EN Programming manual mc-26 / mc-28 / mc-28 4D 16 channel HoTT 2,4 GHz transmitter No.
Index Introduction.............................................................................. 7 Service Centre.................................................................................7 Use and menu functions.......................................................... 8 Short-Cuts.......................................................................................8 Definition of terms................................................................... 9 Receiver configuration.....................
Model type............................................................................. 25 Motor on CH1...............................................................................26 Tail.................................................................................................26 Ailerons/Flaps...............................................................................27 Brake offset...................................................................................27 Servo adjustment............
FLAP -> ELE (flaps -> elevator)........................................................52 Free mixers............................................................................. 53 MIX act. / Phase..................................................................... 56 Only mix channel.................................................................... 56 Dual mixer............................................................................... 57 Fail Safe..................................................
Info display............................................................................. 69 Digital trim / Throttle switch-off trim (function)................. 69 Heli programming................................................................... 70 Throttle curve (Heli)............................................................... 73 Sticks setting (Heli)................................................................. 73 Control adjust (Heli)..............................................................
Introduction Thank you very much for purchasing the Graupner mc-28 HoTT. The transmitter manual is composed by two parts. Part 1, the short manual, is included in the packaging. Part 2, the programming manual, can be found in its last version on www.graupner.de by the related page of the transmitter. Read this manual carefully to achieve the best results with your transmitter and first of all to safely control your models.
Use and menu functions Short-Cuts The following key combinations can be used to directly call up certain menus and options: CLEAR on the right touch pad Brief simultaneous touch of the keys or will restore the active entry fi eld's changed parameter value back to its default value. "Servo screen" keys of the left touch pad will Brief simultaneous activation of the cause a jump from the transmitter's base screen or from almost any menu position to the "Servo" menu.
Definition of terms Control function A control function is understood as the signal for a specific control function. The signal of a control function can be transmitted directly into one control channel or through a mixer to several control channels. The control function includes the influence of the mechanical control path on the corresponding servo. This can be spread or concentrated and modified from linear to highly exponential.
Receiver configuration The servos must be connected to the receiver in the indicated sequence. Not assigned outputs remain free. It is possible to change the settings in the line "Receiver outputs" in the "Model basic setting" menu.
Helicopter models Receiver assignment for helicopter models with 1 to 3 swashplate servos free or special function free or special function free or governor or special function free or special function receiver power supply gyro suppression throttle servo or motor controller free or special function tail servo (gyro-system) Nick-1-servo Roll-1-servo Pitch- or Roll-2 or Nick-2-servo receiver power supply free or special function Receiver assignment for helicopter models with 4 swashplate servos free or spe
Copter free or special function free or special function free or special function free or special function receiver power supply free or special function free or special function free or special function Yaw Nick Roll Motor/Pitch (up/down) receiver power supply free or special function Receiver power supply special function V-cable No. 3936.11 PRX stabilized receiver power supply No. 4136 special function V-cable No. 3936.11 12 / 80 PRX stabilized receiver power supply No.
Symbols explication ! Always observe the information indicated by this warning sign. Particularly those which are additionally marked with the CAUTION or WARNING. The signal word WARNING indicates the potential for serious injury, the signal word CAUTION indicates possibility of lighter injuries. The signal word Note indicates potential malfunctions. Attention indicates potential damages to objects. Menus description The menus are described in the same sequence as they appear in the lower display.
Fail-Safe setup t.b.d. Fail Safe setting not performed yet Thr Throttle or pitch control stick position or throttle limit for helicopters too high too high! No pupil signal Connection between teacher and pupil transmitter disturbed inser t SD card OK Power-on warning is active!!! No SD or SDHC memory card in the card slot or card not readable. Within the time set in the line "Switch-on warning" of the "general settings" menu the transmitter has not been used.
With this selection model specific settings will be available in the menus. Now you can program your model in this model memory. After the initialization of the selected model memory with the desired model type the display changes to the base display of the new assigned model memory. At the same time it will appear for some seconds the warning message that there is no connection with a receiver. Tapping on the SET button you will directly enter the "Base menu". Here you are directly in the line for binding.
