Grandstream Networks, Inc.
COPYRIGHT ©2016 Grandstream Networks, Inc. http://www.grandstream.com All rights reserved. Information in this document is subject to change without notice. Reproduction or transmittal of the entire or any part, in any form or by any means, electronic or print, for any purpose without the express written permission of Grandstream Networks, Inc. is not permitted. The latest electronic version of this user manual is available for download here: http://www.grandstream.
GNU GPL INFORMATION HT801 firmware contains third-party software licensed under the GNU General Public License (GPL). Grandstream uses software under the specific terms of the GPL. Please see the GNU General Public License (GPL) for the exact terms and conditions of the license. Grandstream GNU GPL related source code can be downloaded from Grandstream web site from: http://www.grandstream.
Table of Content DOCUMENT PURPOSE ................................................................................................. 6 CHANGE LOG ................................................................................................................ 7 Firmware Version 1.0.0.1 ....................................................................................................................... 7 GUI INTERFACE EXAMPLES .................................................................................
Rebooting HT801 from Remote ........................................................................................................... 41 UPGRADING AND PROVISIONING ............................................................................ 42 Firmware Upgrade procedure .............................................................................................................. 42 Upgrading via Local Directory: .............................................................................................
Table of Tables Table 1: HT801 Features at a Glance ......................................................................................................... 10 Table 2: HT801 Technical Specifications .................................................................................................... 10 Table 3: Definition of the HT801 Connectors .............................................................................................. 12 Table 4: HT801 LEDs Pattern Description .........................
DOCUMENT PURPOSE This document describes the basic concept and tasks necessary to use and configure your HT801. And it covers the topic of connecting and configuring the HT801, making basic operations and the call features. Please visit http://www.grandstream.com/support to download the latest “HT801 User Guide”.
CHANGE LOG This section documents significant changes from previous versions of administration guide for HT801. Only major new features or major document updates are listed here. Minor updates for corrections or editing are not documented here. Firmware Version 1.0.0.1 This is the initial version for HT801.
GUI INTERFACE EXAMPLES http://www.grandstream.com/sites/default/files/Resources/HT801_web_gui.zip 1. Screenshot of Login Page 2. Screenshots of Status Page 3. Screenshots of Basic Settings Page 4. Screenshots of Advanced Settings Page 5.
WELCOME The HT801 Analog Telephone Adapter provides transparent connectivity for analog phones and faxes to the world of Internet voice. Connecting to any analog phone, fax or PBX, the HT801 is an effective and flexible solution for accessing Internet-based telephone services and corporate intranet systems across established LAN and Internet connections. The Grandstream Handy Tone HT801 is a new addition to the popular Handy Tone ATA product family.
PRODUCT OVERVIEW The HT801 is a 1 port analog telephone adapter (ATA) that allows users to create a high-quality and manageable IP telephony solution for residential and office environments. Its ultra-compact size, voice quality, advanced VoIP functionality, security protection and auto provisioning options enable users to take advantage of VoIP on analog phones and enables service providers to offer high quality IP service.
forward, hold, do not disturb, 3-way conference Voice Codecs G.711 with Annex I (PLC) and Annex II (VAD/CNG), G.723.1, G.729A/B, G.726, iLBC, OPUS, dynamic jitter buffer, advanced line echo cancellation Fax over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.
GETTING STARTED This chapter provides basic installation instructions including the list of the packaging contents and also information for obtaining the best performance with the HT801. Equipment Packaging The HT801 ATA package contains: 1x HT801 1x 5V Power Adapter 1x Quick Installation Guide 1x Ethernet Cable 1x GPL Statement Figure 1: HT801 Package Contents Note: Check the package before installation. If you find anything missing, contact your system administrator.
Micro-USB Power Reset Powers the phone adapter (5V – 1A). Factory reset button. Press for 7 seconds to reset factory default settings. Connecting HT801 The HT801 is designed for easy configuration and easy installation, to connect your HT801, please follow the steps above: 1. Insert a standard RJ11 telephone cable into the p hone port and connect the other end of the telephone cable to a standard touch-tone analog telephone. 2.
Table 4: HT801 LEDs Pattern Description LED Lights Power LED Status The Power LED lights up when the HT801 is powered on and it flashes when it is booting up Internet LED The Ethernet LED lights up when the HT801 is connected to your network through the Ethernet port and it flashes when there is data being sent or received.
