defines the filename of the capture. Only required when capture location is USB. PHONEBOOK PAGE DEFINITIONS Table 13: Phonebook Page Definitions Phonebook Contacts Add Contact Specifies Contact’s First Name, Last Name, Phone Number, Accounts and Groups to add one new contact in phonebook. Edit Contact Edits selected contact. Delete All Contacts Deletes all contacts from phonebook. Phonebook Group Management Add Group Specifies Group’s name to add new group.
options. Default search mode Configures the default phonebook search mode. The default setting is “Qick match”. Phonebook LDAP LDAP Protocol Configures the LDAP protocol to LDAP or LDAPS. The default setting is “LDAP”. LDAPS is a feature to support LDAP over TLS. Server Address Configures the IP address or DNS name of the LDAP server. Port Configures the LDAP server port. The default port number is “389”. Configures the LDAP search base.
cn sn description Specifies the "number" attributes of each record which are returned in the LDAP search result. This field allows the users to configure multiple space LDAP Number Attributes separated number attributes. Example: telephoneNumber telephoneNumber Mobile Configures the entry information to be shown on phone's LCD. Up to 3 fields LDAP Display Name can be displayed. Example: %cn %sn %telephoneNumber Max.
BLF LED PATTERNS Table 14: BLF LED Patterns Pattern: Default Pattern: Analog Call’s state Light Indication Call’s state Light Indication Offline Off Offline Off Idle Solid Green Idle Solid Green Trying Solid Red Trying Solid Red Talking Solid Red Talking Solid Red Proceeding Flashing Red Proceeding Solid Red Incoming call Flashing Red Incoming call Flashing Red GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 68 of 87
Pattern: Directional Mode: Inverse Call’s state Light Indication Call’s state Light Indication Offline Off Offline Off Idle Solid Green Idle Solid Red Trying Flashing Green Trying Solid Green Talking Solid Red Talking Solid Green Flashing Green Proceeding Flashing Green Flashing Red Incoming call Flashing Green Proceeding (Initiator) Proceeding (Receiver) Incoming call Flashing Red Mode: Reverved (Red) Call’s state Offline Idle Light Indication Off (Extension Board Icon: Off)
NAT SETTINGS If the devices are kept within a private network behind a firewall, we recommend using STUN Server. The following settings are useful in the STUN Server scenario: STUN Server Under Settings->General Settings, enter a STUN Server IP (or FQDN) that you may have, or look up a free public STUN Server on the internet and enter it on this field. If using Public IP, keep this field blank. Use Random Ports It is under Settings->General Settings. This setting depends on your network settings.
WEATHER UPDATE To customize GXP2130/GXP2140/GXP2160/GXP2170 to display weather information for the preferred city, users could go to web GUI->Settings->Web Service page and enter the city code in the following options: Figure 2: Web Service By default the City Code is set to "Automatic", which allows the phone to obtain weather information based on the IP location detected.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 72 of 87
EDITING CONTACTS AND CLICK-TO-DIAL From GXP2130/GXP2140/GXP2160/GXP2170 Web GUI, users could view contacts, edit contacts, or dial out with Click-to-Dial feature on the top of the Web GUI. In the following figure, the Contact page shows all the added contacts (manually or downloaded via XML phonebook). Here users could add new contact, edit selected contact, or dial the contact/number.
Click to dial from available lines. Add contacts. Click to call this Edit contact. contact from the phone.
WALLPAPER GXP2130/GXP2140/GXP2160/GXP2170 support 3 approaches for wallpaper configurations: “Default”, “Download”, and “Upload”. GXP2140/GXP2160/GXP2170 also provide loading wallpaper file from USB drive. Default Mode Under Default mode, the phone will display the wallpaper supplied by firmware. Download Mode Under Download mode, the phone will download the wallpaper from the specified server path under “Wallpaper Server Path” option.