Copy Mod¢Mod Copy from model: 01 GRAUBELE ULTIMATE 02 03 STARLET 04 BELL47G frei 05 M G M M R12 R12 R12 ––– Model Export to SD card => => => => => 01 ULTIMATE SD-CARD expor t ? NO YES Import from SD Import from SD-CARD: 16/08/10 ALPINA 16/08/11 EXTRA 16/08/12 COBRA 16/08/13 BELL47G frei 05 to model: GRAUBELE ULTIMATE STARLET BELL47G free M G M M • Select the model to copy and confirm the selection through the SET button.
Copy phase Erase model Copy model–>model Expor t to SD Impor t from SD Copy phase => => => => => Copy from phase: 2 1 4 3 6 5 7 => => Copy to phase: 2 1 4 3 6 5 7 => => Expor t to SD Impor t from SD Copy phase Store changes undo changes => => => => => Expor t to SD Impor t from SD Copy phase Store changes undo changes => => => => => Select the "Copy phase" point an confirm through the SET button. Through the ESC button you can always interrupt the process.
Suppress menus In this menu you can hide menu points from the menu function list. The hiding is related to the model memory. Model select Copy / Erase Suppress menus Suppress models Base setup model Model type Select the menu point to hide or to show and switch the status through the SET button. The crossed-out menu points are then no longer displayed in the multifunction list.
Control mode Base setup model Mod. Name GRAUBELE Stick mode 1 Module HoTT bind n/a Rcv Ch Map n/a R08 SEL In this function you can choose a control mode which will be used for this model memory. In this way it will be determined which control movement of the related control stick will we associated to which channel. Tap n the SET button, set the desired mode through the selection buttons. In the "receiver assignation" section you can see where each servo should be connected.
01 02 03 04 05 06 GRAUBELE M ULTIMATE G M STARLET M BELL47G free free R12 R12 R12 ––– Module Base setup model Mod. name GRAUBELE 1 Stick mode Module HoTT bind n/a Rcv Ch Map R12 n/a BD1 BD2 The binding type is indicated in the model memory list near the model memory name: "G" means global binding "M" means model memory specific binding Through the left and right selection buttons you can select the fields in the lines.
Receiver binding You can bind two receivers to the transmitter. The two bound receivers can be also managed in this option. You can split the control channels of the receivers in the "Receiver output" as you prefer. Binding process Base setup model Mod. name GRAUBELE 1 Stick mode Module HoTT n/a n/a Rcv Ch Map n/a n/a Move to the "n/v" field near the "HoTT" field through the selection buttons. Set your HoTT receivers in the binding mode.
Receiver output Base setup model Mod. name GRAUBELE 1 Stick mode Module HoTT bind bind Rcv Ch Map R12 R08 SET SET This function (Channel Mapping) is available as soon as in the line "Module" is bound at least one receiver. Here you can split the control channels of the transmitter to the bound receivers. You can also select freely the channel order within the receiver. In this way the control channels coming from the transmitter will be assigned to a free selectable output of the receiver.
Is the power supply of the receiver OK? Is the position of the receiver antennas correct? Are there any interference from electronic component in the model? If you have verified these conditions and against it you coul not perform a successful range test, then please contact ou Customer Service (see section "Service Center").
Switch-on warning Base setup model RF transmit ON 99sec RF Range Test DSC Output PPM10 Power on war ning ––– With this option it is possible to program the query for the position of a switch or control so that when the transmitter is switched on in the base display a warning will appear. To do that you have to assign in this line a switch, a control switch or a logical switch. Activate a warning: Move desired switch to ON position (ext. switch: SET) 0:00.0 GRAUBELE S 01 L 0:00.0 «normal » ! Warning ! 4.
Model type Suppress models Base setup model Model type Ser vo adjustment Stick mode. Control adjust Model type Motor at C1 None nor mal Leitwerk Querr./Wölb 1QR Bremsoffs. +100% Ein1 SEL In this menu you can adjust the settings for the actual model type. Here you can select for example the tail and wing type or whether the model has motor or not. If in the model selection you have chosen copter, car or boat in this menu will appear only the line "Motor at CH1".
Motor on CH1 Model type Motor at C1 None Nor mal Tail type Aile/flaps 1AIL Brake Off +100% In1 SEL Tail Model type Motor at C1 None nor mal Tail type Aile/flaps 1AIL Brake Off +100% In1 SEL If you have selected airplane in the model selection, it will also appear the line "Motor at CH1". The setting are also here as previously described. Here you can select the tail type of your model to obtain the related control signals at the receiver outputs (see "Receiver assignation" menu).