CONFIGURATION GUIDE The HT801 can be configured via one of two ways: The IVR voice prompt menu. The Web GUI embedded on the HT801 using PC's web browser. Obtain HT801 IP Address via Connected Analogue Phone HT801 is by default configured to obtain the IP address from DHCP server where the unit is located. In order to know which IP address is assigned to your HT801, you should access to the “Interactive Voice Response Menu” of your adapter via the connected phone and check its IP address mode.
05 “DNS Server “ + IP Same as menu 02 address 07 Preferred Vocoder Press “9” to move to the next selection in the list: PCM U / PCM A iLBC G-726 G-723 G-729 10 “MAC Address” Announces the Mac address of the unit. 13 Firmware Server IP Announces current Firmware Server IP address. Address Enter 12 digit new IP address. Configuration Server IP Announces current Config Server Path IP address. Address Enter 12 digit new IP address.
address. For IP address, add 0 before the digits if the digits are less than 3 (i.e. - 192.168.0.26 should be key in like 192168000026. No decimal is needed). Key entry cannot be deleted but the phone may prompt error once it is detected. Configuration via Web Browser The HT801 embedded Web server responds to HTTP GET/POST requests. Embedded HTML pages allow a user to configure the HT801 through a web browser such as Google Chrome, Mozilla Firefox and Microsoft’s IE. Accessing the Web UI 1.
Changing Admin Level Password 1. Access your HT801 web UI by entering its IP address in your favorite browser. 2. Enter your admin password (default: admin). 3. Press Login to access your settings and navigate to Advanced Settings > Admin Password. 4. Enter the new admin password. 5. Confirm the new admin password. 6. Press Apply at the bottom of the page to save your new settings. Figure 5: Admin Level Password Changing User Level Password 1.
Web Configuration Pages Definitions This section describes the options in the HT801 Web UI. As mentioned, you can log in as an administrator or an end user. Status: Displays the system info, network status, account status, and line options. Basic Settings: Configures the end user level password, IP address modes, web access, time zone settings and language.
Port Status Displays relevant information regarding the FXS port about its registration, DND and call forward features. Port Options Displays relevant information regarding the FXS port about its DND and call forward features. Provision Displays provisioning status. Core Dump Provides generated core dump file if unit malfunctions. Clean will be displayed if no issues.
ID or other identification information about a client. Default is HT8XX. PPPoE account ID Defines the PPPoE username. Necessary if ISP requires you to use a PPPoE (Point to Point Protocol over Ethernet) connection. PPPoE password Specifies the PPPoE account password. PPPoE Service Defines PPPoE service name. If your ISP uses a service name for the PPPoE Name connection, enter the service name here. This field is optional. Default is blank.
Settings” page. Password field is purposely left blank for security reasons after clicking update and saved. Max. length is 25 characters. Confirm Admin Confirms the new admin password. Password Layer 2 QoS Sets values for 802.1Q/VLAN Tag. Default is 0. Valid range is 0-4094. SIP 802.1p. Default is 0. Valid range is 0-7. RTP 802.1p. Default is 0. Valid range is 0-7. STUN Server is Configures IP address or domain name of STUN server. Only non-symmetric NAT routers work with STUN.
Firmware File Checks if firmware file is with matching prefix before downloading it. This field enables Prefix user to store different versions of firmware files in one directory on the firmware server. Firmware File Checks if firmware file is with matching postfix before downloading it. This field enables Postfix user to store different versions of firmware files in one directory on the firmware server. Config File Checks if configuration files are with matching prefix before downloading them.
Authenticate Authenticates configuration before being accepted. This protects the configuration from Conf File unauthorized modifications. Default is No. SIP TLS Certificate Specifies SSL certificate used for SIP over TLS is in X.509 format. The HT801 has builtin private key and SSL certificate. SIP TLS Private Specifies TLS private key used for SIP over TLS is in X.509 format. Key SIP TLS Private Specifies SSL Private key password used for SIP Transport in TLS/TCP.
Tones to North American frequencies. Frequencies should be configured with known values to avoid uncomfortable high pitch sounds. ON is the period of ringing (ON time in ms) while OFF is the period of silence. In order to set a continuous ring, OFF should be zero. Otherwise it will ring ON ms and a pause of OFF ms and then repeats the pattern.
