Spec sheet

Features and Benefits:
Medium Static Pressure Capability
Slim Line Construction 7-7/8” high
Flexible Return Air From Bottom Or Rear
IR Remote Control
Internal Condensate Drain Pump
Sentry Float Switch
Environmentally Safe R-410A Refrigerant
XK - 19 Tether Controller
Slim Duct
Compact and powerful, the Gree Multi+ Concealed Duct
indoor units offer the ultimate in flexibility and discretion.
These slim indoor units are designed to be concealed
above suspended ceilings or within open closet spaces to
deliver conditioned air via ducting and suitable ceiling or
wall grilles. This arrangement provides immense flexibility,
in terms of both the distribution of conditioned air and the
type of grille or diffuser that best compliments the room’s
styling. Each unit comes with an easy to operate wall
mounted tether controller.
CONCEALED DUCT INDOOR DATA DUCT09HP230V1AD DUCT12HP230V1AD DUCT18HP230V1AD DUCT24HP230V1AD
Rated Capacity - Cooling BtuH 8,500 11,900 15,300 23,800
Rated Capacity - Heating BtuH 9,500 13,100 18,700 27,400
Dehumidification pint/hr 1.7 3.0 3.8 5.3
Power Supply (60hz 1-phase) volts 208/230V
Rated Current amps 0.28 0.31 0.41 0.5
Airflow (min/max) CFM 147/265 177/324 294/412 324/589
Sound Pressure Level (min/max) dB(A) 31/37 32/39 33/41 34/42
Unit Dimensions (WxHxD) inch 27.6 x 7.9 x 24.2 27.6 x 7.9 x 24.2 35.4 x 7.9 x 24.2 43.3 x 7.9 x 24.2
Weight (Net/Gross) lbs. 49/60 51/64 60/79 68/90
Refrigerant Port Size (Liquid - Gas/Suction) inch
φ1/4 - φ3/8 φ1/4 - φ3/8 φ1/4 - φ1/2 φ3/8 - φ5/8
Field Drain Pipe Size O.D.
φ1.0-in (φ26-mm) φ1.0-in (φ26-mm) φ1.0-in (φ26-mm) φ1.0-in (φ26-mm)