Ailerons/Flaps Model type Motor at C1 None nor mal Tail type Aile/flaps 1AIL Brake Off +100% In1 SEL In this line you can select the number of servos installed in the wings. The following table shows the control channels to which the servos must be connected.
Column 1 S1 S2 S3 S4 S5 0% 0% 0% 0% 0% Rev cent 100% 100% 100% 100% 100% 100% 100% 100% 100% 100% tr v + In the first column are listed the control outputs. The numbers for the servos refer to the servos connected to the corresponding receiver outputs providing that the transmitter and receiver outputs have not been switched. A change in the control mode therefore does not influence the numbering of the servos.
Sticks setting In this menu you can set the step value of the trim and the control speed. This settings are valid for the channels one to four. The channels are listed with their function in the first column, according to the chosen model type. Ser vo adjustment Stick mode Control adjust Dual Rate / Expo Channel 1 cur ve Switch display Ch.1 Aile Elev Rudd GL PH PH PH 4 4 4 4 Tr St 0.0s 0.0s 0.0s 0.0s Column "Tr" 0.0s 0.0s 0.0s 0.
"Type" In5 GL In6 GL In7 GL In8 GL Normal typ fr fr fr fr ––– ––– ––– ––– SEL 0% 0% 0% 0% offset In this column you can select if the control setting for this channel has to act globally "G" or according to the phase "PH". If the control has to be assigned specifically to the phase, the related phase must be active. In the second line from the bottom of the display will be shown the phase name. "fr" In5 GL fr ––– GL frdesired In6 Move ––– In7 control GL fr adj.
"- Trv +" +100% In5 +100% +100% In6 +100% In7 +100% +100% +100% In8 +100% Normal – tr v + You can reach the column by moving the marking frame with the selection buttons over the "Offset" column to the right side. In this column you can set the control travel for both sides, together or separated for each side. The setting range is 0 … 150% of the normal control travel. The set values always refer to the settings in the column "Centre".
Expo Setting the Expo step-by-step: • Select the line of the desired control function • Assign the switch in the column Geberweg section "Control settings") Geberweg Geberweg Expo = +50% Expo = –100% • Servoweg Servoweg Servoweg Expo = +100% Servoweg Servoweg Expo = +100% You can reach the column by moving the marking frame with the selection buttons over the "SEL" column to the right side. It will be shown "EXPO" instead of "DUAL".
K1 Kur ve Kur ve aus Eingang +50% Ausgang +50% Punkt 1 +50% Nor mal The control curve is defined by up to 6 points (points of intersection) along the entire control stick path. The graphical representation shows how the support points are set and adjusted. In the first line, the effect of the curve function is switched "on" or "off". The "Input" and "Output" lines are only displays. The values indicate the current position of the control stick "Input" and the position of the control signal (output).
Switch display Channel 1 cur ve Switch display Control switch Logical switch Announce Phase settings Schalter 4 1 2 3 7 8 9 6 11 12 13 14 C3 C2 C1 C7 C6 C5 The switch display is a mere display, it is a check function of the switches and control switch in the transmitter. Active switches are highlighted. On the right near the switch number the switch position is displayed with a switch-symbol.
Logical switch Through this function two switches, controls and/or logical switches or the favorite combination of them, can be interconnected. It is realized through a "AND" or "OR" switch. You can program a total of eight logical switches ("L1 ... L8") in each model memory. The result of such a logical switch function can be used as alternative switch function.
Assigning the switch / Selecting the announce 1 2 3 4 ––– ––– ––– ––– Announce GL GL GL GL Typ • In the column “ “ assign a switch, for each switch position it is possible to assign an announce • In the column "Type" you can decide if the announces have to act globally (GL) or according to the phase (PH) • In the right column you can select the announces available in the memory Phase setting Announce Phase settings Phase assignment Phase trim Non-delayed chan Timers (general) Pha1 Pha2 Pha3 Pha4
Time1 Only the times whose switch or control switch, assigned in the line "Lap time/Time tab." of the "Phase timer" menu, is "closed" are measured. The frequency of the switch actuation is displayed in the basic display. This counter will be highlighted as soon as the switch for the "Time1" timer is "open", the timer is hold (stopped). In the stopped state, the recorded switching times can be successively read out with the selection keys.