3. sent or received SIP message (DEBUG level) 4. SIP message summary (INFO level) 5. inbound and outbound calls (INFO level) 6. registration status change (INFO level) 7. negotiated codec (INFO level) 8. Ethernet link up (INFO level) 9. SLIC chip exception (WARNING and ERROR levels) 10. memory exception (ERROR level) The Syslog uses USER facility. In addition to standard Syslog payload, it contains the following components: GS_LOG: [device MAC address] [error code] error message.
Outbound Proxy Specifies IP address or domain name of outbound Proxy, or media gateway, or session border controller. Used by HT801 for firewall or NAT penetration in different network environments. If symmetric NAT is detected, STUN will not work and only outbound proxy can correct the problem. Allow DHCP Option Configures the HT801 to collect SIP server address from DHCP option 120. Default is 120 (override SIP No Server) SIP transport Selects transport protocol for SIP packets; UDP or TCP or TLS.
"Enable". Enabled: "Tel:" will be used instead of "sip:" in the SIP request. Please consult your carrier before changing this parameter. Default is Disabled. SIP Registration Shows the status of SIP registration. If the SIP account is successfully registered, it will display “YES” with green background. If the SIP account is not registered, it will display “NO” with red background.
Layer 3 QoS Defines Diff-Serv values for SIP and RTP. Defaults are: SIP Diff-Serv: 26 / RTP Diff-Serv: 46 Local SIP Port Defines local port to use by the HT801 for listening and transmitting SIP packets. Default value for FXS is 5060. Local RTP Port Defines the local RTP-RTCP port pair the HT801 will listen and transmit. It is the HT801 RTP port for channel 0. The default value for FXS port is 5004. Use Random SIP Controls whether to use configured or random SIP ports.
Authenticate Configures whether to validate the domain certificate when download the server certificate firmware/config file. If it is set to "Yes", the phone will download the firmware/config file domain only from the legitimate server. The default setting is "No". Authenticate Configures whether to validate the server certificate when download the firmware/config server certificate file.
Disable DTMF Uses above DTMF order without negotiation. Default is No. Negotiation Generate When enabled the RFC2833 events are generated until key is released. Default is No. Continuous RFC2833 Events Send Hook Flash Default is No. If set to yes, flash will be sent as DTMF event.
server will be used. Bellcore rings and tones are independent from custom ring tones. The custom ring tones can also be specified by alert-info header, for example AlertInfo: ;info=ring5 Disable Call Disables receiving a second incoming call when the line is engaged. Waiting Default is No. Disable Call Disables displaying caller ID when receiving a second incoming call. Default is No.
proxy is configured and supporting 484 responses (Incomplete Address). Otherwise, the call will likely be rejected by the proxy (with a 404 Not Found error). Default is No. This feature is NOT designed to work with and should NOT be enabled for direct IP-toIP calling. Dial Plan Prefix Adds specified prefix to dialed number. Use # as Dial Key Treats “#” as the “Send” (or “Dial”) key. If set to “No”, this “#” key can be included as part of the dialed number. Default is Yes. Dial Plan Dial Plan Rules: 1.
• <=1617>[2-9]xxxxxx - allows dialing to local area code (617) numbers by dialing 7 numbers and 1617 area code will be added automatically • 1[2-9]xx[2-9]xxxxxx - allows dialing to any US/Canada Number with 11 digits length • 011[2-9]x. - allows international calls starting with 011 • [3469]11 - allow dialing special and emergency numbers 311, 411, 611 and 911 Note: In some cases, user wishes to dial strings such as *123 to activate voice mail or other application provided by service provider.
UAC Specify Refresher UAS Specify Refresher Specifies which end will act as refresher for outgoing calls. Default is Omit.: UAC: The handy tone acts as the refresher. UAS: Callee or proxy server act as the refresher. Specifies which end will act as refresher for incoming calls. Default is Omit.: UAS: The handy tone acts as the refresher. UAC: Callee or proxy server act as the refresher. Force INVITE Uses INVITE message to refresh the session timer. Default is No.
Fax Mode Specifies the fax mode : T.38 (Auto Detect) FoIP by default, or Pass-Through (must use codec PCMU/PCMA) Re-Invite after Fax Permits the unit to send out the re-INVITE for T.38 or Fax Pass Through if a fax tone is Tone Detection detected. Default is Enabled Mode Jitter Buffer Type Jitter Buffer Length Selects jitter buffer type (Fixed or Adaptive) based on network conditions. High (initial 200ms, min 40ms, max 600ms) Note: not all vocoders can meet the high requirement.