Figure 6: Upload Selected Wallpaper to Phone GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 76 of 87
SAVING THE CONFIGURATION CHANGES After users makes changes to the configuration, press the "Save" button will save but not apply the changes until the "Apply" button on the top of web GUI page is clicked. Or, users could directly press "Save and Apply" button. We recommend rebooting or powering cycle the phone after applying all the changes. REBOOTING FROM REMOTE LOCATIONS Press the "Reboot" button on the top right corner of the web GUI page to reboot the phone remotely.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 78 of 87
PACKET CAPTURE GXP2130/GXP2140/GXP2160/GXP2170 is embedded with packet capture function on firmware 1.0.4.10 or greater. The related options are under Maintenance -> Packet Capture. Figure 7: Packet Capture in Idle In the option Capture Location, User can select to store the capture file in phone’s internal storage or extended USB storage. When the Capture Location is specified as USB, a USB drive must be connected.
Figure 9: Capture to Internal Storage When the capture configuration is set, press Start button to start packet capture. The Status will become RUNNING while capturing, as showed in Figure 8 and Figure 9. Press Stop button to end capture. If the capture location is internal storage, user can press Download button to download capture file to local PC. If capture location is USB, the file will be saved on USB automatically with the defined name. The capture file is in .pcap format.
MULTICAST PAGGING GXP2130/GXP2140/GXP2160/GXP2170 supports multicast paging, including sending and listening. On the phone, users could send multicast page by setting the multicast address and port. Also, users can listen to at most 10 different multicast IP address. Multicast sender related settings are under Web UI, Settings -> Programmable keys. Select Multicast paging as the key mode for dial page call. Multicast paging listening related settings are under Web UI Settings -> Multicast Paging.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 82 of 87
UPGRADING AND PROVISIONING The GXP2130/GXP2140/GXP2160/GXP2170 can be upgraded via TFTP/HTTP/HTTPS by configuring the URL/IP Address for the TFTP/HTTP/HTTPS server and selecting a download method. Configure a valid URL for TFTP or HTTP/HTTPS; the server name can be FQDN or IP address. Examples of valid URLs: firmware.grandstream.com fw.ipvideotalk.com/gs There are two ways to setup a software upgrade server: The LCD Keypad Menu or the Web Configuration Interface.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 84 of 87
UPGRAGE VIA WEB GUI Open a web browser on PC and enter the IP address of the phone. Then, login with the administrator username and password. Go to Maintenance->Upgrade and Provisioning page, enter the IP address or the FQDN for the upgrade server in "Firmware Server Path" field and choose to upgrade via TFTP or HTTP/HTTPS. Update the change by clicking the "Save and Apply" button. Then "Reboot" or power cycle the phone to update the new firmware.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 86 of 87
CONFIGURATION FILE DOWNLOAD Grandstream SIP Devices can be configured via the Web Interface as well as via a Configuration File (binary or XML) through TFTP or HTTP/HTTPS. The "Config Server Path" is the TFTP or HTTP/HTTPS server path for the configuration file. It needs to be set to a valid URL, either in FQDN or IP address format. The "Config Server Path" can be the same or different from the "Firmware Server Path".
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 88 of 87
RESTORE FACTORY DEFAULT SETTINGS Warning: Restoring the Factory Default Settings will delete all configuration information on the phone. Please backup or print all the settings before you restore to the factory default settings. Grandstream is not responsible for restoring lost parameters and cannot connect your device to your VoIP service provider.
This page intentionally left blank GXP2130/GXP2140/GXP2160/GXP2170 ADMINISTRATION GUIDE Page 90 of 87
EXPERIENCING THE GXP2130/GXP2140/GXP2160/GXP2170 Please visit our website: http://www.grandstream.com to receive the most up- to-date updates on firmware releases, additional features, FAQs, documentation and news on new products. We encourage you to browse our product related documentation, FAQs and User and Developer Forum for answers to your general questions. If you have purchased our products through a Grandstream Certified Partner or Reseller, please contact them directly for immediate support.
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