Pha1 Pha2 Pha3 Pha4 Pha5 Announce normal – Star t – Strecke – – Announce Here you can select an announce for each phase. The announce can be selected from the supplied voice pack or from a user voice pack. When you switch to the corresponding phase, the announcement is reproduced. Phase assignation In this menu, you can assign a switch or switch combination to the phases.
Note The trim of "Elevator", "Aileron" and "Rudder" is factory-set to "Global". This setting can, however, always be changed to "phase-specific" at any time in the "Sticks setting" menu. Channels without delay Annnounce Phase settings Phase assignment Phase trim Non-delayed chan Timers (general) Non-delayed channels non-delay normal 7 8 9 10 11 12 Normal In this menu item, you can switch off the switching delay set in the "Phase setting" menu for individual control channels depending on the phase.
the selection key over the "Timer" column to the right side. The timer defined as "stopwatch" or "motor runtime" adds the switch-on time. If you do not enter a value in the "Timer" column, the timer counts up. If you set a value, the timer counts backward from this value. Through the buttons t u or of the right touch-pad you can reset the timer in the basic display to "0:00h". In the "Alarm" column, you can specify a time at which an audible alarm is emitted.
Reset to the initial value by tapping at the same time the t u or buttons of the right touch-pad. Chassis This timer is started by an assigned switch. If you want to stop the timer, you must switch the assigned switch to the "Off" position and press the ESC key. Reset to the initial value by tapping at the same time the t u or buttons of the right touch-pad. Phase timer In this menu you can set the timers assigned in the "Phase setting" menu.
Good to know: What is a mixer? Each model memory has eight freely programmable linear mixers, four freely programmable curve mixers and four cross-mixers. These mixers basically allow a control signal from one control to be mixed with another channel. Depending on the type of mixer, this can be adjusted linearly, in the form of a curve or crosswise. In addition, there are pre-programmed mixers in the "Wing mix" menu.
Programming of the wing type Model type: "1AIL" Wing mixers Brake settings AI 0% ––– RU Nor mal If you have entered "1AIL" in the "Aile/Flap" line of the "Model type" menu, the "Mixer menu" of your transmitter corresponds to the figure on the left. Regardless of the selected combination of ailerons and flaps, all available parameters can be changed depending on the phase.
Aile -> Dir Wing mixers Brake settings AI 0% ––– RU EL FL 0% ––– 0% FL EL 0% 0% ––– Normal Model type: "2AIL" Wing mixers Brake settings 0% Aile diff. AI 0% ––– RU EL AI 0% 0% ––– Normal The aileron is mixed up with the rudder. In conjunction with the differentiation of the ailerons the negative torque is compensated. This allows a "clean" curve flight. The rudder remains separately controllable. The deflection direction can be adjusted in the range of ±150%.
Model types with "2/4AIL 1/2/4FLAP" Regardless of the selected combination of ailerons and flaps, all Wing mixers available parameters can be changed depending on the phase. Multi-flap menu Brake settings Aile diff.
AI AI-Tr. Diff. AI Pos. FL EL FL EL FL Off. Nor mal +100% +100% 0% 0% 0% 0% 0% 0% 0% ––– AI Model type: "2AIL 4FLAP" The options available in the Wing mix menu and its submenus depend on the number of ailerons and flaps servos specified in the "Model type" menu. Only the necessary setting options are available at all times. With this setting, all options for the pair of ailerons and, after a "step" to the right, the options of the pair of flaps are displayed.
Model type: "4AIL 4FLAP" If the servos are connected to the receiver as described in the section "Receiver assignment" and if you have selected in the "Model type" menu, the abbreviations "AILE", "AILE2", "FLAP" and "FLAP2" refer to the following flaps. AI left AI2 left FL left FL2 left FL2 right FL right AI2 right AI right With this setting, all options for the pair of ailerons and, after a "step" to the right, the options of the second pair of ailerons are displayed.