On Hook Timing Specifies the on-hook time for an on-hook event to be validated. HT801 supports a range from 40 to 2000 ms. Default value is 400. Gain Adjusts the voice path volume. • Rx is a gain level for signals transmitted by FXS • Tx is a gain level for signals received by FXS. Default = 0dB for both parameters. Loudest volume: +6dB Lowest volume: -6dB. User can adjust volume of call using the Rx gain level parameter and the Tx gain level parameter located on the FXS port configuration page.
DTMF Methods The HT801 support the following DTMF mode: DTMF in-audio DTMF via RTP (RFC2833) DTMF via SIP INFO Set priority of DTMF methods according to your preference. This setting should be based on your server DTMF setting. Preferred Vocoder (Codec) The HT801 supports following voice codecs. On FXS port page, choose the order of your favorite codecs: PCMU/A (or G711µ/a) G729 A/B G723.
Register a SIP Account The HT801 supports 1 FXS port which can be configured with 1 SIP account. Please refer to the following steps in order to register your accounts via web user interface : 1. Access your HT801 web UI by entering its IP address in your favorite browser. 2. Enter your admin password (default: admin). 3. Press Login to access your settings. 4. Go to FXS Port page. 5. In FXS Port tab, set the following: a. Account Active to Yes. b.
After applying your configuration, your account will register to your SIP Server, you can verify if it has been correctly registered with your SIP server from your HT801 web interface under Status > Port Status > Registration (If it displays Registered, it means that your account is fully registered, otherwise it will display Not Registered so in this case you must double check the settings or contact your provider).
*50 Disable Call Waiting (for all subsequent calls). *51 Enable Call Waiting (for all subsequent calls). *67 Block Caller ID (per call). Dial “*67” +” number”. No dial tone is played in the middle. *82 Send Caller ID (per call). Dial “*67” +” number”. No dial tone is played in the middle. *69 Call Return Service: Dial *69 and the phone will dial the last incoming phone number received. *70 Disable Call Waiting (per call). Dial “*70” +” number”. No dial tone is played in the middle.
UPGRADING AND PROVISIONING The HT801 can be upgraded via TFTP/HTTP/HTTPS by configuring the URL/IP Address for the TFTP/HTTP/HTTPS server and selecting a download method. Configure a valid URL for TFTP or HTTP/HTTPS; the server name can be FQDN or IP address. Examples of valid URLs: firmware.grandstream.com fw.ipvideotalk.com/gs Firmware Upgrade procedure Please follow below steps in order to upgrade the firmware version of your HT801: 1.
Upgrading via Local Directory: 1. Download the firmware file from Grandstream web site; 2. Unzip it and copy the file in to a folder in your PC; 3. From the HT801 web interface (Advanced Settings page) you can browse your hard drive and select the folder you previously saved the file (HT801fw.bin); 4. Click “Upload Firmware” and wait few minutes until the new program is loaded. Note: Always check the status page to see that the program version has changed.
Managing Firmware and Configuration File Download When “Automatic Upgrade” is set “Yes, every” the auto check will be done in the minute specified in this field. If set to “daily at hour (0-23)”, Service Provider can use P193 (Auto Check Interval) to have the devices do a daily check at the hour set in this field with either Firmware Server or Config Server. If set to “weekly on day (0-6)” the auto check will be done on the day specified in this field.
RESTORE FACTORY DEFAULT SETTINGS Warning: Restoring the Factory Default Settings will delete all configuration information on the phone. Please backup or print all the settings before you restore to the factory default settings. Grandstream is not responsible for restoring lost parameters and cannot connect your device to your VoIP service provider.
For example: if the MAC address is 000b8200e395, it should be keyed in as “0002228200333395”. Reset from Web Interface (Reset Type) 1. Access your HT801 UI by entering its IP address in your favorite browser. 2. Enter your admin password (default: admin). 3. Press Login to access your settings. 4. Go to Basic Settings > Reset Type. 5. Press Reset button (after selecting the reset type). Full Reset: This will make a full reset.
EXPERIENCING HT801 Please visit our website: http://www.grandstream.com to receive the most up- to-date updates on firmware releases, additional features, FAQs, documentation and news on new products. We encourage you to browse our product related documentation, FAQs and User and Developer Forum for answers to your general questions. If you have purchased our products through a Grandstream Certified Partner or Reseller, please contact them directly for immediate support.
FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
