Spec sheet

Our Multi+ Universal Floor/Ceiling indoor units are designed to be
suspended from a ceiling or mounted low on a wall. The slender and
lightweight design is perfect for restaurants or hallways where wall
space is limited. Aesthetically pleasing to the eye, the Multi+ Universal
Floor/Ceiling units are a great fit beneath windows, in public or light
commercial applications. Each unit can be operated by an infrared
remote control or wired tether controller to allow maximum flexibility
in any application.
Features and Benefits:
4-way Discharge Air
Multi Speed Fan
IR Remote Control
XK - 19 Tether Controller
Comfortable Sleep Mode
Swing Louver
Cleanable Air Filter
Dry Coil mode for Anti -Mildew Protection
Remote Control Lockout
Power Failure Recovery
Universal Floor/
Ceiling
FLOOR/CEILING INDOOR DATA FLR09HP230V1AF FLR12HP230V1AF FLR18HP230V1AF FLR24HP230V1AF
Rated Capacity -Cooling BtuH 8,500 11,900 17,000 22,800
Rated Capacity - Heating BtuH 9,500 13,100 18,700 27,400
Dehumidification pint/hr 1.7 3.0 3.8 5.3
Power Supply (60hz 1-phase) volts 208/230V
Rated Current amps 0.3 0.3 0.5 0.5
Airflow (min/max) CFM 265/383 265/383 294/559 412/736
Sound Pressure Level (min/max) dB(A) 36/40 36/40 40/45 44/48
Unit Dimensions (WxHxD) inch 48.0 x 27.6 x 8.9 48.0 x 27.6 x 8.9 48.0 x 27.6 x 8.9 48.0 x 27.6 x 8.9
Weight (Net/Gross) lbs. 88/110 88/110 88/110 100/120
Refrigerant Port Size (Liquid - Gas/Suction) inch
φ1/4 - φ3/8 φ1/4 -φ3/8 φ1/4 - φ1/2 φ3/8 - φ5/8
Field Drain Pipe Size O.D.
φ0.67-in (φ17-mm) φ0.67-in (φ17-mm) φ0.67-in (φ17-mm) φ0.67-in (φ17-mm)