Multiflaps menu Wing mixers Multi-flap menu Brake settings 0% Aile diff. AI 0% ––– RU FL EL 0% 0% ––– Normal This menu is only displayed if at least two ailerons and one flap or more are selected in the "Model type" menu. The "AILE2" column and the "FLAP" and "FLAP2" columns are available in this menu to the right of the "AILE" column, depending on the number of pairs of control surface specified in the »Model type« menu. AILE AI AI Tr. Diff. FL pos. Normal +100% +100% 0% 0% AI AI Tr. Diff. FL pos.
Diff. FL pos. FL EL FL Nor mal 0% 0% 0% 0% ELE -> FLAP (ELEVATOR -> FLAP) 0% 0% AI FL pos. 0% FL 0% 0% EL FL 0% 0% 0% ––– EL FL Off. Nor mal STO In order to support the elevator, the flap function can be influenced by the elevator control in a phase-specific manner through this mixer. Select the mixing direction so that the flaps move downward when the elevator is pulled ("up"), and conversely upward when the elevator is pushed ("down"), that is, in an opposite direction.
Brake setting Wing mixers Multi-flap menu Brake settings 0% Aile diff. AI 0% ––– RU FL EL 0% 0% ––– Nor mal Brake settings Butt. 0% 0% D.red 0% 0% EL cur ve Normal FL AI 0% 0% FL2 The "Brake settings" menu is not shown if in the "Model type" menu "Motor on CH1 front / rear" and in the column "Motor" of the "Phase setting" menu for the currently active phase it has been entered "yes". The "Brake mixers" can be adjusted according to the phase. Butt.
D.red (Differentiation reduction) Brake settings Butt 0% 0% D.red 0% 0% AI cur ve Nor mal FL AI 0% 0% FL2 If you use the aileron differentiation, the aileron effect is more or less strongly affected by the arise of the ailerons. Justification: a further excursion of the one aileron is no longer possible (almost) and the control surface moving downward does not reach the "normal" position.
AIL -> RUD (aileron -> rudder) Wing mixers Multi-flap menu Brake settings AI 0% ––– RU FL EL 0% 0% ––– Normal FLAP -> ELE (flaps -> elevator) Wing mixers Multi-flap menu Brake settings AI 0% ––– RU FL EL 0% 0% ––– Normal In this mixer, the aileron is entrained by the aileron control. In conjunction with the differentiation of the ailerons the negative torque is compensated. This allows a "clean" curve flight. The rudder remains separately controllable.
Free mixers Phase timers Wing mixers Free mixers MIX active/phase MIX-only channel Dual mixer M1 M2 M3 M4 M5 Typ ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? fr zu M8 C9 C10 C11 C12 Typ ?? ?? ?? ?? ?? ?? ?? ?? ?? ?? fr zu In this menu you can find free programmable linear and curve mixers. Regardless of the type of model chosen, in each model memory are available eight linear mixers with the designation M1 to M8 as well as four curve mixers with the designation C9 to C12. Mixer programming step by step: 1.
In a series switch of mixers, the direct control signal of the channel is not used as the input of the mixer but the already mixed signal of the channel from the upstream mixer. P : This option also includes the trim values from the "Phase trim" menu of the input channel as a function of the phase. Notice In the case of series switch, note that the mixing travel of the individual mixers add together with simultaneous stick movement. As a result, the servo or the servos may mechanically collide.
Offset (mixer neutral point) The dotted vertical line in the middle of the graphic indicates the position of the mixer neutral point ("offset"). This is the point on the control travel where the mixer does not affect the control channel. By default this point is in the control center. If you select the line under "Offset", the bottom line will show "STO" and "SET". With the selection of "STO" you define the position for the offset with the control.
C.Mix 9 aus Kur TrimveX axis Input +35% –37% Output –55% Point 2 nor mal 8 10 Trim X-axis function This function can be activated by tapping the left-hand t or the right u selection button of the right-hand touch panel while the value field is active. You can then move the active point horizontally or vertically using the selection buttons. Deleting support points Place the marker frame in the "Point" line and briefly tap the SET button.
Dual mixer Mixer1 Mixer2 Mixer3 Mixer4 Typ Dual mixer ?? ?? ?? ?? ?? ?? ?? ?? zu 0% 0% 0% 0% Diff. In this menu, you can link two control functions with four freely programmable dual mixers. Example (V-tail mixer): 4,8 V C 577 Servo C 577 4 4,8 V Rudder / Elevator right Best.-Nr. 4101 4 Rudder / Elevator left Servo Control channels (receiver outputs) V-Tail mixer er dd r Ru vato Ele Control functions inputs Ru dd er r Se Ele ite vat or 3 o vat Ele 3 Best.-Nr.
Trainer In this menu you can set the functions for the teacher / pupil operation. The operation can be wireless or wired with HoTT transmitters. Please also observe the instructions of the pupil transmitter. T/P:Pupil Pupil Teacher SW: ––– 1 2 3 4 5 6 n/a BIND: Connection through cable (DSC port): Teacher function Pupil transmitter: start a new model memory without programming, select the mode setting. Teacher transmitter: Select the channels which have to be handed over to the pupil transmitter.
Profitrim Profi trim AI AI FL FL TR OFF OFF OFF OFF CTL ––– ––– ––– ––– ON/OFF ––– SET SET SET SET Function for fast, direct trimming of the aileron and flap positions. The trim range of the controls is about ±25 %. In the line "TR" it is determined which of the two control surfaces pairs "AILE" and "FLAP" and which of the two possible flap functions should be able to be trimmed. In the line "Ctrl", you define the proportional control to be used for trimming.
Trim memory Trim memory CH1 0% 0% AILE 0% ELEV 0% RUDD POS Storage of the actual trim position 0% 0% 0% 0% SET In the left column (POS) is shown the actual value of the trim. If you tap now the SET button, the trim value is transferred to the memory. The trim value is now displayed in the "SET" column on the right side. The bar display in the main display shows again the center position. If you want to delete the stored trim value, tap the selection keys t u or on the selected line.
Telemetry TEL.RCV BIND. 1 SETTING & DATA VIEW SENSOR RF STATUS VIEW VOICE TRIGGER RX DATA ON ALARM SETTING 3 :435_USER_Voice_MU 4 :436_USER_Voice_MU 5 :437_USER_Voice_MU 6 :438_USER_Voice_MU 7 :439_USER_Voice_MU 8 :440_USER_Voice_MU 9 :441_USER_Voice_MU 10:442_USER_Voice_MU ALARM SETTING - Tapping the SET button will display a list. In the first line, select "OFF" to disable the function of this menu.
10 11 12 0 ST 4. In the left column, select the channel to be edited first, then proceed with the other channels the same way 0.1s TIME 0% POS ––– 5. Sequence 0u: Set the initial position in the value field through "POS". 6. In the value field of the "Time" column, use the selection keys t u (left) to set the duration of the first sequence. 7. Sequence 1 … max. 9 - The next sequence is selectable when a time has been set.
Required receiver settings: In the "SETTINGS & DATAVIEW" menu set "20 ms". In the "SETTINGS & DATAVIEW" menu set "SAME". The control channel in use should not be used either as an input or as an output channel of a mixer.
MP-3 Player F i l e n o t fo u n d A ––– Vol:15 fr A00/00 ––– T00/00 If the message "no files" appears, the transmitter will not find any suitable MP3 files on the inserted SD card or there is no SD card in the transmitter. Insert a suitable card or check the contents of the "MP3" directory on the SD card on a PC or laptop. Copy appropriate MP3 files to this directory. Make sure there are two specific font files in the MP3 directory. These files are necessary to display the titles correctly.
Control mode (preset) Here you can select the control mode that is preset when setting up a new model memory. This determines which control functions are assigned to the control sticks. In the "Receiver assignment" menu, you can see which control function is output on which channels. Changing the control mode in an existing model memory is only possible in the "Basic setting model" menu.
Stick-type (only by mc-26) Potentio. - Setting when standard gimbal sticks with potentiometers are used. 4D-stick - Setting when optional 4D-stick gimbal sticks with potentiometers are used. Module DSC port The transmitter is equipped with a HoTT RF module as standard. External RF modules from other manufacturers can be connected to the DSC and DATA sockets. The selection of "HoTT", "EXT." or "SP." can be switched specifically for the model memory.
Switch-on melody Battery alarm threshold Switch-on warning Touch sensitivity DATA sel. In this line, you can turn on and off the switch-on and the switch-off sounds. In this line you can preset the warning threshold of the display in 0,01V steps between 3.50 and 4.50 V depending on the type of battery used. Make sure that the set value is not too low to give you sufficient time to land your model after a battery warning.
Vibration Vibra tio n a l a rm OFF P ow e r on OFF Volta ge Ra nge ON V03 Te le me try OFF Time norma r l Here you can assign a vibration alarm to the listed warnings. There are 10 different variants (V01-V10) or "OFF" of the vibration alarm.
Info display ABCDEF12 RFID 1.234 firmware ver. 2016/09/17(Sa ) date 18:19:20s time SD-CARD 3896MB 3623MB available 92% This menu shows information about the transmitter and the SD card. The date and time can be set here. RFID - Identity number of the transmitter Firmware version - shows the version of the transmitter firmware Dat.
Heli programming Select model type Suppress models Base setup model Helicopter type Ser vo adjustment Stick mode Control adjust Base setup model RF Range test 99sec DSC Output PPM10 Autorotation ––– Auto.C1 Pos. -55% ––– STO Suppress models Base setup model Helicopter type Ser vo adjustment Stick mode Control adjust Helicopter type Swashplate 1 Ser vo no Linear. swashpl. Rotor direct right Pitch min.
Helicopter type Swashplate 3Sv(2rol) no Linear. swashpl. Rotor direct right Pitch min. back SEL • Swashplate linearization: For Flybarless systems, select "no" here. In the case of paddle head systems, the setting "yes" can prevent unwanted side effects, such as pitch change when the roll function is activated or tensions between the linkage of the swash plate servos. • Rotor direction: Here you can set the direction of the rotor direction, seen from above the helicopter (see figure).
Announce Phase settings Phase assignment Non-delayed chan Timer (general) Phase timers Phase assignment combi prior C D E F A B 6 5 2 5. Phase assignation menu: • Switching off the autorotation switch • Select the switch for the normal flight phase and switch it off in the correct position. • Select combination C and press the SET key • Actuate the selected flight phase switch. • Switch to test whether the switch between the flight phase Normal and Acro 3D is correct.
Throttle curve (Heli) The setting of the curve is explained in the previous description of the menu "Throttle curve". Note that the curve characteristic set here acts as an input signal on mixers of the "Helicopter mix" menu. Ser vo adjustment Stick mode Control adjust Dual Rate / Expo Channel 1 cur ve Switch display PitchKnüppel K-1Kurve »Heli-Mischer« Pitch K1 Gas K1 Heckrotor Sticks setting (Heli) The setting of the column is explained in the previous description of the menu "Stick settings".
Channel 7 - Gyro In5 GL Thro GL Gyro GL In8 GL Nor mal typ fr fr fr fr ––– ––– ––– ––– SEL 0% 0% 0% 0% Offset Current gyro systems can be adjusted for a smooth, proportional effect; you can also choose between two different modes of action by the transmitter. If the Gyro you are using has this option, you can specify "Normal" Gyro action and "Heading Lock operation" in the "Offset" column in the range of ± 125%.
Ring limit Ring limiter OFF 4 3 4 3 4 3 10 9 OFF 4 3 12 11 OFF X Y X Y SET Input Output This function is used to control up to three of the so-called Voith-Schneider drives of ship models. The function only appears in the multi-function menu when the model type "Boat" has been selected. In the "Input" column, select the two channels which are to be used for controlling the drive unit. You can also use channel 5 - 16. A control must then be assigned on the selected channel.
Firmware update The programs and files which are also required for updating the transmitter combined into one software package can be downloaded from www.graupner.de. Download this software package from the Internet, and unpack it on your computer. All other information can be found in internet in the same page where the software package is available. Firmware updates of the transmitter can be performed in two ways.
Update through USB port Download the actual software package from the Internet, and unpack it on your computer. Connect your switched off transmitter with your PC, by using the included USB cable, which is supplied with the package content, plug USB cable directly to the micro USB port of the transmitter and the other end to a free port in your computer. All other information can be found in the instructions that come in the software package.
Notes on environmental protection Disposal notes This symbol on the product, user manual or packaging indicates that this product must not be disposed of with other household waste at the end of its life. It must be handed over to the applicable collection point for the recycling of electrical and electronic equipment. The materials are recyclable as marked. By recycling, material reusing or other forms of scrap usage you are making an important contribution to environmental protection.
